Weight Limit:
300 Lb / 136 Kg For Upper Bed
130 Lb / 59 Kg For Desk
C.W. - 2019/4/29
2014 Dorel Home Products All Rights Reserved
Metal Loft Bed with Desk
Thank you for purchasing from DHP!
DO NOT RETURN TO THE STORE !
If parts are missing or damaged, we will gladly ship your
replacement parts free of charge.
Visit www.dhpfurniture.com/eng/replacement-parts
or call Toll-Free 1-800-267-1739
Date of Purchase
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY
INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
4308429
Lot Number
B34430842900
Full
Silver
1
Advertisement
Table of Contents
Related Manuals for Dorel Home Products 4308429
Summary of Contents for Dorel Home Products 4308429
- Page 1 Visit www.dhpfurniture.com/eng/replacement-parts or call Toll-Free 1-800-267-1739 Date of Purchase Lot Number THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. B34430842900 C.W. - 2019/4/29 2014 Dorel Home Products All Rights Reserved...
- Page 2 Warranty Information Read Before Beginning Assembly DHP warrants this product to be free from defects in material and workmanship and Call our toll free number if you need assistance. agrees to remedy any such defect. This warranty covers one year from the date of Work in a spacious area and near where the unit will be used, preferably on a original purchase.
- Page 3 Parts Replacement Parts, visit www.dhpfurniture.com/eng/replacement-parts All in 1 big box! There are inner box(es) that include components required to complete this assembly. Before you throw the package, please use the Post Post Post Post Guard Rail Check Box to identify the parts and ensure that T964040 T964050 T964060...
- Page 4 Parts Replacement Parts, visit www.dhpfurniture.com/eng/replacement-parts All in 1 big box! There are inner box(es) that include components required to complete this assembly. Before you throw the package, please use the Rail Brace Desk Slat Check Box to identify the parts and ensure that T964000 T965320 T922560...
- Page 5 Hardware Pack Hardware Pack #: T4308429-00 1/4" X 11/16" 5/16" X 3/4" X 28 X 10 1/4" X 1 3/8" 1/4" X 2" 5/16" X 2 3/16" X 23 Please do not completely tighten all the hardware, until the entire assembly is complete, unless otherwise indicated in the step-by-step instructions.
- Page 6 Step 1 Attach G to D with Attach Z to D & G with...
- Page 7 Step 2 Attach M to D & Z with Attach K to Z with Note: Part K must be oriented as indicated with the bracket towards part M.
- Page 8 Step 3 Attach C to G, K & M with &...
- Page 9 Step 4 Attach I, R & L to A & B with & For your safety, please ensure that the warning on I is oriented towards upside and inside of the bed. Warning label on I should be oriented on the same side as side rail holes!
- Page 10 Step 5 5.1 Attach E X 2 to A, B, C & D with 5.2 Attach J X 2 to A, B, C & D with Wide side of the slot should be facing up !
- Page 11 Step 6 Attach V to I & G with...
- Page 12 Step 7 Insert P into J X 2 as illustrated, then lock P into place with Y.
- Page 13 Step 8 8.1 Press W onto P as illustrated. 8.2 Press Q onto W alternating left and right as illustrated. For better performance, attach the Slat Spacers Q at equal spaces. (Approximately = 17.5 inches or 445 mm for upper bed). 17.5"...
- Page 14 Step 9 Attach F to K & R with Attach H to B & C with &...
- Page 15 Step 10 Attach S to H & F with...
- Page 16 Step 11 Attach T to A & J with Attach T to B & J with Attach T to C & J with Attach T to D & J with Edge must be faced inside.
- Page 17 Helpful Hints Weight Limit: 300 Lb / 136 Kg For Upper Bed 130 Lb / 59 Kg For Desk Move your new furniture carefully, with two people lifting and carrying the unit to its new location. Your DHP furniture can be disassembled and reassembled to move.
- Page 18 WARNINGS for Bunk Bed Follow the information on the warnings appearing on the upper bunk end structure and on the carton. Do not remove warning label from bed. Always use the recommended size mattresses or mattress supports, or both, to help prevent the likelihood of entrapment or falls. Use only a full mattress which is 74"-75"...
- Page 19 4308429 NO LO REGRESE A LA TIENDA ! Si le faltan piezas o las que se incluyen est n da adas, con Cama elevada con escritorio mucho gusto le enviaremos sus piezas de reemplazo sin cargo extra. Matrimonial Visite www.dhpfurniture.com/spa/replacement-parts...
- Page 20 Partes Instrucciones Paso 1 Piezas de reemplazo, visite www.dhpfurniture.com/spa/replacement-parts Una G con D con Todo se incluye en 1 caja grande! Una Z con D & G con Paso 2 Hay 1 caja(s) interna(s) que incluyen los componentes necesarios para completar este ensamblaje.
- Page 21 Consejos tiles L mites de peso: 300 Lb / 136 Kg en la cama superior; 130 Lb / 59 Kg en la escritorio. Mueva sus muebles nuevos con cuidado, con dos personas levantando y llevando el aparato a su nueva ubicaci n. Precauc on Sus muebles DHP se pueden desmontar y volver a ensamblar en caso de mudanza.
- Page 22 4308429 NE RETOURNEZ PAS AU MAGASIN ! Si une pi ce est manquante ou endommag e, nous vous Lit mezzanine avec bureau exp dierons avec plaisir vos pi ces de remplacement gratuitement. Lit deux places Visitez www.dhpfurniture.com/fre/replacement-parts Argent ou appelez au 1-800-267-1739...
- Page 23 Pi ces Instructions Pi ces de rechange, visitez www.dhpfurniture/fre/replacement-parts tape 1 Attacher G D avec Tout dans 1 grosse bo te! Attacher Z D & G avec Il y a des bo tes int rieures qui contiennent les composants pour completer tape 2 l'assemblage.
- Page 24 Conseils utiles Limite de Poids: 300 Lb / 136 Kg sur le lit sup rieur; 130 Lb / 59 Kg sur le bureau. D placez votre nouveau mobilier avec soin, nous recommandons deux personnes pour soulever et transporter le mobilier vers son nouvel emplacement. Avertissement Votre mobilier DHP peut tre d mont et r -assembl pour faciliter les d m nagements.
