SEC-ADW10
DOOR/WINDOW ALARM
Description:
1. Siren
3. Keypad
4. Battery LED indicator
5. Battery Compartment
Battery installation:
1. The battery compartment is accessed from
the rear of the alarm by removing the screw
from the bottom and lifting the back cover (see
figure B).
2. Insert 4x AA size batteries (not included)
according the polarity as shown in figure C.
3. When the last battery is
inserted the alarm will beep
very loud to indicate that the batteries are
installed properly. Replace the back cover.
NOTE: After removing the batteries, press
number 4 before installing new batteries. The
alarm must be programmed again with the
security code each time the batteries are
removed or replaced.
ENGLISH
INSTRUCTIONS
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Konig Security SEC-ADW10
Summary of Contents for Konig Security SEC-ADW10
- Page 1 ENGLISH INSTRUCTIONS SEC-ADW10 DOOR/WINDOW ALARM Description: 1. Siren 2. Magnetic Contact 3. Keypad 4. Battery LED indicator 5. Battery Compartment Battery installation: 1. The battery compartment is accessed from the rear of the alarm by removing the screw from the bottom and lifting the back cover (see figure B).
- Page 2 Alarm installation: Alarm Place the alarm on the door or window with screws or adhesive tape. Magnetic contact The magnetic contact must be aligned to the same level next to the alarm so contact can be made when the door or window is closed, either on the left or right side (see figure D).
