  • Page 1 TE-06 TOWERLIFT TORRE ELEVADORA OPERATING INSTRUCTIONS USER MANUAL MANUAL DE INSTRUCCIONES V.04.14...
  • Page 2 Tlf Nacional: 96 171 81 83 info@prolifts.es - www.prolifts.es Este manual de usuario y catálogo anexo de piezas de repuesto es propiedad de PRO LIFTS S.L. Queda prohibida su reproducción total o parcial por cualquier medio que la tecnología actual permita.
  • Page 3 R: Catch pawl / Gatillo bloqueo patas S: Transport compartment / Alojamiento de transporte T: Transport wheels / Ruedas de transporte V: Working compartment / Alojamiento de trabajo W: Winch / Cabrestante PRO LIFTS S.L. Depósito legal y copyright 2014. Todos los derechos reservados.
  • Page 4 The model type, production year and se- rial number must be quoted in any queries 2.14 - Exclusive ALS system (Auto-Lock Security), pat. pen. 200501056.hed in sa- or orders for spare parts. tin polyester. PRO LIFTS S.L. Depósito legal y copyright 2014. Todos los derechos reservados.
  • Page 5 PRO LIFTS S.L. Depósito legal y copyright 2014. Todos los derechos reservados.
  • Page 6 3.10 - Take care with all obstacles above the lift and its extension zone such as cornices, balconies, and luminous signboards. It is very important to avoid the presence of all types of cables below the extended lift. PRO LIFTS S.L. Depósito legal y copyright 2014. Todos los derechos reservados.
  • Page 7 25Kg. Without this load the brake will not work. 3.16 - NEVER take apart the crank of the winch when the lift is carrying a load or extended. PRO LIFTS S.L. Depósito legal y copyright 2014. Todos los derechos reservados.
  • Page 8 4.5 - Blocking: Once the system is ele- bridge, down truss or many towers to ele- vated to its required height gently turn the vate a structure of any type, it is almost PRO LIFTS S.L. Depósito legal y copyright 2014. Todos los derechos reservados.
  • Page 9 PRO LIFTS S.L. promises, that from the immediately with a new one. Do not use date of purchase and during the warranty the lift if the cables are in bad condition.
  • Page 10 2.13 - Cable: Acero DIN 3060. Calidad de las especifi caciones y las piezas del pro- resistencia a la torsión 180 kg/mm ducto sin previo aviso. El tipo de modelo, Diámetro del cable: 4 mm. PRO LIFTS S.L. Depósito legal y copyright 2014. Todos los derechos reservados.
  • Page 11 Es necesario verifi car que la carga está correctamente apoyada y centrada en el soporte de elevación apro- piado para que el peso de la carga sólo actúe en una dirección vertical. PRO LIFTS S.L. Depósito legal y copyright 2014. Todos los derechos reservados.
  • Page 12 Es muy importante evitar la presencia de todo tipo de cables por debajo de la torre ex- tendida. PRO LIFTS S.L. Depósito legal y copyright 2014. Todos los derechos reservados.
  • Page 13 25 kg. Sin esta carga mínima el freno no funcionará. 3.16 - NUNCA desmontar la manivela del cabrestante cuando el elevador está soportando una carga o exten- dido. PRO LIFTS S.L. Depósito legal y copyright 2014. Todos los derechos reservados.
  • Page 14 Manual de usuario ESPAÑOL 3.17 - Sólo deben ser utilizadas piezas de repuesto originales de VMB PRO LIFTS S.L. O R I G I N A L 4.4 - Elevación: Gire la manivela del 4. INSTRUCCIONES DE USO. cabestrante en sentido horario (N ) para 4.1 - Colocar el elevador sobre una super-...
  • Page 15 No deben utilizarse estructura y aplicará una fuerza lateral a otros productos, para evitar los efectos los elevadores provocando su bloqueo y negativos sobre el mecanismo de frena- ruptura. PRO LIFTS S.L. Depósito legal y copyright 2014. Todos los derechos reservados.
  • Page 16 El período de garantía para este elevador es de 2 años a partir de la fecha de com- pra. PRO LIFTS S.L. se compromete, que a partir de la fecha de compra y durante el período de garantía, a resolver los fallos que puedan producirse, debidos a mate- rial defectuoso o fabricación.
  • Page 17 TE-06 3234/ 3235/ 3236/ 3234B 3235B 3236B 2034 6402/ 6402B 6408 2055/ 2055B PRO LIFTS S.L. Depósito legal y copyright 2014. Todos los derechos reservados.
  • Page 18 TE-06 2042/ 2042B 2043 2209N 2049 x4 2036/ 2036B 2032 2056 2021 2023 7061 2090 2044 2032 2056 2041 2032 2056 PRO LIFTS S.L. Depósito legal y copyright 2014. Todos los derechos reservados.
  • Page 19 2152 x3 7078 x3 2035 2044 7061 7061 2038 2047 2047 2029 2050 2051 2056 x2 2161 Estabilizador completo TE-06 2046 2037 Ref: 2434 7061 2033 2030 2048 2049 PRO LIFTS S.L. Depósito legal y copyright 2014. Todos los derechos reservados.
  • Page 20 TE-06 2027 6406 6401 2028 2025 3233 2022 2024 2039 3233 2083 2083 3237 3238 3238 3238 3238 7078 PRO LIFTS S.L. Depósito legal y copyright 2014. Todos los derechos reservados.
  • Page 21 Tuerca autoblocante M5 2047 M12 Washer Arandela M12 2048 M6 Washer Arandela M6 2049 M6 Screw Tornillo M6 2050 M5 Screw Tornillo M5 2051 M10 nut Tuerca M10 PRO LIFTS S.L. Depósito legal y copyright 2014. Todos los derechos reservados.
  • Page 22 Tornillo M4 6408 Plastic end cap Tapón de plástico pata 7061 M10 Washer Arandela M10 7078 M8 Auto-blcok nut Tuerca autoblocante M8 7160ML 450 Kg Cabestrante Cabestrante 450 Kg PRO LIFTS S.L. Depósito legal y copyright 2014. Todos los derechos reservados.
  • Page 23 PRO LIFTS S.L. Depósito legal y copyright 2014. Todos los derechos reservados.
  • Page 24 / vmblifts Canal VMBLifts For further information follow the advise of our technicians: Para más información consulte con nuestros técnicos en: PRO LIFTS S.L. C/ Ciudad de Barcelona Nº19 Pol. Ind. Fuente del Jarro 46988 Paterna (Valencia) Spain Tlf Export: +34 96 171 81 86 Tlf Nacional: 96 171 81 83 email: info@prolifts.es...
