Summary of Contents for Thales Cinterion LGA DevKit Things
- Page 1 ® Cinterion LGA DevKit Things User Guide Version: DocId: lga_devkit_t_ug_v01...
- Page 2 Copyright © 2020, THALES DIS AIS Deutschland GmbH Trademark Notice Thales, the Thales logo, are trademarks and service marks of Thales and are registered in certain coun- tries. Microsoft and Windows are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries.
-
Page 3: Table Of Contents
® Cinterion LGA DevKit Things User Guide Page 3 of 26 Contents Contents Introduction ......................... 4 Feature and Benefits..................4 Supported Products ................... 5 Package Content ....................5 Quickstart ........................7 Mounting the LGA DevKit Socket ..............7 LGA DevKit Overview ....................8 Top and Bottom View.................. -
Page 4: Introduction
® Cinterion LGA DevKit Things User Guide Page 4 of 26 1 Introduction Introduction ® ® The Cinterion LGA DevKit is designed as a generic development adapter for Cinterion ® modules. With the LGA DevKit it is no longer necessary to connect the Cinterion evaluation modules to an adapter for test and development purposes. -
Page 5: Supported Products
® Cinterion LGA DevKit Things User Guide Page 5 of 26 1.2 Supported Products Supported Products The following table lists modules that are supported by the LGA DevKit T, depending on the module’s pad count (i.e., module’s footprint). Table 1: Supported products LGA DevKit T A (LGA 68) B (LGA 112) - Page 6 ® Cinterion LGA DevKit Things User Guide Page 6 of 26 1.3 Package Content Cinterion ® LGA DevKit socket T (L30960-N0114-A100) LGA112 Figure 2: LGA DevKit socket T with LGA DevKit variant T lga_devkit_t_ug_v01 2020-08-20 Public / Released...
-
Page 7: Quickstart
® Cinterion LGA DevKit Things User Guide Page 7 of 26 2 Quickstart Quickstart Please complete the following steps to quickly get started with your LGA DevKit. • Mount the LGA DevKit socket onto the LGA DevKit (for details see Section 2.1). -
Page 8: Lga Devkit Overview
® Cinterion LGA DevKit Things User Guide Page 8 of 26 3 LGA DevKit Overview LGA DevKit Overview Top and Bottom View Figure 3 Figure 4 show the top and bottom view of the of the LGA DevKit T variant. Error LED Configurable &... -
Page 9: Block Diagram
® Cinterion LGA DevKit Things User Guide Page 9 of 26 3.2 Block Diagram Block Diagram Native Micro USB Data Left side: Right side: Module Pins Peripherals Combinded Powering Module Signals RF Main/ DRX On board ASC0 Micro GPS Antenna Connector Connector Connector Jumper Status LEDS GPS Signal Jumpers ASC0 Switch Signal FTDI ... -
Page 10: Lga Devkit Interfaces
® Cinterion LGA DevKit Things User Guide Page 10 of 26 4 LGA DevKit Interfaces LGA DevKit Interfaces The LGA DevKit comes with two USB interfaces supporting power supply and serial commu- nication. You may choose to setup communication via a module's USB port and/or a module's UART (ASC0) port via FTDI232R VCP. -
Page 11: Pin Headers
® Cinterion LGA DevKit Things User Guide Page 11 of 26 4.3 Pin Headers Pin Headers The pin headers at the top side can be used to setup connections between modules and pos- sible on board peripherals. Thus, pin headers having signal names at their left side only, name- ly the pin headers CONTROL, ASC0_A, ASC0_B, DAI, ASC1, and GPIO, can be bridged by jumpers. -
Page 12: On Button: Module Start And Power Down
® Cinterion LGA DevKit Things User Guide Page 12 of 26 4.4 ON Button: Module Start and Power Down ON Button: Module Start and Power Down Pushing the ON button shortly (i.e., <0.5s), the LGA DevKit starts up and initially analyses the mounted module orientation and type. -
Page 13: Free Level Shifters
® Cinterion LGA DevKit Things User Guide Page 13 of 26 4.8 Free Level Shifters Free Level Shifters The LGA DevKit provides 4 free level shifters, placed & connected at the patch field on the un- derside. The level shifters are referenced to the module's Vext, and Vref that by default corre- sponds to 3V or to "REF IN"... -
Page 14: Patch Field
® Cinterion LGA DevKit Things User Guide Page 14 of 26 4.10 Patch Field 4.10 Patch Field A small patch field is available at the LGA DevKit's under- side. If required, you can add simple components (LED, Transistors etc.) here. All module signals, except USB and RF are accessible at the underside by the labeled pads. -
Page 15: Power Supply
® Cinterion LGA DevKit Things User Guide Page 15 of 26 4.11 Power Supply 4.11 Power Supply The LGA DevKit can be supplied through one or two USB ports that should be in the range of 5V +-5%, and/or externally by the DSB75/DSB-Mini. The modules supply level can be adjusted in the range between 2.8…4.8V by setting the variable resistor at the DevKit's top side. -
Page 16: External Reference Supply
® Cinterion LGA DevKit Things User Guide Page 16 of 26 4.11 Power Supply 4.11.2 External Reference Supply To drive/operate the LGA DevKit's interfaces at certain voltage levels, an external reference voltage may be connected. By default, i.e., without an external reference voltage connected, the interface operates at 3V to meet the DSB75/DSB-Mini requirements. -
Page 17: General Characteristics
® Cinterion LGA DevKit Things User Guide Page 17 of 26 5 General Characteristics General Characteristics The following table lists absolute maximum ratings for the LGA DevKit. Please note that viola- tion of these limits may cause permanent damage to the LGA DevKit. Table 2: Absolute maximum ratings Parameter Unit... -
Page 18: Operating The Lga Devkit With A Dsb
® Cinterion LGA DevKit Things User Guide Page 18 of 26 6 Operating the LGA DevKit with a DSB Operating the LGA DevKit with a DSB LGA DevKit on DSB-Mini The LGA DevKit supports a 2x40pin connector at its underside, compatible to the DSB75/DSB- Mini. -
Page 19: Lga Devkit On Dsb75
® Cinterion LGA DevKit Things User Guide Page 19 of 26 6.2 LGA DevKit on DSB75 LGA DevKit on DSB75 To operate the LGA DevKit with the DSB75 please complete the following steps: • Mount the LGA DevKit onto the DSB75. •... -
Page 20: Document Information
LGA DevKit T. Failure to comply with these precautions violates safety stan- dards. Thales assumes no liability for customer’s failure to comply with these precautions. The following is a non-extensive list of the mobile phone and LGA DevKit T usage restrictions: Pacemaker patients are advised to keep their hand-held mobile away from the pacemaker while it is on. -
Page 21: Appendix
® Cinterion LGA DevKit Things User Guide Page 21 of 26 8 Appendix Appendix LGA DevKit T 8.1.1 Placement CON14 CON9 CON13 CON11 CON12 CON7 CON10 LED2 CON18 LED6 CON17 BTN1 BTN2 LED9 LED4 LED5 LED3 LED1 Top view Underside view Figure 15: Top and bottom placements (LGA DevKit T) lga_devkit_t_ug_v01 2020-08-20... -
Page 22: Schematics
® Cinterion LGA DevKit Things User Guide Page 22 of 26 8.1 LGA DevKit T 8.1.2 Schematics MULTI_ADAPTER_TX62_TX82_STEP1_np MULTI_ADAPTER_TX62_TX82_STEP1_PATCHFIELD_np TX62 TX62 VUSB_MODULE 200R VUSB/3.?? VUSB RF_OUT ANT_MAIN/2.?? VUSB_MODULE VUSB BOARD.D+/3.?? USB_DP GNSS_ANT ANT_GPS/2.?? T22A BOARD.D-/3.?? USB_DN AUX_ANT ANT_DRX/2.?? NX3008NBKS PULL_VUSB/2.?? ON_MODULE/4.?? V180 VEXT_MODULE/2.?? -
Page 23: Lga_Devkit_T_Ug_V01
® Cinterion LGA DevKit Things User Guide Page 23 of 26 8.1 LGA DevKit T MICROCONTROLLER SMA + U.FL CONNECTORS 18pF 18pF ANT_MAIN/1.?? IC9A TP10 RESET@UC /RST_PCIN14_C6 SCK_PCIN5_B5 100k MISO_PCIN4_B4 MOSI_PCIN3_B3 +3V3/4.?? CON2 SS_OC1B_PCIN2_B2 ON_BUTTON 73251-1150 OC1A_PCIN1_B1 ON/4.?? RESET@UC 18pF 18pF ICP1_CLKO_PCIN0_B0 R100... - Page 24 ® Cinterion LGA DevKit Things User Guide Page 24 of 26 8.1 LGA DevKit T TC1014-3.0VCT713 LDO BATT+ GPS PWR LDO +3V BATT+: 2.8V - 4.86V TP68 EXTERN_REFERENCE/2.?? V480 VOUT BATT+/4.?? ANT_GPS_PWR/2.?? T14A BATT+/4.?? ISL80103 TP81 IC10 TP64 TP65 LDO_OUT/4.?? EN_BATT+/2.?? EN/UVLO NX3008PBKS...
- Page 25 ® Cinterion LGA DevKit Things User Guide Page 25 of 26 8.1 LGA DevKit T LEVEL SHIFTER ASC0.1 PINHEADER 80 PIN INTERFACE CON7 Control IC14 EEPROM VCC-A VCC-B VREF/3.?? VEXT_BUFF/3.?? ON/2.?? ON_MODULE/1.?? RXD0_X100/3.?? RXD0@LS EMERG_RST_X100/2.?? EMG_RST/1.?? CTS0_X100/3.?? CTS0@LS VEXT_JUMPER/3.?? VEXT_MODULE/2.?? CCIN_X100/2.?? CCIN/1.?? DAC_OUT_X100...
- Page 26 THALES DIS AIS Deutschland GmbH Werinherstrasse 81 81541 Munich Germany...
