- Page 1 Benefits: First time setup in 3 minutes Auto/Manual Clock in and Clock Daylight Saving Control out for HTA-820/830/840 TCP/IP Communication for Excellent for Payroll HTA-830/840 Management Perfect for wall-mount or PoE(Power over Ethernet) for desktop use HTA-840 Version 2.0...
- Page 2 NOTICE This manual is designed to provide information about HTA Series Time & Attendance Recorder. Every effort has been made to make this manual as accurate as possible, but no warranty or fitness is implied. Information contained in this manual is subject to change without prior notice in order to improve reliability, design or function.
-
Page 3: Table Of Contents
Table of Contents Package Contents ........................ 4 Product Overview ......................... 5 Features ..........................6 HTA-810/820/830/840 Comparison Table ................7 Specifications........................8 Physical Dimensions ......................9 Safety Precautions ......................10 Pictorial Introduction ......................12 Wiring Connections ......................15 RS-485 Wiring Connection ....................15 RS-232 Wiring Connection .................... -
Page 4: Package Contents
Screws x 4 Quick Start Guide x 1 EM Proximity Card x 1 Magnetic Cards x 3 Barcode Cards x 3 Additional items for HTA-810/820 Adaptor x 1 Cable x 1 DC Jack Converter x 1 If adaptor is not included. -
Page 5: Product Overview
Product Overview Thank you for purchasing this high quality “DIY” Time Attendance Recorder. HTA-810, 820, 830 and 840 are designed mainly for time and attendance recording with easy installation, auto/manual clock in and clock out and daylight saving control, 32 sets alarm outputs. -
Page 6: Features
Valid card identification, maximum storage up to 8,000 records for HTA-820/830/840. Standalone/Network communication via RS232/RS485, dial-up modem and TCP/IP (External Converter required) for HTA-810/820. HTA-830/840 uses TCP/IP communication interface. Visual LED for distant display of time, card number (last 4 digits) and for communication mode, swiped card indication. -
Page 7: Hta-810/820/830/840 Comparison Table
HTA-810/820/830/840 Comparison Table Description HTA-810 HTA-820 HTA-830 HTA-840 Transaction Data 8200 8200 8200 8200 Valid Card Identification, 8000 8000 8000 Max. Records Keypad 4 keys 4 keys 4 keys Keypad Backlight Re-swiped card auto 0 ~ 255 sec. 0 ~ 255 sec. -
Page 8: Specifications
Specifications Description HTA-810 HTA-820 HTA-830 HTA-840 8-bit Processor 256K Memory 1 Relay (Chime Bell/Electronic Lock) for HTA-820/830/840 Output Ports Cardholders/Events Max. up to 8200 transaction data LED Indicator Visual LED for display of time, Swiped card indication (last 4 digits), COMM. X 1... -
Page 9: Physical Dimensions
Physical Dimensions Front View & Side View Back Base... -
Page 10: Safety Precautions
Safety Precautions To ensure the maximum reliability of the HTA-810/820/830/840, please follow the guidelines listed below: DO’s Always read the safety precautions carefully. Keep this user manual for future reference. When product has been damaged during transit, kindly inform your courier. - Page 11 Electronic equipment may be hazardous if misused. Do not attempt to alter any interior components. Doing so may be extremely dangerous and may result in fire or electronic shock. Never pour away liquid into the opening that could damage or cause electrical shock. Do not attempt to use the device when it has been damaged.
-
Page 12: Pictorial Introduction
Pictorial Introduction ◆ Front View HTA-810 HTA-820/830/840 Visual LED to show time, last 4 digits of the card Time/ Message Display number or error message. Shift Key(for manual clock A, B, C, D (4 keys for HTA-820/830/840) in/clock out) Red LED blinks upon receipt of data from PC;... - Page 13 ◆ Backview With Base HTA-810/820 HTA-810/820 without Base...
- Page 14 HTA-830 HTA-830 without Base HTA-840 HTA-840 without Base...
-
Page 15: Wiring Connections
Wiring Connections RS-485 Wiring Connection Note: Assign different IDs for each HTA-810/820/830/840 recorder when there are more than one recorder in the network. Default ID is “1” Set your ID with our software. RS-232 Wiring Connection... -
Page 16: Tcp/Ip Rj-45 Connection For Hta-830
TCP/IP RJ-45 Connection for HTA-830 TCP/IP RJ-45 Connection for HTA-840... -
Page 17: Alarm Output Connection
Alarm Output Connection HTA-810/820/830 HTA-840... -
Page 18: Communication Connection
Communication Connection RS232/RS485 Communication Port for HTA-810/820 Communication Port for HTA-830... - Page 19 Communication Port for HTA-840 Note: POE stands for transmitting DC power.
-
Page 20: Power Supply Connection
Power Supply Connection Note: Power Supply Connection is for HTA-810/820/830. This is not applicable for HTA-840 as it uses PoE (Power over Ethernet) for its power supply. -
Page 21: Installation
Mount it onto the wall using the screws (not required for desktop use) Step 3~4 Align the extrusion part of the base to HTA-810/820 recorder’s slots on the edges for base installation Step 5~6 Fasten the 2 screws on the bottom to... -
Page 22: Troubleshooting
A: Please make sure DC12V power adaptor is properly plugged with correct polarity. Q: Unable to establish communications. A: For HTA-810/820, please make sure the device ID is correctly set. For HTA-830/840, make sure the IP port is correctly set. -
Page 23: Appendix 1: Error Message Description
Appendix 1: Error Message Description Error Code Message Description Err0 Cannot save invalid card Err1 Re-swipe of card within a limited time prohibited Err2 Card number contains non-numeric character under compression mode. Err3 Cannot overwrite, memory full Err4 Memory buffer 100% full Bad0 Flash configuration area damage Bad1... - Page 24 HUNDURE. In no event shall HUNDURE’s liability exceed the price paid for the product from direct, indirect, special, incidental, or consequential, damages resulting from the use of the product, its accompanying software, or it’s documentation.
