Installation and Operational Instructions for
ROBA -brake-checker plus AC Type 029.700.2
®
Standards
Product standard
VDE 0160 / DIN EN 50178:1998-04
EMC inspections
EN 61000-6-2:2006-03
EN 61000-6-4:2007-09
Insulation coordination
acc. VDE 0110 / EN 60664:2008-01
Installation space (e. g. control cabinet) IP54
Rated insulation voltage voltage inputs 480 V
Rated insulation voltage Grounding/Protective extra low
voltage 300 V
RMS
Reliability nominal values
SN 29500, T = 60 °C / failure rates, components
EN ISO 13849-1
Disposal
Electronic Components
Products which have not been disassembled can be
disposed of under Code No. 160214 (mixed materials)
or components under Code No. 160216 (Code No. acc.
200/532/EC), or can be disposed of by a certified disposal
firm.
Malfunctions / Breakdowns
Malfunction
Brake does not release
No signal
Error (continuous
signal)
Warning
10 10 10 10
26/06/2019 HH/GF
Page 10 of 10
Electronic equipment for
use in power installations
Interference immunity
Interference emission
RMS
Possible Causes
No supply voltage available
Brake line interrupted
Brake is not permitted
Brake is worn
Brake release is not recognised
Brake drop-out is not detected
Break voltage drop (supply voltage)
Wear limit reached
Supply voltage too low
Coil temperature of the brake too high
Chr. Mayr GmbH + Co. KG
Eichenstraße 1, D-87665 Mauerstetten, Germany
Tel.: +49 8341 804-0, Fax: +49 8341 804-421
www.mayr.com, E-Mail:
Guidelines on the WEEE Directive 2012 / 96 / EU
Avoidance of waste from electrical and electronic devices
and the reduction of such waste through recycling.
Our electromagnetic products (ROBA-stop
/ ROBATIC clutches) as well as the components required
®
for control and monitoring (rectifier / brake-checker) and the
DC motors (tendo -PM) are frequently used in electrical and
®
electronic devices within the appropriate area of application
of WEEE, independent of the applicable product categories.
The stated products do not fall within the area of application
of this Directive.
They have been classified as electromagnetic / electronic
components (VDE 0580) or as electronic equipment (EN
50178), and have been determined for installation in devices
for "use in accordance with the intended purpose". Only
products which are to be viewed as devices in terms of the
Directive and not as parts or components are subject to
registration obligations.
Measures
Check voltage on input terminal
Check brake supply line (check passage)
Use released brake
Open and clean the brake, check the air gap;
Replace the brake if necessary
Brake is not permitted
Incorrect RBC-module (brake nominal voltage)
Brake is not permitted
Check the supply module function
Check network stability and reinstate it
Check the brake and replace if necessary
Check or increase supply/output voltage on the
supply module
Check effective coil power, ext. Temperature, friction
