Bame Delma POLARIS 4 Manual

Electronic control board for sliding gates

Advertisement

ELECTRONIC
CONTROL BOARD
FOR SLIDING GATES
MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Delma POLARIS 4 and is the answer not in the manual?

Questions and answers

Summary of Contents for Bame Delma POLARIS 4

  • Page 1 ELECTRONIC CONTROL BOARD FOR SLIDING GATES MANUAL...
  • Page 2 !!! ATTENTION - NOTICE FOR THE INSTALLER !!! The bridges present on the contacts STOP, SENSITIVE EDGE, PHOTOCELLS, will not be installed anymore by BAME s.r.l. for safety and normative reasons. If one more of these contacts will not be utilised for any reason, the installer must insert a bridge on the contacts to assure a correct operation of the control board.
  • Page 3 POLARIS 4 POLARIS 4 MANUAL SUMMARY - Assembly diagram ........................- List of electric contacts ......................- Programming the work time ..................... - Programming of motor torque and timing: • Parameter T1 : motor torque for normal work phase ............9 •...
  • Page 4 ASSEMBLY DIAGRAM - 4 -...
  • Page 5 CONTACTS CLUTCH POWER SUPPLY (POSITIVE POLE) CLUTCH POWER SUPPLY (NEGATIVE POLE) CLUTCH HALL SENSOR 14 – 15 START/STOP CONTACT 14 – 16 OPEN CONTACT 17 – 18 PHOTOCELL CONTACT (Normally Closed ) 17 – 19 PRESSURE SAFETY DEVICE CONTACT (Normally closed) 20 –...
  • Page 6 CHECKS TO BE DONE BEFORE PROGRAMMING THE BOARD • The segments on the display corresponding to STOP, PRESSURE SAFETY DEVICE and PHOTOCELLS must be lit. These input contacts must be normally closed. (FIG.1) CLUTCH START/STOP CLOSING PHOTOCELLS LIMIT SWITCH PRESSURE OPENING SAFETY DEVICE LIMIT SWITCH...
  • Page 7 • Unlock the motor with the emergency release system and move the gate until complete opening and complete closing to verify if the limit switches are installed correctly. At each limit switch correspond one segment on the display (FIG.1). • Before to start programming bring the gate in closing and lock again the motor (FIG.4) - 7 -...
  • Page 8 Programming the work time 1. Power the control board. 2. Memorize the remote as parameter C1 page 16 3. Press P1 and P2 simultaneously for three seconds to begin programming the board. 4. Letter A appear on the display. 5. Press P2 to confirm. 6.
  • Page 9 Setting the torque and lagging PARAMETER T1 - Torque setting for normal working phase Values goes from 0 to 9 0 = maximum torque 9 = minimum torque 1. Press P1 and P2 simultaneously for three seconds to begin programming the board. 2.
  • Page 10 PARAMETER T3 – Extra time Display Seconds Values goes from 0 to 9 0 = 1 second of extra time 9 = 5,5 secons of extra time 1. Press P1 and P2 simultaneously for three seconds to begin programming the board. 2.
  • Page 11 Setting of secondary parameters (not necessary for a standard installation) PARAMETER T4 - Automatic closure of the gate from photocell impulse Display Seconds Values goes from 0 to 9 0 = function OFF 9 = closure after 27 seconds from the impulse 1.
  • Page 12 PARAMETER T5 - Timing for automatic closure Display Seconds Values goes from 0 to 9 0 = function OFF 9 = closure after 240 seconds 1. Press P1 and P2 simultaneously for three seconds to begin programming the board. 2. Letter A appear on the display. Scroll the menu with P1 until letter T appears on the display.
  • Page 13 PARAMETER T6 - Timing for courtesy light Display Seconds Values goes from 0 to 9 open gate pilot light 0 = open gate pilot light 9 = switching off after 4,5 minutes 1. Press P1 and P2 simultaneously for three seconds to begin programming the board.
  • Page 14 PARAMETER T7 - Timing for pedestrian opening Display Seconds Values goes from 0 to 9 0 = function OFF 9 = opening of 18 seconds 1. Press P1 and P2 simultaneously for three seconds to begin programming the board. 2. Letter A appear on the display. Scroll the menu with P1 until letter T appears on the display.
  • Page 15 PARAMETER T8 - Motor brake Display Milliseconds The motor brake it is used to stop the movement of the gate after the intervention of a Stop command or limit switch command. Value goes from 0 to 9 0 = brake OFF 1 = braking of 30ms 9 = braking of 270ms 1.
  • Page 16 Setting the remote control codes If using dipswitches remote controls before learning them on the control board, please set a personal code with the dipswitches positioned inside the remote control. During the learning of the remote controls we advice to disconnect the antenna and do not employ too much time to send the code of the remote control, specially in urban areas where there are many radio disturbs.
  • Page 17 Parameter C3: pedestrian opening code 1. Press P1 and P2 simultaneously for three seconds to begin programming the board. 2. Letter A appear on the display. Scroll the menu with P1 until letter C appears on the display. Press P2 to confirm. 3.
  • Page 18 Parameter C5: erasing of all remote control codes 1. Press P1 and P2 simultaneously for three seconds to begin programming the board. 2. Letter A appear on the display. Scroll the menu with P1 until letter C appears on the display. Press P2 to confirm.
  • Page 19 Additional features The additional features are not necessary for normal operations, but they are very useful in case of parti- cular installations. Parameter F1: display clutch status (ON/OFF) This parameter is used to check if the clutch has been detected or not, during the setting of the work time. 1.
  • Page 20 Parameter F2: pre-blinking It is possible to enable or disable the pre-blinking in the opening and closing phase following the instruc- tion listed below. Values goes from 0 to 1 0 = pre-blinking OFF 1= pre-blinking ON 1. Press P1 and P2 simultaneously for three seconds to begin programming the board.
  • Page 21 Parameter F4: transform pressure safety device contact in second photocell contact This function transform the costa (PSD) contact in a second contact for photocells enabled also during the opening phase.This option can be used when installing two pairs of photocells, one pair working only during the closing phase and the second pair working during the closing and the opening phase.Furthermore during closure if there is an obstacle between the second pair of photocells the control board will stop the gate and then reverse the movement only when the obstacle is removed.
  • Page 22 Parameter F6: reset of the control board This function will reset all parameters to default settings without deleting the remote controls codes. 1. Press P1 and P2 simultaneously for three seconds to begin programming the board. 2. Letter A appear on the display. Scroll the menu with P1 until letter F appears on the display.
  • Page 23 WARNINGS!!! OUR COMPANY, AS MANUFACTURER, CAN NOT BE HELD RESPONSIBLE FOR DAMAGES DUE TO WRONG OR MISSING CONN ECTIONS OR DUE TO AN IMPROPER SETTING. THE SAFETY DEVICES SHOULD BE ALWAYS INSTALLED AND KEPT IN FULL WORKING ORDER. ONCE TERMINATED THE SYSTEM SETTING, YOU SHOULD PLACE BACK THE CONTAINER ON ITS POSITION, FASTENING TIGHT ITS SCREWS.
  • Page 24 BAME s.r.l. - Via L. da Vinci, 23 - 46020 SAN GIACOMO SEGNATE (MN) - ITALY Tel. +39 0376 616 638 - Fax +39 0376 629 456 - http://www.bame.it - http://www.delma.it Unità locale: Via Enrico Berlinguer, 6 - 63844 GROTTAZZOLINA (FM) - ITALY...
