Benthin RR36 Electrical Installation

Electrical Installation
WARNING
Installation work in the 230 V range must only
be carried out by authorised specialists.
The motor may only be
230 V 24 V
Trans-
supplied by extra-low
former
voltage safety power supplies.
Detailed information you can get from your specialist dealer
on inquiry.

Maintenance

The motor system is maintenance-free.

Connecting example

Single control
with switch with integrated power pack
24 V DC
D
2 × 0,75²
Power
supply
230 V / 50 Hz
Switch
Conduit
Abzw.-
box
Dose
L1
N
PE
Power supply
Netz
230 V / 50 Hz
Connecting example
Single control
with wireless wall transmitter or wireless hand transmitter
1-channel wireless
hand transmitter
Telis 1 RTS
5-channel wireless
hand transmitter
Telis 4 RTS
Motor
Antrieb
SOMFY
1
M
Wireless receiver
Funkempfänger
2
Modul DC RTS
Modul DC RTS
Switch with integrated
Schalternetzteil
power pack
230 V / 24 V DC / 0,7 A
M
L N +(-) -(+)
M
Antrieb Motor
. Misprints, errors and changes excepted . Version 02-09-2013 . 97000208
®
© 2013 Benthin
Wireless receiver
D
2 × 0,75²
Transformer
Power supply
230 V / 50 Hz
Wireless
Wireless
program time control
wall transmitter
Centralis RTS Chronis RTS
Power supply
Netz
230 V / 50 Hz
L1 N PE
Conduit Abzw.-
Dose box
rt
red
+
Transformer
Transformator
black sw
- 230 V / 24 V
2
2 x 0,5
Electrical Installation
Roman blind type RR36
(24 V Motor)
Dear Customer,
With this motorised roman blind system you have chosen a system that
offers innovation, high quality, and comfort, with remote control and
switch/push button options available to guarantee your satisfaction system
Your roman blind Manufacturer
Please read this intructions carefully
before fitting the blind
Installation work in the 230 V range
must only be carried out by authorized specialist.
Wrong installation may result in accidents.
Alterations of the blind must be approved by the blind manufacturer.
Keep remote controls out of the reach of children!
