HunterDouglas Luxalon 84B Installation Instructions

Linear ceiling

Advertisement

Cut-outs
GB
NL
Paneelbewerking
F
Découpes
D
Ausschnitte
E
Recortes
GB

Demounting

NL
Demontage
F
Démontage
D
Demontage
E
Desmontaje
GB
While demounting the panel make sure to support the part of the panel that has already been removed from the carriers.
NL
Ondersteun het deel van het paneel dat reeds uit de draagprofielen verwijderd is.
F
Lorsque vous démontez la lame, veillez à maintenir le côté déjà démonté.
D
Stellen Sie während der Demontage sicher, dass der bereits von der Tragschiene abmontierte Teil des Paneels abge-
stützt wird.
E
Al desmontar el panel asegurase que el operario siempre tiene sujeta la parte ya desmontada.

Maintenance

GB
NL
Onderhoud
F
Entretien
D
Instandheltung
E
Mantenimiente
Luxalon® Ceilings are, by utilising high quality materials and extensively tested coatings, easy to maintain. When cleaning
GB
is required, it is advised to use a slightly damp, non-linting and non-abrasive cloth. A mild neutral (pH=7) cleaning
agent may be used if necessary. Never use aggressive cleaning agents since they will cause damage to the panels. Before
cleaning the ceiling always try the chosen method of cleaning on a non-visible part of the panel.
Ventilation
When using a Luxalon® Ceiling in rooms with higher humidity levels it is important always to use aluminium panels and
carriers and to ensure that the rooms are ventilated properly.
Een Luxalon® Plafond is, door gebruik van kwalitatief hoogwaardige materialen en grondig geteste lakken, onderhouds-
NL
arm. Indien schoonmaken noodzakelijk is adviseren wij om het plafond te reinigen met een vochtige, niet pluizende en niet
krassende doek en eventueel een eenvoudig, niet bijtend (pH=7) schoonmaakmiddel te gebruiken. Het is schadelijk het
plafond bloot te stellen aan agressieve schoonmaakmiddelen. Probeer het schoonmaakmiddel uit op een niet zichtbaar
deel van de panelen.
Ventilatie
Bij toepassing van een Luxalon® Plafond in een vochtige ruimte is het van belang altijd aluminium panelen en draagpro-
fielen te gebruiken en dat de ruimte goed geventileerd wordt.
Les plafonds Luxalon®, du fait de la qualité des matériaux et de leur revêtement, sont d'un entretien très facile. Lorsqu'il y
F
a lieu de les nettoyer, il est conseillé d'utiliser un chiffon doux légèrement humide.
Un nettoyant neutre (pH=7) peut être utilisé si cela s'avère nécessaire. N'utilisez jamais un détergent aggressif qui en-
dommagerait la lame. Commencez toujours par nettoyer une partie non visible de la lame.
Aération
Lorsque vous utilisez un plafond Luxalon® dans une pièce à fort degré d'humidité, il est important de toujours choisir des
lames et porteurs en aluminium et d'assurer une bonne ventilation de la pièce.
Luxalon® Decken sind durch Verwendung von hochwertigem Material und umfassend getesteter Farbbeschichtung einfach
D
zu warten. Falls eine Reinigung notwendig sein sollte, benutzen Sie ein leicht feuchtes, nicht staubendes und schleiffreies
84B-Multipanel
Leinentuch. Ein mildes (pH=7) Reinigungsmittel kann bei Bedarf benutzt werden. Nehmen Sie nie aggressive Reinigungs-
mittel, da diese Schäden auf den Paneelen verursachen. Bevor Sie die Paneele reinigen, probieren Sie die ausgewählte
Reinigungsmethode an einer nicht sichtbaren Stelle.
Belüftung / Feuchträume
Wenn Sie eine Luxalon® Decke in Räumen mit hohem Feuchtigkeitsniveau verwenden, ist es wichtig immer Aluminium –
84C
Paneele und – Tragschienen zu benutzen. Zudem ist eine gute Durchlüftung der Räume notwendig.
Debido a la calidad de los techos Luxalon®, el mantenimiento debe centrarse en la limpieza. Para la limpieza, se debe
E
utilizar únicamente un trapo húmedo. Si fuera necesario, también puede utilizarse un producto de limpieza suave y neutro
(ph=7). Nunca utilice productos de limpieza agresivos ni elementos tipo gasa. Antes de limpiar el techo, se aconseja que
hagan pruebas en alguna zona menos visible.
84R
Ventilación
En zonas de alto nivel de humedad, los paneles y los soportes deben ser de aluminio. Es muy aconsejable que la habita-
ción tenga una buena ventilación.
30-80-130BXD
www.hunterdouglascontract.com
Luxalon
®
Linear Ceiling 84B-84C-84R-Multipanel
GB
Installation instruction
We have endeavoured to design these instructions to assist a trained ceiling professional with the mounting and installation of a
Luxalon® exterior ceiling. We accept no responsibility for poor workmanship, failure to comply with these instructions, improper
installation or installation by someone other than a trained ceiling professional.
NL
Montage handleiding
Deze montage dient ter ondersteuning van ervaren plafond installateurs bij de montage en inbouw van een Luxalon® buitenplafond.
Wij accepteren geen verantwoordelijkheid voor schade ten gevolge van onvakkundige montage, het niet opvolgen van de montage
handleiding of montagefouten veroorzaakt door onvoldoende gekwalificeerd personeel.
F
Instructions de montage
Nous avons concu ces instructions afin d'assister un professionnel de plafond au montage et à l'installation d'un plafond extérieur
de Luxalon®. Nous n'acceptons aucune responsabilité d'une manque de compétence, d'une négligence de répondre à ces
instructions, d'une installation impropre ou d'une installation par quelqu'un d'autre qu'un professionnel de plafond.
D
Montageanleitung
Mit dieser Anleitung sind wir bestrebt, Decken-Fachpersonal beim Einbau und der Montage der Luxalon® Außendecke zu unterstützen.
Wir übernehmen keine Verantwortung für Ausführungsmängel, die Nichteinhaltung der Montage-anleitung, unsachgemäße Montage
bzw. Montagefehler durch den Einsatz von nicht ausreichend qualifizierten Fachpersonal.
E
Instrucciones de Montaje
Instrucciones de montaje de un techo exterior de Luxalon®, de obligado cumplimiento para su correcta instalación. No se
considerará ninguna reclamación como consecuencia de la falta de seguimiento de las instrucciones indicadas, o de la falta de
calidad en el montaje.
revision 3
Multipanel
84B - 84C
84R
