Front And Rear Panel Diagrams - Adcom High-Current Power Amplifier GFA-555se Owner's Manual

REAR PANEL
FRONT PANEL
model GFA-555se
power
( 7 ) ( 8 )
(1) Inputs (unbalanced)
(2) Inputs (balanced)
(3) Output Binding Posts
(4) AC Fuse
(5) AC Power Cord
( 1 )
( 2 )
( 3 )
( 4 )
high current power amplifier
instantaneous distortion alert
L
(6) Mode Switches
(7) On/Off Switch
(8) Power LED
(9) Thermal Protection LED
(10) Distortion Alert LEDs
9
( 1 )
( 2 )
( 6 )
( 5 )
thermal protection
R
channel
( 10 ) ( 9 )
