FLEXCOMM II
This manual contains information pertaining to the installation of the C-5000 Communication Management
Controller with FLEXCOMM II and FLEXCOMM I. FLEXCOMM II consists of the RT-5000 Transceiver, appropriate
antennas, and optional equipment as required. FLEXCOMM I consists of the RT-9600 Transceiver, RT-9600F
Transceiver, RT-7200 Transceiver, and optional combinations of up to three of the following FLEXCOMM
Transceivers: RT-30, RT-118, RT-138(F), RT-406F, RT-450, appropriate antennas, and optional equipment as
required. The C-5000 can also interface with combined applications of FLEXCOMM II and FLEXCOMM I, i.e., a
hybrid RT System configuration that consists of both RT-5000 and FLEXCOMM I Transceivers.
1. Components
The following components can be installed:
A. Communication Management Controller
C-5000 PN 31300-0X01-XXXX (See Figure 1-1)
B. FLEXCOMM II
(1) Transceivers
RT-5000
(2) Antennas Systems (Refer to Table 1-2)
AT-560
AT-160
AT-5000
AT-550
AT-150
AT-50
AT-51
AT-140
AT-400
FC-50 Logic Converter
150-1355-000 Rev. K
The document reference is online, please check the correspondence between the online documentation and the printed version.
Installation Manual
SECTION 1 - INTRODUCTION
IMPORTANT
PN 400-015525-XXXX (See Table 1-1)
PN 121-040130-XX
PN 121-040129-XX
PN 121-040045-XX
PN 121-017850-01
PN 153-017822-01
PN 121-016587-01
PN 121-016796-01
PN 121-016584-01
PN 121-16821-01
PN 153-016586-01
CONFIDENTIAL AND PROPRIETARY TO COBHAM
C-5000 (Non-Digital)
Page 12
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for COBHAM Flexcomm I
Summary of Contents for COBHAM Flexcomm I
- Page 1 Transceivers: RT-30, RT-118, RT-138(F), RT-406F, RT-450, appropriate antennas, and optional equipment as required. The C-5000 can also interface with combined applications of FLEXCOMM II and FLEXCOMM I, i.e., a hybrid RT System configuration that consists of both RT-5000 and FLEXCOMM I Transceivers.
- Page 2 PN 121-0002-000 AT-461 PN 121-0011-000 AT-462 PN 121-014378-01 AT-695 PN 121-0019-000 AT-960 PN 121-0010-000 150-1355-000 Rev. K CONFIDENTIAL AND PROPRIETARY TO COBHAM Page 13 The document reference is online, please check the correspondence between the online documentation and the printed version.
- Page 3 FLEXCOMM II C-5000 (Non-Digital) Installation Manual Note: Refer to the following for information on FLEXCOMM I antennas and installation: FLEXCOMM I Installation Manual, WED Manual No. 150-040011- 000, for information on FLEXCOMM Antennas. WED Manual No. 150-0061-000 for information on RT-9600 and RT-7200 Antennas.
- Page 4 153-017851 FC-550 Logic Converter 146-016958-01 Gasket, AT-400 146-014960-01 Gasket, AT-51 146-014959-01 Gasket, AT-50 150-1355-000 Rev. K CONFIDENTIAL AND PROPRIETARY TO COBHAM Page 15 The document reference is online, please check the correspondence between the online documentation and the printed version.
- Page 5 Transceiver, FLEXCOMM Hi Band VHF, 138.0000 - 173.9975 MHz, with increased sensitivity (precludes Guard). 150-1355-000 Rev. K CONFIDENTIAL AND PROPRIETARY TO COBHAM Page 16 The document reference is online, please check the correspondence between the online documentation and the printed version.
- Page 6 138F units are compatible with Digital Coded Squelch Systems (Motorola Digital Private Line and GE Digital Channel Guard). 150-1355-000 Rev. K CONFIDENTIAL AND PROPRIETARY TO COBHAM Page 17 The document reference is online, please check the correspondence between the online documentation and the printed version.
- Page 7 Transceiver, FLEXCOMM UHF Band, 450.0000 - 469.9875 MHz, with increased sensitivity (precludes Guard). 150-1355-000 Rev. K CONFIDENTIAL AND PROPRIETARY TO COBHAM Page 18 The document reference is online, please check the correspondence between the online documentation and the printed version.
- Page 8 Transceiver, RT-9600 VHF HI-Band, 150.0000 - 173.995 MHz, 14/28 VDC, 100 mW Audio, Recessed Connector, with Guard Receiver and CTCSS Tones 150-1355-000 Rev. K CONFIDENTIAL AND PROPRIETARY TO COBHAM Page 19 The document reference is online, please check the correspondence between the online documentation and the printed version.
- Page 9 100 mW Audio, Recessed Connector, with Guard Receiver, and Voice Encryption interface compatible continues…... 150-1355-000 Rev. K CONFIDENTIAL AND PROPRIETARY TO COBHAM Page 20 The document reference is online, please check the correspondence between the online documentation and the printed version.
- Page 10 9600F units are compatible with Digital Coded Squelch Systems (Motorola Digital Private Line and GE Digital Channel Guard). 150-1355-000 Rev. K CONFIDENTIAL AND PROPRIETARY TO COBHAM Page 21 The document reference is online, please check the correspondence between the online documentation and the printed version.
- Page 11 300-316835 Shock Mounts Shock Mounts, RT-5000, Vertical or 246-044540-01 Horizontal Tray (Recommended) continues…... 150-1355-000 Rev. K CONFIDENTIAL AND PROPRIETARY TO COBHAM Page 22 The document reference is online, please check the correspondence between the online documentation and the printed version.
- Page 12 RG-142 coax) 129-049113-01 N Type (Plug, 90 degree) for use with RG-142 coax) continues…... 150-1355-000 Rev. K CONFIDENTIAL AND PROPRIETARY TO COBHAM Page 23 The document reference is online, please check the correspondence between the online documentation and the printed version.
- Page 13 Kit includes: Software RP_Win Software for Windows 404-041382 Cable RP Cloning Cable 246-042755-01 continues…... 150-1355-000 Rev. K CONFIDENTIAL AND PROPRIETARY TO COBHAM Page 24 The document reference is online, please check the correspondence between the online documentation and the printed version.
- Page 14 FLEXCOMM II C-5000 (Non-Digital) Installation Manual Table 1-12: Connectors Used (cont’d) Item Designator Description Wulfsberg P/N Mil Spec P/N Flexcomm I System converting to Flexcomm II System Special Adapters Adapter Cable Harness/Transceiver/Antenn 153-041054 a Tuner Adapter Cable C-5000 Parallel to Serial...
- Page 15 Maintenance of the FLEXCOMM II (Non-Digital) Transceiver is ‘on condition’ only. Periodic maintenance of this product is not required. 150-1355-000 Rev. K CONFIDENTIAL AND PROPRIETARY TO COBHAM Page 26 The document reference is online, please check the correspondence between the online documentation and the printed version.
