- Page 1 ® WALLACE & TIERNAN SENSOR MEASURING MODULES AND RETROFIT KITS FOR MFC INSTALLATION MANUAL...
- Page 2 Sensor measuring modules for MFC WT.050.580.001.DE.IM.0714...
-
Page 3: Table Of Contents
Sensor measuring modules for MFC Contents Contents Introduction Documentation 1.1.1 Target groups Conventions General safety instructions Intended use Description Version 3.1.1 Sensor measuring modules 3.1.2 Plug in cards for retrofit kits Description 3.2.1 General Installation Opening the housing Installing and wiring plug-in card 1 to 7 Installing IR board Connecting the sensor cable Inserting and connecting the sensors... - Page 4 Sensor measuring modules for MFC Contents WT.050.580.001.DE.IM.0714...
-
Page 5: Introduction
Sensor measuring modules for MFC Introduction 1. Introduction Documentation 1.1.1 Target groups This documentation provides installation and maintenancepersonnel with the information needed to install and retrofit the unit. All persons working with the sensor measuring module and retrofit kits must have read and understood the instruction manual, particularly the safety instructions. - Page 6 Sensor measuring modules for MFC Introduction Icon Note Signification Please note These notes facilitate work with the unit. WT.050.580.001.DE.IM.0714...
-
Page 7: General Safety Instructions
Sensor measuring modules for MFC General safety instructions 2. General safety instructions Intended use The sensor measuring modules and retrofit kits are designed to be installed in the MFC control unit. The operational safety of the sensor measuring modules and retrofit kits can onlybe guaranteed so long as they are used strictly as intended. - Page 8 "Authorized specialists" refers to trained technicians of the operator, Evoqua Water Technologies GmbH and, if applicable, the service partner. Only qualified electricians may perform work on electrical components.
-
Page 9: Description
Sensor measuring modules for MFC Description 3. Description Due to the MFC's modular design, simple retrofitting and configuration of sensor measuring modules in accordance with the plug-and-play principle is possible at any time. Different versions are available. Version 3.1.1 Sensor measuring modules W3T170339 Total chlorine TC1 W3T170341... -
Page 10: Description
Sensor measuring modules for MFC Description Description 3.2.1 General A Sensor cable B Housing duct C Sensor D Plug-in card Sensor measuring module The sensor measuring module consists of: • Sensor (C) (not in 3 electrode cells, mA/V input) • Sensor cable (A) with watertight housing cable duct (B) (not in 3 electrode cells, mA/V input) - Page 11 Sensor measuring modules for MFC Description In principle, the following sensor measuring module types or retrofit kits can be installed in module slots 1 to 4: ® for DEPOLOX 5 flow block assembly ® for DEPOLOX 4 flow block assembly with PT100 temperature option for membrane sensors: free chlorine FCI, chlorine dioxide (CD7), ozone (OZ7), total chlorine...
- Page 12 Sensor measuring modules for MFC Description Module slot 6 As an option, module slot 6 can be equipped with a four-way mA (MOD 6) output card. Each mA output can be optionally assigned with a measured value or also with a controller control signal (Ym feedback / Yout).
-
Page 13: Installation
Sensor measuring modules for MFC Installation 4. Installation Opening the housing 1 Remove the housing cover of the flow block assembly by pressing the two buttons on the top of the housing. Please note (Not required for retrofitt kits without sensors) 2 Release the five screws on the cover of the electronic module. - Page 14 Sensor measuring modules for MFC Installation Arrangement of Example using the combination chlorine/pH/conductivity/Cl-N the plug-in cards and cables A B C D E F A mA-out plug-in card (mod 6) B mA/V input plug-in card (mod 5) C CI-N plug-in card (mod 4) D Conductivity plug-in card (mod 3) E pH plug-in card (mod 2) F Cl...
-
Page 15: Installing And Wiring Plug-In Card 1 To
Sensor measuring modules for MFC Installation Installing and wiring plug-in card 1 to 7 1 Remove the slot's dummy cover. Save for later use! 2 Insert and screw in the plug-in card. 3 If necessary, wire the sensor cable terminal strip and insert into the plug-in card. - Page 16 Sensor measuring modules for MFC Installation "DES" module for membrane Terminal assignment: sensors TC1, FC1, CD7, OZ7 1: Red 2: White 3: Blue Shield: Black Depending on the module slot, the included plug must be used for connection on the left or right side. "mS"...
- Page 17 Sensor measuring modules for MFC Installation "mA out" module for • All mA outputs can be assigned as desired: installation as mod 6 , pH, Redox, Cl-N, conductivity, temperature, Ym/Yout (See Instruction Manual „MFC” under "Input/Output" - "Analog Output 1/2 or 3/4" Menu 1.5.) •...
-
Page 18: Installing Ir Board
Sensor measuring modules for MFC Installation Installing IR board Please note IR boards can be operated with all MFC firmware versions. A Slot for IR module View inside the housing with IR board B Nut C IR board D Housing slot WT.050.580.001.DE.IM.0714... -
Page 19: Connecting The Sensor Cable
Sensor measuring modules for MFC Installation C IR board D Housing slot E Screw Pin contact strip G Plug H Spacing bolt IR window 1 To simplify installation of the IR board (C), first remove the plug (G) and insert the IR board into the housing slot (D) below the IR window (I). -
Page 20: Inserting And Connecting The Sensors
Measurement Inputs in the Instruction Manual „MFC”. Observe the max. back pressure (pressurized version). Please consult the membrane sensor data sheet for this figure. You can request this figure from Evoqua Water Technologies GmbH or locate it in the Instruction Manual „MFC”. Arrangement of the sensors ®... - Page 21 The life of the battery is approx. 5 years; the impedance converter should be sent to Evoqua Water Technologies GmbH for battery replacement. Please note The respective installation accessories must be used if installing the pressurized conductivity electrode and membrane sensors.
-
Page 22: Mounting The Housing Covers
Sensor measuring modules for MFC Installation Mounting the housing covers 1 Ensure that the cable bushes are fitted correctly. 2 Carefully place the electronic module cover. Make sure that the sensor cables are in the cable conduits. Fasten with five housing screws. 3 Carefully place the housing cover onto the flow block assembly and snap into place. -
Page 23: Firmware Update
The MFC firmware can always be updated to the latest version via the RS232 interface. A special downloading pages is available on the Internet: Internet: www.evoqua.com => Download => Firmware => MFC - DEPOLOX 5 or at: Evoqua Water Technologies GmbH, Auf der Weide 10, D-89312 Günzburg, +49 (0)8221-9040... -
Page 24: Lap Download Description
Sensor measuring modules for MFC Installation 4.8.1 lAP download description Connection: • Switch off the MFC mains voltage. • Connect the PC to the MFC using the interface cable W3T164565 Set up the connection cable as described below: Connection: RS232 Terminal MFC 9-pin D-Sub (PC/Laptop) TxD13 ------------------------------>Pin 2 RxD... - Page 25 Sensor measuring modules for MFC Installation 4 Next Click Next and the software automatically searches for a device on an RS232 interface. All available interfaces are searched on the PC. Connected devices are displayed with name, software version and software number, such as Depolox Pool 01.03 EAE1022 MFC 01.00...
- Page 26 Sensor measuring modules for MFC Installation WT.050.580.001.DE.IM.0714...
-
Page 27: Wiring Diagram
03.08.05 Date 03.08.05 Design Center LAE4321 18.07.08 Drawn Prod. / Sales LAE4703 08.10.09 Date Date LAE5900.010 13.05.14 Checked release Issue Revision Date Name Norm Urspr. Ers. f. Ers. d. Project Evoqua Water Technologies GmbH order number Drawing number Sheet 8673... - Page 28 Date 03.08.05 Design Center LAE4321 18.07.08 Drawn Prod. / Sales LAE4703 08.10.09 Date Date LAE5900.010 13.05.14 Checked release Issue Revision Date Name Norm Urspr. Ers. f. Ers. d. Project Evoqua Water Technologies GmbH order number Drawing number Sheet 8673 WT.050.580.001.DE.IM.0714...
- Page 29 03.08.05 Date 03.08.05 Design Center LAE4321 18.07.08 Drawn Prod. / Sales LAE4703 08.10.09 Date Date LAE5900.010 13.05.14 Checked release Issue Revision Date Name Norm Urspr. Ers. f. Ers. d. Project Evoqua Water Technologies GmbH order number Drawing number Sheet 8673...
- Page 30 Date 03.08.05 Design Center LAE4321 18.07.08 Drawn Prod. / Sales LAE4703 08.10.09 Date Date LAE5900.010 13.05.14 Checked release Issue Revision Date Name Norm Urspr. Ers. f. Ers. d. Project Evoqua Water Technologies GmbH order number Drawing number Sheet 8673 WT.050.580.001.DE.IM.0714...
- Page 31 03.08.05 Date 03.08.05 Design Center LAE4321 18.07.08 Drawn Prod. / Sales LAE4703 08.10.09 Date Date LAE5900.010 13.05.14 Checked release Issue Revision Date Name Norm Urspr. Ers. f. Ers. d. Project Evoqua Water Technologies GmbH order number Drawing number Sheet 8673...
- Page 32 Date 03.08.05 Design Center LAE4321 18.07.08 Drawn Prod. / Sales LAE4703 08.10.09 Date Date LAE5900.010 13.05.14 Checked release Issue Revision Date Name Norm Urspr. Ers. f. Ers. d. Project Evoqua Water Technologies GmbH order number Drawing number Sheet 8673 WT.050.580.001.DE.IM.0714...
- Page 33 03.08.05 Date 03.08.05 Design Center LAE4321 18.07.08 Drawn Prod. / Sales LAE4703 08.10.09 Date Date LAE5900.010 13.05.14 Checked release Issue Revision Date Name Norm Urspr. Ers. f. Ers. d. Project Evoqua Water Technologies GmbH order number Drawing number Sheet 8673...
- Page 34 Date 03.08.05 Design Center LAE4321 18.07.08 Drawn Prod. / Sales LAE4703 08.10.09 Date Date LAE5900.010 13.05.14 Checked release Issue Revision Date Name Norm Urspr. Ers. f. Ers. d. Project Evoqua Water Technologies GmbH order number Drawing number Sheet 8673 WT.050.580.001.DE.IM.0714...
-
Page 35: Index
Sensor measuring modules for MFC Index 6. Index Arrangement of the cables 14 Module "DES" module 15 "DES" module for membrane sensors 16 "F-" module 15 "mA out" module 17 Cable extension 21 "mA/V" module as mod 1 – 4 16 Connecting sensors 20 "mA/V"... - Page 36 Sensor measuring modules for MFC Index WT.050.580.001.DE.IM.0714...
- Page 37 Sensor measuring modules for MFC...
- Page 38 All information presented herein is believed reliable and in accordance with accepted engineering practices. Evoqua makes no warranties as to the completeness of this information. Users are responsible for evaluating individual product suitability for specific applications. Evoqua assumes no liability whatsoever for any special, indirect or consequential damages arising from the sale, resale or misuse of its products.
