The materials are reusable according to their markings. By reusing, recycling or
other forms of utilization of old devices you make an important contribution to
the protection of our environment.
Please contact your local authorities for details about collection points.
Risk of electric shock
Caution: To reduce the risk of electric shock, do n ot remove the
cover (or back). There are no user serviceable part s inside. Refer
servicing to qualified service personnel.
Safety, Environmental and Setup Instructions
Use the device in dry indoor environments only.
Protect the device from humidity.
Do not open the device. RISK OF ELECTRIC SHOCK! Refer opening and servicing to qualified personnel.
Connect this device to a properly installed and earthed wall outlet only. Make sure the mains voltage corresponds with
the specifications on the rating plate.
Make sure the mains cable stays dry during operation. Do not pinch or damage the mains cable in any way.
A damaged mains cable or plug must immediately be replaced by an authorized service center.
In case of lightning, immediately disconnect the device from the mains supply.
Children should be supervised by parents when using the device.
Clean the device with a dry cloth only.
Do NOT use CLEANING AGENTS or ABRASIVE CLOTHS!
Do not expose the device to direct sunlight or other heat sources.
Install the device at a location with sufficient ventilation in order to prevent heat accumulation.
Do not cover the ventilation openings!
Install the device at a safe and vibration-free location.
Install the device as far away as possible from computers and microwave units; otherwise radio reception may be
disturbed.
Do not open or repair the enclosure. It is not safe to do so and will void your warranty. Repairs only by authorized
service/ customer center.
Only use mercury and cadmium-free batteries.
Used batteries are hazardous waste and NOT to be disposed of with the household waste!!!
Return the batteries to your dealer or to collection points in your community.
Keep batteries away from children. Children might swallow batteries.
Contact a physician immediately if a battery was swallowed.
Check your batteries regularly to avoid battery leakage.
Batteries shall not be exposed to excessive heat such as sunshine, fire or the like.
CAUTION: Danger of explosion if battery is incorrectly replaced
Replace only with the same or equivalent type
ENVIRONMENTAL PROTECTION
Do not dispose of this product with the normal household waste at the end
of its life cycle. Return it to a collection point for the recycling of electrical
and electronic devices. This is indicated by the symbol on the product,
user manual or packaging.
WARNING
Do not open!
This symbol indicates the presence of dangerous
voltage inside the enclosure, sufficient enough to
cause electric shock.
This symbol indicates the presence of important
operating and maintenance instructions for the
device.
EN 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IR4000DAB and is the answer not in the manual?

Questions and answers

Summary of Contents for SOUNDMASTER IR4000DAB

  • Page 1 ENVIRONMENTAL PROTECTION Do not dispose of this product with the normal household waste at the end of its life cycle. Return it to a collection point for the recycling of electrical and electronic devices. This is indicated by the symbol on the product, user manual or packaging.
  • Page 2: Table Of Contents

    IR4000DAB / English Instruction Manual Contents Ⅰ Features/Technical Specifications……………………………………………3 Ⅱ Ma i n K e y s …… …………… ……………… ……………… ……………… ……3 Ⅲ Overall Menu Diagram……………………………………………………………4-5 IV Swich ON or Switch off………………………………………………………………5 V O p er a t i o ns ……………………………………………………………………5 -9 1 .
  • Page 3: Ⅰ Features/Technical Specifications

    IR4000DAB / English Instruction Manual I Features/Technical Specifications ◆Available for global stations by internet ◆Compatible with the audio of WMA/MP3/OGG ◆Support the digital Radio of DAB/DAB+ (BAND -13F) and the FM Radio Ⅲ ◆With 240*320 RGB TFT screen ◆With the adapter of DC 5.5V 2000mA and build-in battery of 2000mA/HR ◆Access to available Wi-Fi Internet...
  • Page 4: Ⅲ Overall Menu Diagram

    IR4000DAB / English Instruction Manual Wireless Network Configuration Wireless Network(WPS PBC) III. Overall Manu Diagram Manual Configuration Check Network when Power on Manage my media Set Date and Time Network > Set Time Formart Set Date Formart Date & Time >...
  • Page 5 IR4000DAB / English Instruction Manual Ⅳ Switch ON or OFF Plug the adapter into the hole of DC IN(on the back of the product) and press the ‘ON/OFF’ switch to ‘ON’, then the logo ‘Welcome’ will be shown on the screen, meanwhile, the radio will scan the available Internet automatically.
  • Page 6: Internet Radio

    IR4000DAB / English Instruction Manual 2 DAB Press MENU→press LEFT or RIGHT button to choose DAB/DAB+ →press SELECT to enter the interface of DAB/DAB+(It will search the DAB/DAB+ stations automatically. After search, it will show the names and numbers of the searched stations)→ press to choose station→press SELECT to enter the station.
  • Page 7: Media Center

    IR4000DAB / English Instruction Manual 5 Media Center 5.1 USB Functions: Play the audio medium by USB , which is compatible with the files of WMA/MP3/AAC/AAC+/ FLAC/WAV. Steps: Press MENU→press LEFT or RIGHT button to choose ‘Media Center’→press SELECT to enter the interface →choose ‘USB’...
  • Page 8: Local Radio

    IR4000DAB / English Instruction Manual 6. Local Radio Fuctions: To setup the list or menu of Local Radio Steps: Press MENU→press LEFT or RIGHT button to choose ‘Local Radio’→press SELECT to enter the interface →choose ‘the station of local radio’ by →enter it by SELECT.
  • Page 9: Financial Information

    IR4000DAB / English Instruction Manual time’ and the present weather will be shown by turns in every 10 seconds. Or You can press SELECT to do the switch quickly. ●Above should be with available internet. 8.2 Financial Information Tips: On the interface of ‘Financial Information’, you can aim at your interested items...
  • Page 10: Alarm

    IR4000DAB / English Instruction Manual Fuctions: When ‘Power On’, choose ‘Enable’ to check the status of network link automatically; choose ‘Disable’ not to check it. Tips: If the network is not linked on the model of ‘Enable’, it will automatically show the choices for you to set up the network.
  • Page 11: Language

    IR4000DAB / English Instruction Manual Turn off 4.1.1 Repeat: To set up the Alarm Date The choices are as below: -Everyday -Thu -Once -Fri -Mon -Sat -Tue -Sun -Wed Tips: ●When choosing ‘everyday’, it will select the day from Mon. to Sun.
  • Page 12: 8.Buffer

    IR4000DAB / English Instruction Manual 8 Buffer Steps: Press MENU→Configuration→Buffer→SELECT to set up the buffer from 2 seconds to 8 seconds. 9 Weather Functions: To show the current weather of selected city on the model of Standby Steps: Press MENU→Configuration-> Weather->...
  • Page 13: Equaliser

    IR4000DAB / English Instruction Manual ‘Repeat all’, means to play all the items in your playlist repeatedly. 12.3 Repeat One ‘Repeat one’, means to play the chosen item repeatedly. 12.4 Shuffle ‘Shuffle’, means to play all the items in your playlist at random.
  • Page 14: Line Out

    IR4000DAB / English Instruction Manual Ⅶ Line out You can switch the radio’s medium onto other speakers by a 3.5mm audio line. Tips : By doing so, you can control the media volume only by other speakers Ⅷ Battery ●It’s with build-in battery of 2000mA/HR, which will be charged fully for 4 or 5 hours.
  • Page 15: Technical Data

    IR4000DAB / English Instruction Manual ⅩTechnical Data Input voltage ,current : 5.5V 2A Power consumption: max. 12W Radio Frequency range: FM (87.50MHz – 108.00MHz , 50KHz/step) DAB (Band III, 174.928MHz – 239.200MHz) Store temperature::-10 ~ +60 ℃ Operating temperature: +5 ~ +40 ℃...
