- Page 1 User Manual for model BC0530...
-
Page 2: Table Of Contents
Observe any caution or warning notices. They are limited. Use a commercial service company. Locate important and provide notice of potential hazards. one from the Scotsman website: www.Scotsman-ice. Keep this manual for future reference. Scotsman Ice Systems are designed and manufactured with the highest regard for safety and performance. -
Page 3: Specifications
2.5 gpm Storage Bins Voltage 115 volt models The ice machine will likely be too deep to fit properly on a typical ice storage bin. Scotsman B530 bins will • Maximum 126 VAC require attachment bracket that is included with the •... -
Page 4: Back View
BC0530 User Manual Back View Ø.875 ELECTRICAL INLETS (2X) 3/4" FPT POTABLE WATER INLET 29.8 27.8 EXIT OPENING FOR Ø3/4" ID FLEX TUBING DRAIN 5/16-18 FOR MOUNTING (2X) 17.8 Note: Model and serial dataplate on the back. March 2020 Page 4... -
Page 5: Plan And Cabinet Drawings
BC0530 User Manual Plan and Cabinet Drawings ICE DROP OPENING 12.6 AIRFLOW DIRECTION 25.8 30.7 CLEARANCE FOR AIRFLOW 33.7 LEFT FRONT RIGHT Note: Do NOT install on a bin where the ice drop opening is blocked. March 2020 Page 5... -
Page 6: Placement And Guidelines
Scotsman. • Do not install the equipment in wet areas. Scotsman reserves the right to make design changes • Do not locate the equipment near any heat and/or improvements at any time. source, in direct sunlight, in hot ambient areas, or Specifications and design are subject to change without proper clearance for ventilation. -
Page 7: Installation: Assembly
Attach the ice machine to the ice storage bin. The ice machine is supplied with an attachment bracket to fit Scotsman B330 and B530 ice storage bins. Make all plumbing and electrical connections to the ice machine and ice storage bin. See the next page. -
Page 8: Installation: Water
BC0530 User Manual Installation: Water Drain lines must be installed with a minimum drop of Connect Water Supply 2.5 cm per meter run (.3 inch drop per foot run). NOTE - Purge all water supply lines before connecting them to the ice machine. -
Page 9: Installation: Electrical
BC0530 User Manual Installation: Electrical All units are intended to be installed with a permanent Follow all local and national codes. connection to the field electrical supply. Drop Connect Electrical Supply Wires cord connections should never be used with this The unit has lead wires that are available at the back equipment. -
Page 10: Installation Check List
BC0530 User Manual Installation Check List ◊ Is the ice maker and bin assembly level? ◊ Is there proper clearance around the machine for air circulation? ◊ Have all electrical, water and sewer connections been made? ◊ Has the supply voltage been tested with the ice ma+er on a dedicated, protected circuit? ◊... -
Page 11: Initial Start Up
BC0530 User Manual Initial Start Up Remove front and right side panels. 2. Move the on-off switch to the “ON” position and observe the water flowing from the distributor Remove all shipping materials from the ice machine tube, filling the water tank. Also observe that including the water plate shipping strap. -
Page 12: Condenser Cleaning
BC0530 User Manual Condenser Cleaning The air cooled condenser will need regular 4. Vacuum the back of the condenser and / or blow maintenance. All air used to cool the ice machine from the inside to release any dirt. Imbedded flows through it, and eventually it will become grease will require the use of coil cleaner. -
Page 13: Cleaning Water System
1. Mix 3 oz. of Scotsman Clear 1 Scale Remover in a gallon of warm water. 13. Allow the solution to circulate for 15 minutes. -
Page 14: Component Location
BC0530 User Manual Component Location Water Plate Switch Control Stream Water Level Control Tube Water Plate Water Pump Water Fill Probe Controller March 2020 Page 14... -
Page 15: Help
BC0530 User Manual Help Before calling for service, check here for your issue. Problem: No ice, the machine is silent. • Be sure the unit has power. • Remove the front panel and check that the On/ Off switch is in the On or Ice position. -
Page 16: Wiring Diagram
BC0530 User Manual Wiring Diagram MODEL BC0530A-1A March 2020 Page 16... - Page 17 SCOTSMAN ICE SYSTEMS 101 Corporate Woods Parkway Vernon Hills, IL 60061 800-726-8762 www.scotsman-ice.com 17-3720-01...
