Optional Parts - Whirlpool GY398LXP Parts Manual

For Models: GY398LXPB01, GY398LXPQ01, GY398LXPT01, GY398LXPS01
Illus. Part
No. No. DESCRIPTION
PAINT, TOUCH−UP (1/2oz.)
72017 White
261869 Cord Brown
72032 Black
PAINT, SPRAY
350930 White
261900 Citrine White
830864 Black
ADHESIVE
591014 Adhesive
Loctite (1/3 oz.)
482338 Sealer, Silastic
(3 oz.)
8186415

OPTIONAL PARTS

(Black) (White)
Illus. Part
No. No. DESCRIPTION
SPLICING WIRES−−25FT.
LENGTH
242828 Wire (12 Ga.
150 c Black)
242820 Wire (14 Ga.
150 c Black)
242821 Wire (14 Ga.
150 c Blue)
242822 Wire (14 Ga.
150 c Brown)
242830 Wire (14 Ga.
200 c Brown)
242823 Wire (14 Ga.
150 c Green)
242824 Wire (14 Ga.
150 c Orange)
242829 Wire (12 Ga.
150 c Red)
242825 Wire (14 Ga.
150 c Red)
242831 Wire (14 Ga.
200 c Red)
242826 Wire (14 Ga.
150 c White)
242827 Wire (14 Ga.
150 c Yellow)
242832 Wire (14 Ga.
200 c Yellow)
9
(Biscuit) (S.Steel)
Illus. Part
No. No.
WIRING HARNESS PARTS
9759538 Harness, Wire
9759702 Harness, Wire
9759701 Harness, Wire
9759703 Harness, Wire
9759715 Conduit
3196173 Screw (Conduit)
313660 Clip, Ground Wire
4448664 Clamp
4449809 Screw
112432 Nut
4450800 Screw, Ground
4452222 Spacer, Harness
3400015 Screw, Ground
Miscellaneous
814381 Hinge Pin Kit
4448950 Screw, Install (4)
9782676 Anit−Tip Assy
9757784WH White
9757784BL Black
9757784BT Biscuit
9757784SS S.Steel
DESCRIPTION
(Main)
(Cooktop Power)
(Cooktop Left)
(Cooktop Right)
Filler,Counter Top
