Icotera 86071 Installation Manual

Optical cpes and ftus
Hide thumbs
Table of Contents

Advertisement

Quick Links

Installation of Icotera optical CPEs and FTUs
Installation Guide for Icotera Fibre Termination Units
and optical Customer-Premises Equipment
Published: February 2017
Document version: 1.0
1
Icotera A/S, Kongevejen 400D, 2840 Holte, Denmark - info@icotera.com
Document version: 1.0

Advertisement

Table of Contents
loading

Related Manuals for Icotera 86071

Summary of Contents for Icotera 86071

  • Page 1 Installation of Icotera optical CPEs and FTUs Installation Guide for Icotera Fibre Termination Units and optical Customer-Premises Equipment Published: February 2017 Document version: 1.0 Icotera A/S, Kongevejen 400D, 2840 Holte, Denmark - info@icotera.com Document version: 1.0...

  • Page 2: Change Log

    Installation of Icotera optical CPE and FTU Change log Date Version Reason for a change Author <ijakobik@icotera.com> 15/03/2017 First release available to public. Icotera A/S, Kongevejen 400D, 2840 Holte, Denmark - info@icotera.com Document version: 1.0...

  • Page 3: Supported Models

    Installation of Icotera optical CPE and FTU Preface This installation guide covers all steps necessary to perform physical installation of Icotera CPE, ONT, and FTU. It shows how to open FTU case when it can be freely manipulated in hands (eg. after unpacking it) and when it is mounted on the wall.

  • Page 4: Safety Precautions

    Do not allow children to play with the product, as it contains small parts that could be detached and create a choking hazard.  Use only original Icotera components and replacement parts. Failure to do so may result in performance loss, damage to the product, fire, electric shock, or injury. Any unauthorised modifications also invalidate the warranty.
  • Page 5 CPE/ONT model. Fibre optics safety The Icotera CPE in its optical variant utilizes laser and fibre optic technology. Although the strength of the light beam transmitted through the fibre is comparably low, caution should be maintained when handling fibre connectors and cords. When not connected, all optical connectors and sockets must be protected with dedicated caps.
  • Page 6 Used to fix the fibre cable/pipe to the holders. Cable tie 1 or 2 The amount of required items depends on the installation type chosen. Cable tie should Icotera A/S, Kongevejen 400D, 2840 Holte, Denmark - info@icotera.com Document version: 1.0...
  • Page 7 Used for gas sealing when the installation connector - type 2 type is blowing air pipe based. (optional) Demultiplexes incoming signal to separate WDM Filter CATV and data fibres. Icotera A/S, Kongevejen 400D, 2840 Holte, Denmark - info@icotera.com Document version: 1.0...
  • Page 8  Free airflow ensuring proper working conditions for the CPE. The Icotera's CPE has ample ventilation openings on the sides and top of the CPE. It is important to remember however, that free airflow must be maintained in the area surrounding the device at all times.
  • Page 9 2. Turn FTU around and grab FTU base by its large openings. Figure 5. Grab FTU base 5. Separate FTU bottom from its cover. Figure 6. Separate FTU bottom and cover Icotera A/S, Kongevejen 400D, 2840 Holte, Denmark - info@icotera.com Document version: 1.0...
  • Page 10 The remaining six lateral insertion points require openings to be made in the FTU cover. The chosen openings need to be cut out along kerfs that are embossed on the inside surfaces of the FTU cover walls. Icotera A/S, Kongevejen 400D, 2840 Holte, Denmark - info@icotera.com Document version: 1.0...
  • Page 11 Figure 10. Avoid cutting at angle close to 90° Figure 11. To make cutting easier hold knife at angle of about 45° Icotera A/S, Kongevejen 400D, 2840 Holte, Denmark - info@icotera.com Document version: 1.0...
  • Page 12 Ensure that at least 80 cm of the fibre cable remains beyond the sleeve outlet. Then fasten the fibre cable to the holders inside the FTU base. The number of ties and their arrangement may vary but must ensure a smooth flow of the cable Icotera A/S, Kongevejen 400D, 2840 Holte, Denmark - info@icotera.com Document version: 1.0...
  • Page 13 Figure 16. Maximal values of pigtail's protector part If the installation requires additionally splicing a WDM filter, it can be placed in the holder below the splice tube holders. Icotera A/S, Kongevejen 400D, 2840 Holte, Denmark - info@icotera.com Document version: 1.0...
  • Page 14 2. After S-shaped coil is made, run the fibre between the short and long fences in the top, and under short fence in the bottom, as shown in the picture below. Icotera A/S, Kongevejen 400D, 2840 Holte, Denmark - info@icotera.com Document version: 1.0...
  • Page 15 3. Repeat second step twice to get three full fibre coils between the short and long fences. Figure 21. Run the fibre twice more between the short and long fences Icotera A/S, Kongevejen 400D, 2840 Holte, Denmark - info@icotera.com Document version: 1.0...
  • Page 16 5. Once more run the fibre as in the step 4, and secure fibre plug on its support. Figure 23. Run the fibre once more above the long fence and secure plug on its support Icotera A/S, Kongevejen 400D, 2840 Holte, Denmark - info@icotera.com Document version: 1.0...

  • Page 17: Installing The Cpe

    (with or without CATV service, VoIP service, etc.) and particular user environment configuration. The configuration presented below utilizes all available CPE ports:  1 CATV port  4 Ethernet ports  2 VoIP ports Icotera A/S, Kongevejen 400D, 2840 Holte, Denmark - info@icotera.com Document version: 1.0...
  • Page 18 Figure 26. The CPE with user equipment and DC12V cable plugged in Now the CPE installation process is complete and you can start using the CPE in your environment. Icotera A/S, Kongevejen 400D, 2840 Holte, Denmark - info@icotera.com Document version: 1.0...
  • Page 19 Figure 28. Pull FTU edge with your left hand while holding its right side in place 2. FTU cover should bend slightly and its left side should disengage from the base. Icotera A/S, Kongevejen 400D, 2840 Holte, Denmark - info@icotera.com Document version: 1.0...
  • Page 20 Figure 30. Hold left side of the FTU cover and pull its right side 6. Separate FTU cover from its base Figure 31. FTU case is now opened Icotera A/S, Kongevejen 400D, 2840 Holte, Denmark - info@icotera.com Document version: 1.0...

  • Page 21: Appendix A: Other Installation Examples

    WDM filter connected to a common fibre that enters the FTU through a blowing air pipe. The filter, mounted in the holder in the bottom of the FTU, separates the CATV and data signals and sends them through their corresponding fibres. Icotera A/S, Kongevejen 400D, 2840 Holte, Denmark - info@icotera.com Document version: 1.0...
  • Page 22 Figure 35. CPE fitted with the blind bottom cover with safety caps attached Before connecting the cords, safety caps need to be removed from the CPE and patch cord connectors. Icotera A/S, Kongevejen 400D, 2840 Holte, Denmark - info@icotera.com Document version: 1.0...
  • Page 23 GPON installation with a single fibre that enters FTU through a blowing air pipe terminated with a gas block connector. Figure 37. FTU base and GPON configuration with gas block type 1 installed – note the 86018 model of the FTU Icotera A/S, Kongevejen 400D, 2840 Holte, Denmark - info@icotera.com Document version: 1.0...
  • Page 24 Installation of Icotera optical CPE and FTU Figure 38. FTU base and GPON configuration with gas block type 2 installed– note the 86018 model of the FTU Icotera A/S, Kongevejen 400D, 2840 Holte, Denmark - info@icotera.com Document version: 1.0...

  • Page 25: Appendix B: Ftu Base Drilling Template

    The following image can be used as a template to mark drilling points before mounting the FTU base on a wall. The distances between openings for screws are the same for both 86018 and 86071 FTU bases, so this template may be used for both previous and present Icotera FTU cases.

This manual is also suitable for:

86072
