- Page 1 User Guide Icotera i6800 Triple play FTTH solution Published: October 2016 Software version: 1.10.0 Document version: 2.0...
-
Page 2: Table Of Contents
Product Overview ......................5 General Features and Characteristics ................ 5 Physical Description ....................5 Configuring and managing the i6800 ................. 8 Web interface general overview ................. 8 Logging in to the web interface ................10 Viewing device status information ................11 Managing the LAN and Wi-Fi settings .............. -
Page 3: Change Log
Change log Date Version Reason for a change Author 28/10/2016 First release available to public. <ijakobik@icotera.com>... -
Page 4: Introduction
Two-channel SIP VoIP with alaw/ulaw fax is supported. Among other supported features local tones and fast dial are included. The Icotera i6800 provides a wide transparent bandwidth to support CATV analog channels or a combination of analog and digital channels including HDTV broadcast. -
Page 5: Product Overview
This chapter provides a comprehensive overview of the i6800 components, features and characteristics. General Features and Characteristics This section presents a list of features and characteristics of the Icotera i6800 related to its hardware, software and environment of operation. Features •... - Page 6 Figure 1. The Icotera i6800 front panel Status LEDs There are two types of the Icotera i6800 status LEDs: LAN port LEDs and the LEDs on the LED panel that is located between LAN and POTS ports. Figure 2. The Icotera i6800 status LEDs...
- Page 7 The power port accepts DC 12V power source. It is important to make sure that the proper power adapter is suitable to a particular region. On/Off Switch The On/Off switch enables you to switch the i6800 on or off, as well as reboot the i6800 and restore the last saved configuration. Reset Button The Reset button has four modes of operation: •...
-
Page 8: Configuring And Managing The I6800
Figure 3. Icotera i6800 web interface Top bar The top bar contains the Icotera logo, device designation, drop-down list which enables to choose interface language, and the Log out button. Menu The menu has a form of a collapsible list of available options, which are grouped into two levels: main and secondary. - Page 9 Figure 4. Collapsing i6800 web interface menu Management area The management area is where all the i6800 management and status information are displayed and modified. Depending on the selected option, it can display a set of particular configuration options or a list of current i6800 status information.
-
Page 10: Logging In To The Web Interface
Logging in to the web interface Complete the following steps to log in to the web interface: Enter the address of your i6800 unit in the address bar of your web browser. The following login prompt will be displayed. Figure 5. Icotera i6800 login prompt Enter your username and password in the respective fields. -
Page 11: Viewing Device Status Information
IP leases for LAN interfaces, and to view VoIP call log. Obtaining general system information To access general information about your i6800 go to Status > System information. This menu includes the following information: The System information section: •... - Page 12 Configuring and managing the i6800 Figure 6. System information section of the Status menu Monitoring the WAN interface The WAN section of the Status menu lists basic information about interface as well as the statistics of data carried through the interface.
- Page 13 Configuring and managing the i6800 • Default gateway: The default gateway configured for the WAN interface. • MAC address: The interface's physical address. The WAN counters section displays statistical information about the data. The WAN information menu can be refreshed at any with the Refresh button.
- Page 14 The LAN information can be refreshed at any with the Refresh button. Monitoring the wireless interfaces The Wi-Fi 802.11b/g/n and Wi-Fi 802.11ac sections contain information about i6800 wireless interfaces and their access points. These two sections describe separate interfaces, but their...
- Page 15 Configuring and managing the i6800 Figure 9. The Wi-Fi interface tab of the Status menu The General section contains the following general information about the interfaces: • Status: Interface status, either On or Off. • Channel: The wireless channel on which the interface operates (Reselect button allows to reselect channel if Channel option in Settings section is set to auto).
- Page 16 Configuring and managing the i6800 • Status: Current status of the given interface, either Up or Down. • Pkts in: The number of incoming packets in the current session. • Pkts out: The number of outgoing packets in the current session.
- Page 17 Configuring and managing the i6800 • Duration: Call duration. • Status: Call status (e.g. answered, busy) • Codec: Codec used. • Dir.: Call direction (incoming or outgoing). • Max Jitter: Maximal jitter value in seconds. • Pkts. lost: Number of lost packets.
-
Page 18: Managing The Lan And Wi-Fi Settings
Configuring and managing the i6800 Managing the LAN and Wi-Fi settings The Settings menu provides advanced configuration options to control the Layer 3 network parameters of your cabled and Wi-Fi network. This menu allows to configure the IP settings of all available interfaces in your home network. - Page 19 Configuring and managing the i6800 • Lease time: specifies the DHCP lease renewal time in seconds. The value in this field must range from 60 to 86400 and cannot be higher than the value in the Max lease time field. It is recommended to leave this value at its default setting.
- Page 20 Use the Encryption drop-down list to select the type of encryption key and the encryption algorithm used to secure the Wi-Fi transmission between your computer and the i6800. Available choices are None, WEP-64, WEP-128, WPA TKIP, WPA AES, WPA TKIP-AES, WPA2 TKIP, WPA AES and WPA TKIP-AES.
- Page 21 Configuring and managing the i6800 Figure 14. The WPS section Access lists Each access list provides an Ethernet layer 2 filter, which can be used either to allow or to deny particular users to connect based on their Wi-Fi adapters MAC address. In order to configure the Access list for your interfaces, complete the following steps: Click the Wi-Fi 802.11b/g/n or Wi-Fi 802.11ac submenu of the Settings menu to open the...
- Page 22 Configuring and managing the i6800 In order to set a limit of clients that may be connected to your APs, check the Client limit checkbox and enter the desired client limit value. The maximum value is 32 clients. Use the Access list behavior radio buttons to define the desired behaviour of the access list: •...
-
Page 23: Using Network Diagnostic Tools
Using network diagnostic tools The Diagnostic menu contains Ping, Traceroute, Wi-Fi scan, and Reset options, which can be used to troubleshoot connection problems and to reboot the i6800. Ping option To use the network Ping tool, complete the following steps: Click the Ping submenu in the Diagnostic menu to open the Ping section. - Page 24 Figure 18. Wi-Fi scan section of the Diagnostic menu The network scan tool enables the i6800 to execute a site survey for all wireless networks in the neighborhood. As a result of this survey, a list of scanned networks will be presented. In order to execute the site survey from your CPE complete the following steps: Press the Scan button in the Network Scan section.
- Page 25 Configuring and managing the i6800 After the site survey has been completed, the table of networks will be displayed, which contains the following information: • CH: operating channel number of the neighboring network. • Type: connection type. • SSID: SSID of the neighboring network.
-
Page 26: Changing Administrator Settings
Managing LEDs behaviour Use the following steps to manage i6800 LEDs behaviour: In the Administration menu click the LEDs submenu to go to the LEDs section. Figure 21. LEDs section of the Administration menu From the LEDs drop-down list choose the preferred LEDs behaviour: •... - Page 27 Configuring and managing the i6800 • high - LEDs are visible in daylight. • medium - LEDs are barely visible in daylight. • low - LEDs are visible in darkness but not in daylight. Confirm your changes by clicking the Save button on the bottom bar or click Reset button to restore default settings.
-
Page 28: Managing Services
Configuring and managing the i6800 Managing services The Services menu provides configuration options for controlling port forwarding, DMZ, ALG, parental control settings, Wake-on-LAN function, and DDNS configuration. Managing port forwarding Use the following steps to manage port forwarding: In the Services menu click the Port Forwarding submenu. - Page 29 Configuring and managing the i6800 range, and in the Int. IP field type internal IP address. Then, in the Int. port, type internal port number. • Click checkbox in the Loopback column to enable loopback feature for a given port.
- Page 30 Configuring and managing the i6800 Confirm your changes by clicking the Save button on the bottom bar or click Reset button to restore previously saved settings. To activate ALG settings click Apply button. Managing Parental control Use the following steps to manage Parental control settings: In the Services menu click the Parental control submenu.
- Page 31 Configuring and managing the i6800 • Check Use DNS filtering checkbox to activate fields in Enabled column. • Check Enabled checkbox to activate Domain and Exact matching fields. • Fill Domain field with domain name which would be blocked. • From the Exact matching drop-down list chose matching method for domain name (Suffix matching or Exact matching).
- Page 32 Configuring and managing the i6800 In the Services menu click the DDNS submenu. Figure 27. DDNS section of the Services menu Complete the following steps to manage the DDNS. • Check the Enabled checkbox to enable DDNS service • Enter update interval.
- Page 33 The information contained in this document represents the current view of Icotera on the issues discussed as of the date of publication. Because Icotera must respond to changing market conditions, it should not be interpreted to be a commitment on the part of Icotera, and Icotera cannot guarantee the accuracy of any information presented after the date of publication.
