- Page 1 ITEM NAME: Belham Living Santa Clara Hexagonal Polycarbonate Gazebo SKU: PACA054-1 & PACA054-2 For assistance with assembly, please contact Customer Care Center 1-888-880-4884...
- Page 2 Note: It is very important to read and follow these Safety Precautions before assembly and during the use of this product. PRE-ASSEMBLY PREPARATION: THIS PACKAGE MAY CONTAIN SMALL ITEMS WHICH SHOULD BE KEPT AWAY FROM CHILDREN • Please check that all parts and hardware are included before beginning assembly. Save all packing materials until assembly is complete to avoid accidentally discarding smaller •...
- Page 3 PART LIST Part Description Quantity Part Description Quantity Part Description Quantity A Cross Beam N Roof rim AA Self tapping screw 24 B Netting rail O Roof rim BB Hex bolt C U-Shaped bracket 12 P Tube end cover CC Hex bolt & Nut D Corner Post Q Tube end cover 12 DD Spanner...
- Page 4 STEP-BY-STEP ASSEMBLY: Step 1 Attaching the netting rail and U-bracket Cx12 AAx24 Fig. 1.1 BBx 12 Fig. 1.2 1.1 Attach two U-shaped brackets (C) onto the top of each cross beam (A) with bolts (BB) using spanner (DD). (Fig. 1.1) 1.2 Attach two netting rails (B) to the inner side of each cross beam (A) with four screws (AA) using Philips screwdriver (FF).
- Page 5 Step 3 Attaching Support Bars BBx24 3.1 Install supports bars (E)/(F) between post (D) and cross beams (A) with bolts (BB) using spanner (DD) to stabilize the main frame. (Note: Attach the support bars (E & F) to the corner post (D) first loosely then to the cross beam (A) before fully tightening bolts for ease of assembly).
- Page 6 Step 5 Attaching the Roof Frame to the Main frame CCx6 Fig. 5.2 Fig. 5.1 5.1 From a free standing ladder in the center of the main frame, place the complete roof frame on the main frame. 5.2 Secure roof tubes in the bracket at the top of corner posts with bolts and nuts (CC) using spanners (DD) and (EE).
- Page 7 Step 7 Attaching Cross Bars 7.1 Attach cross bars (K) to the bottom of roof sheets (R). Step 8 Installing Middle Roof Tubes Lx12 Fig. 8.1 CCx12 Fig. 8.2 BBx18 8.1 Secure the top of two middle roof tubes (L) onto one washer plate (M) with bolts (BB).
- Page 8 Step 9 Installing Roof Sheets 9.1 Slide roof sheets (S), (U) and (T) into the rails of roof tubes (G) and middle roof tubes (L) until they firmly fit the rails. Step 10 Attaching Roof Rims 10.1 Cover the bottom of roof sheets (S) and (T) with roof rims (N). 10.2 Cover the bottom of roof sheets (U) with roof rims (O).
- Page 9 Step 11 Installing Tube End Covers Fig. 11.2 Fig. 11.1 11.1 Cover the bottom of roof tubes (G) with tube end covers (P) with bolts (BB) using spanner (DD). (Fig. 11.1) 11.2 Cover the bottom of middle roof tubes (L) with tube end covers (Q ) with bolts (BB) using spanner (DD).
