economical
leading design
clean air approved
Natural 7 Wood Pellet Fire
Owners & Installation Manual
PLEASE READ THIS ENTIRE MANUAL BEFORE INSTALLATION, AND USE OF THIS WOOD PELLET FIRE.
FAILURE TO FOLLOW THESE INSTRUCTIONS COULD RESULT IN PROPERTY DAMAGE, BODILY INJURY,
OR EVEN DEATH.
Contact your local building or fire official about restrictions and installation requirement in your area.
Advertisement
Chapters
Table of Contents
Related Manuals for Pellet Fire Solutions Ravelli Natural 7
Summary of Contents for Pellet Fire Solutions Ravelli Natural 7
- Page 1 economical leading design clean air approved Natural 7 Wood Pellet Fire Owners & Installation Manual PLEASE READ THIS ENTIRE MANUAL BEFORE INSTALLATION, AND USE OF THIS WOOD PELLET FIRE. FAILURE TO FOLLOW THESE INSTRUCTIONS COULD RESULT IN PROPERTY DAMAGE, BODILY INJURY, OR EVEN DEATH.
- Page 2 ATTENTION If you are a not a registered pellet re installer, and do not have legitimate access to the necessary passwords to install and program the Natural 7 Wood Pellet Fire, you MUST NOT install or attempt to install this fire. The Natural 7 Wood Pellet Fire requires technical programming and individualised air pressure adjustments to ensure it will operate safely and efciently, and to avoid possible damage...
-
Page 3: Table Of Contents
Owner’s section - Table of Contents Introduction................5 1.1 Specifications................ 5 Safety Warnings & Recommendations....... 6 Installation................... 6 2.2 Deciding where to locate your wood pellet burning fire.. 7 2.3 Ash.................... 7 2.4 Clinkering.................. 7 2.5 Filling Fuel Hopper.............. 7 Flammable Liquids..............8 2.7 Operating Instructions............... 8 Safety Devices................Responsibilty................2.10 Spare Parts................. What are Wood Pellets?............ - Page 4 Operating your Pellet Fire............. 15 Preliminary Operation..............15 Description of Handheld Set............15 Handheld Touch Radio Initialization........... 16 Description of the Display............16 6.5 Time and Date Settings............... 17 Loading the Auger............... 18 6.7 Setting Operating Temperature and Power....... 19 Turning the Device on..............19 Operating Phases of the Stove..........6.9.1 Alarms ..................
-
Page 5: Introduction
Your local Pellet Fire Solutions dealer will be happy to assist you in obtaining information with regards to your local building codes and installation restrictions. 1.1.1 Rating label Location Ravelli Natural 7 Freestanding: rating label located back unit. Note: Consumption will vary with the type of fuel used. -
Page 6: Safety Warnings & Recommendations
Ask your dealer for a recommended pellet type. Installation The stove must be installed and tested by specialised personnel approved by Pellet Fire Solutions. Please read this manual before installing or operating the stove. If you require further information,... -
Page 7: Deciding Where To Locate Your Wood Pellet Burning Fire
• Do not clean the stove until the structure and the ashes have cooled down completely. Carry out all operations with maximum safety. Natural 7 should be installed in a centrally located position within the home. This will assist the appliance to perform to the level required. As the Natural 7 heats space by convecting air across the top of the unit, the heater should face the majority of the area to be heated. -
Page 8: Flammable Liquids
Flammable Liquids Never use gasoline, gasoline – type lantern fuel, kerosene, charcoal lighter fluid or similar liquids to start or “freshen” up a fire in the stove. Keep all such liquids well away from the stove while it is use. Operating Instructions The stove is completely automated and will self-regulate the ignition phase, five levels of power and... -
Page 9: What Are Wood Pellets
What are Wood Pellets? Wood pellets are made from sawdust and wood shavings. The material used cannot contain any foreign substance such as glue, varnish or synthetic substances. Subjecting it to high pressure, the wood is pressed through a plate with holes, and due to the high pressure, the sawdust is heated activating the natural binders of the wood. -
Page 10: Pellet Combustion
Pellet Combustion Combustion is simply a chemical reaction between combustible and carburant. The result of this reaction is the heat. The three elements that are required for combustion are: -Combustible (pellet) -Carburant (oxygen available in the air) -Ignition (electrical resistance for ignition) PELLET To achieve combustion, the combustible and the carburant must be available in the correct proportions. -
Page 11: Maintenance And Cleaning
Maintenance and Cleaning Before carrying out any maintenance, take the following precautions: Maintenance and Cleaning Make sure that the stove has been turned off, and that the general power supply has been disconnected • (Ensure that the plug is disconnected from the socket, thus avoiding accidental electric shocks). Before carrying out any maintenance, take the following precautions: •... -
Page 12: Cleaning The Ash Drawer
Rengøring af askeskuffen: Cleaning the ashes drawer: Reinigung des Aschekastens: Askeskuffen skal rengøres hver 30. dag. The ashes drawer must be cleaned every days, depending on the length of time the stove is used, Det afhænger i alle tilfælde af hvor længe The ashes drawer must be cleaned every 30 Der Aschekasten muss alle 30 Tage gereinigt brændeovnen anvendes og af den type... -
Page 13: Acess To The Inspection Hatches For Cleaning The Smoke
guarnizionate pertanto prima di rimontare hautes températures ; le botole, assicurarsi che le guarnizioni che après le nettoyage du poêle il faut nettoyer permettono l’ermeticità non siano usurate. la plaque et s’assurer que le joint n’est pas Smontare lo scambiatore in ghisa come in abimé... -
Page 14: How To Load Pellets
How to load pellet open the lid of pellet tank (1) and lift the iron slide (2) as shown. This helps to prevent the pellet bag to touch the cast-iron parts. Lid of pellet tank Iron slide 5.9 How to remove flame trap Remove and clean the flame trap regularly Fase A / Phase A Fase B / Phase B... -
Page 15: Operating Your Pellet Fire
Vers. 01 del 07/04/15 Manuale utente PALMARE IDRO TOUCH RADIO Operating your Pellet Fire Pag.22 Vers. 01 del 07/04/15 Manuale utente PALMARE IDRO TOUCH RADIO Preliminary Operations Pag.22 Preliminary Operations Wiring Preliminary Operations Wiring power cord of the stove. What to check befor turning on the stove power cord of the stove. -
Page 16: Handheld Touch Radio Initialization
Vers. 01 del 07/04/15 Manuale utente PALMARE IDRO TOUCH RADIO Pag.23 Handheld touch radio initialization Handheld touch radio initialization In order to operate correctly, the handheld set should be interfaced with the electronic board installed inside the stove. For this FIRST INSTALLATION? PRESS THE KEY RADIO ADJ ON THE STOVE... -
Page 17: Time And Date Settings
When you replace the batteries, you do not have to run the initialization procedure of the handheld set. In this case, when on display appears the message “FIRST INSTALLATION ?”, select NO Description of the display Description of the display The display of the handheld set is described below (in stand-by mode): After 5 minutes of inactivity, the display of the handheld set turns dark, switching to “SLEEP”... - Page 18 Time and date setting Time and date setting Below are given the steps for accessing the relative menu. MENU USER USER SCREW FEEDING COMFORT CLIMA USER CHRONOTHERMOSTAT SETTINGS MANUFACTURER AIR-PELLET SET ENGINEER STOVE STATE Press the key Press the key “access menu” to Press the key “selection”...
-
Page 19: Loading The Auger
Vers. 01 of:07.04.14 User’s manual HANDHELD TOUCH RADIO Loading the Auger Pag.22 Loading the auger Carry out this operation to facilitate stove’s first start operations; You should also check that you have introduced pellets into the hopper and wait until the stove is in “SHUTDOWN” or “FINAL CLEANING” mode. The number expressed in sec- onds indicates the rotation time of the infeed screw during the first loading cycle. -
Page 20: Operating Phases Of The Stove
Vers. 01 of:07.04.14 User’s manual HANDHELD TOUCH RADIO Pag.23 Operating Phases of the Stove Operating phases of the appliance Modulation During the work phase, the appliance should reach the room temperature set; when this condition is met, the stove switches to MODULATION mode in which fuel consumption and ventilation are minimum. - Page 21 Vers. 01 of:07.04.14 User’s manual HANDHELD TOUCH RADIO Pag.24 The first setting allows the activation of the CLIMATE COMFORT function. This function is intended to ensure that the room tem -perature set is maintained steady upon setting the maximum period of “X” minutes (SWITCH-OFF DELA Y: 5 MIN) before switch-ing to ECO STOP phase.
- Page 22 Vers. 01 of:07.04.14 User’s manual HANDHELD TOUCH RADIO Pag.25 Settable switch-on program Settable switch-off program Day of the week with active program Number of "chrono" program (1-2-3-4) Setting the power upon programming Setting ambient temperature By pressing the Increment key you can change each value and, at step 3, enable the days of the week; By pressing the Increment key you can change each value and, at step 3, enable the days of the week;...
- Page 23 Vers. 01 of:07.04.14 User’s manual HANDHELD TOUCH RADIO Pag.26 Stove State Below are given the steps for accessing the relative menu starting from Stand-By mode. MENU USER USER SCREW FEEDING SCREW FEEDING USER CHRONOTHERMOSTAT CHRONOTHERMOSTAT MANUFACTURER AIR-PELLET SET AIR-PELLET SET ENGINEER STOVE STATE STOVE STATE...
- Page 24 Vers. 01 of:07.04.14 User’s manual HANDHELD TOUCH RADIO Pag.27 Settings Below are given the steps for accessing the relative menu starting from Stand-By mode. MENU USER USER SCREW FEEDING COMFORT CLIMA USER CHRONOTHERMOSTAT SETTINGS MANUFACTURER AIR-PELLET SET ENGINEER STOVE STATE Press the key Press the key “confirm”...
- Page 25 Vers. 01 of:07.04.14 User’s manual HANDHELD TOUCH RADIO Pag.28 Single ducting (function present only in models equipped with single ducting system) The stoves with optional fan employ the natural convection system that ensures a considerable heat output in the environment with the total absence of noise generated by room ventilation.
- Page 26 % of ventilation (see the MAN and AUT control table) Cubic capacity priority among rooms Stove phase synthetical layout PHASE DESCRIPTION The stove is in the switch off phase and the cooling phase has not been completed yet. FINAL CLEANING SWITCH ON The heater pre-heating phase has started and the pellets start to fall into the grate.
- Page 27 Vers. 01 of:07.04.14 User’s manual HANDHELD TOUCH RADIO Pag.36 PHASE DESCRIPTION Switch-on is requested but with the stove in cooling phase; once this condition is met, it START/RESTART WAIT restarts automatically. The HOT restart phase is activated. SWITCH ON RESTART Functioning is similar to the SWITCH ON phase The maximum fume temperature threshold has been reached.
-
Page 28: 6.9.1 Alarms
6.9.1 Alarms Vers. 01 of:07.04.14 User’s manual HANDHELD TOUCH RADIO Pag.37 Alarms (table with reference codes) TITLE REASON SOLUTION TRIAL - No voltage during work phase - Press the switch off key and switch on boiler switch-on. AL 01 BLACK OUT - If the problem persists, contact the Support Service - The fume probe is malfunctioning... - Page 29 Vers. 01 of:07.04.14 User’s manual HANDHELD TOUCH RADIO Pag.38 In the case of alarm 07 THERMAL BREAKER below shows the location where to operate to reset the thermal switch with manual reset. Manual reset thermal breaker Unscrew the protective cap and press the button to reset the thermal breaker Unscrew the protective cap and press the button to reset the thermal breaker...
-
Page 30: Maintenance Record
7. Maitenace record Maintenance Record DATE WORK CARRIED OUT SIGNATURE... -
Page 31: Warranty Information
8. Warranty Information Component(s) Parts Period Comments Pellet Solution s and its partner Ravelli , Fireplace, Full 5 years Surface manufacturers of the Ravelli range of pellet fires stovebody and replacement parts finishes, parts covering: burnpot liner extends the following warranty for their wood pellet fires 2 years and ceramic when purchased from an authorised Pellet... -
Page 32: Warranty Exclusions
Warranty Exclusions The warranty is void if: The pellet fire has been over-fired or operated in This warranty does not cover the following: atmospheres contaminated by chlorine, fluorine, or other • Changes in surface finishes as a result of normal use. damaging chemicals. -
Page 33: Proof Of Purchase/Warranty
9. Proof of Purchase/Warranty Use this page to note down the details of your wood pellet fi re purchase, and attach the receipt and any other documents/ business cards from the retailer that sold you the fi re. Name of Store where Pellet fi re was purchased: ....................... Date of Purchase: ....................... - Page 34 Table of Contents Dimensions R avelli Natural 7............... Deciding where to locate your wood pellet burning stove: ........36 Clearances to Combustibles – Ravelli Natural 7 Freestanding ......36 Exhaust and Fresh Air Intake Locations ..............36 Installation ....................37 Dimensions –...
-
Page 35: Dimensions R Avelli Natural 7
Dimensions (Ravelli Natural 7) NATURAL 7 Unit of Measurement Height 1040 Width Depth Weight Diameter of smoke exhaust duct Min.-max. calorofic power 4.3 - 6.6 Min.-max. hourly consump- Kg/h 0.95 – 1.5 tion of pellets Electrical power absorbed during operation Supply V - Hz 220 –... -
Page 36: Deciding Where To Locate Your Wood Pellet Burning Stove
This will optimize heat circulation. Check clearances to combustibles. Clearances to Combustibles – Ravelli Natural 7 Freestanding This pellet heater requires floor protection which must be non-combustible, extending beneath the stove the full width and depth of the unit including (150mm) in front for ember protection. -
Page 37: Installation
Installation Dimensions – Natural 7 Freestanding Refer to Safety T 0506 for all clearances to combustible. Clearances & Minimum clearances shown are in millimetres. All Ravelli fires tested AS/NZS 2918:2001. a guide only. Refer to the Installation and Operation Manual supplied with every Ravelli Pellet Fire or if in doubt, consult your Pellet Retailer. -
Page 38: Minimum Clearance To Combustibles
Minimum Clearance to Combustibles Side of Unit A ( ) 50mm Rear wall to Lined Flue C, G, ) 25 mm Rear wall to Unlined Flu C, 75mm Rear of Unit (H) 1 0mm Rear corners (Corner Installation) (F) 1 0mm Floor protection (from glass) (B) 150mm Location of the Pellet Fire... -
Page 39: Internal Standard Flue Kit (50Sbd/N)
50S D/N Internal Standard Flue Kit Dual/Natural This flue kit may be used in new and replacement applications in rooms with stud height of 2.4m. The overall height of the flue is 3.6m. The visible flue is finished in black and the ceiling plate is white. The support angles for securing the liner to the ceiling are not shown. -
Page 40: External Standard Flue Kit (51Ita)
51ita 51ita External Standard Flue Kit This flue kit may be used in new and replacement applications with the flue penetrating the wall behind the fire, running vertically up an outside wall and penetrating the soffit. The overall height of the flue is 3.6m. -
Page 41: Seismic Restraint
Seismic Restraint All installation scenario for atural 7 require the use of hold-down anchors . Fixing to Concrete Floor: • Minimum M8 expansion anchors (M10 recommended) or min M8 epoxy- set anchors. • Approved Anchors: Expansion Anchors-Ramset Dynabolt and Trubolt, Hilti HAS. •... -
Page 42: How To Mount The Side Panels
Brochure for Broschüre für Modell Opuscule dédié au modèle Natural 7 model Natural 7 Natural 7 2.12 How to mount the side panels... -
Page 43: Installation Data Sheet
Installation Data Sheet Name of Owner: Name of Dealer: ________________________________ ________________________________ Address: Address: ________________________________ ________________________________ ________________________________ ________________________________ ________________________________ ________________________________ ________________________________ ________________________________ Phone: Phone: ________________________________ ________________________________ Model: __________________________ Name of Installer: ________________________________ Serial Number: ____________________ Address: Date of Purchase: __________ (dd/mm/yy) ________________________________ Date of Installation: _________ ________________________________... -
Page 44: Maintenance Record
Maintenance Record DATE WORK CARRIED OUT SIGNATURE... -
Page 45: Producer Statement And Warranty Registration Form
Declaration by Owner: I hereby certify the above particulars are true and correct. My Pellet Fire Technician has demonstrated to me the correct operation of my Pellet Fire. I understand that warranty conditions require an authorised Pellet Fire Solutions Installer to complete the installation...
