Automated Signature Technology 3

Basic Machine Components

Part 1: Components

Signature card reader

The Signature Card Reader is located on the top left side of the Ghostwriter. The status light is located
on the top of the machine. The Signature Card is inserted into the front of the reader. This status light
will blink green when the reader is accessing the signature card.

Keypad

The buttons on the keypad vary in function depending on the menu options that appear on the
screen. See the LCD panel for function key listing.
Electric lock [optional]
The electric lock is located on the right side of the machine. Once locked, it will prevent any operation of the
machine.

On-Off switch

The on-off switch is located on the bottom right front of the machine.

Writing head

The writing head holds the pen and signs the signature. See page 4 for details.
