Kangook Paramotors
USER GUIDE
FEBRUARY 2020

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Vittorazi Atom 80 and is the answer not in the manual?

Questions and answers

Related Manuals for Kangook Vittorazi Atom 80

Summary of Contents for Kangook Vittorazi Atom 80

  • Page 1 Kangook Paramotors USER GUIDE FEBRUARY 2020...

  • Page 2: Table Of Contents

    Intermediate Swing Attachment Arms ................36 d. Swan Neck Attachment Arms ..................44 Pre-flight check ......................... 51 Checklist ............................52 Definitions ........................... 54 Recommended Tools ......................55 Kangook Paramotors User Guide – February 2020 – V3.0 Copyright 2020 All Rights Reserved.

  • Page 3: Introduction

    If you have any question or comments, do not hesitate to contact us at: KANGOOK PARAMOTORS 2699 5e Avenue, Local 20 Shawinigan, Québec G9T 2P7 Canada info@rsultra.com Tel : 1-819-538-5000 Fax : 418 289 3810 Kangook Paramotors User Guide – February 2020 – V3.0 Copyright 2020 All Rights Reserved.

  • Page 4: Motors And Multi-Fit Frame Systems

    Motors and Multi-fit Frame Systems The unique advantage of the Kangook range of products is its frame modularity. Indeed, most engine types will fit on our frames thanks to our Multifit system.
  • Page 5 For more information, please visit the following manufacturers websites: vittorazi.com polinithor.com |corsairmotors.com Kangook Paramotors User Guide – February 2020 – V3.0 Copyright 2020 All Rights Reserved.

  • Page 6: The Modular Cage System

    The Modular Cage System Kangook Paramotors produce cages made up of 2 or 3 identical ‘modular’ sections and a foot section. The assembly of the cage on the frame is easy and can be made in three steps. Note: The cage sections are delivered with the connectors and the velcro straps already in position.
  • Page 7 Step 1 : Connecting the Foot section Frame without foot attachment Foot attachment Foot attachment section inserted into the Frame Kangook Paramotors User Guide – February 2020 – V3.0 Copyright 2020 All Rights Reserved.
  • Page 8 3 : Push on the center of the cage section in order to 4 : You should hear ‘click’ once the section in position. insert it in the frame. Kangook Paramotors User Guide – February 2020 – V3.0 Copyright 2020 All Rights Reserved.
  • Page 9 7 : Then, insert through the buckle and pass the strap 8 : Finally, tighten the strap and any cut excess. Be sure into B. to leave at least 5cm. Kangook Paramotors User Guide – February 2020 – V3.0 Copyright 2020 All Rights Reserved.
  • Page 10 Attach the left cage section using the same process as for the right side. Your setup should appear as follows: 1 : Left and right cage sections attached to the foot and the frame. Kangook Paramotors User Guide – February 2020 – V3.0 Copyright 2020 All Rights Reserved.
  • Page 11 Velcro straps as shown 4 : Final result should look like this including the 3 : Attach the frame strap as shown. foot and 3 cage section. Kangook Paramotors User Guide – February 2020 – V3.0 Copyright 2020 All Rights Reserved.

  • Page 12: Harness And Frame System

    Harness and Frame System Kangook Paramotor frames have been specially designed to use the all features of the Sup’Air El Comfort harness. This system accommodates the full range of options when choosing one of the 6 different attachment systems offered by Kangook.
  • Page 13 11 : Then, pull the strap in order to get rid of this 10 : Keep pulling until there is only one second loop. loop left. Kangook Paramotors User Guide – February 2020 – V3.0 Copyright 2020 All Rights Reserved.
  • Page 14 To finish, assure yourself that the harness is well set by checking that it is fixed by: ● 2 straps on the top ● 2 straps on the sides ● 2 straps on the bottom (carrying straps) Kangook Paramotors User Guide – February 2020 – V3.0 Copyright 2020 All Rights Reserved.

  • Page 15: Split Leg Harness System

    Split Leg Harness System The Split Leg Harness can also be used on your Kangook Frame. The main benefits are its lightness as well as the freedom of movements it during the take-off and landing phases of your flight. Perform the following three steps on both sides of the harness.
  • Page 16 8 : Then, tighten the picture 4 loop in order to press 9 : Get rid of the previous loop by pulling the strap the harness against the frame. of the other loop. Kangook Paramotors User Guide – February 2020 – V3.0 Copyright 2020 All Rights Reserved.
  • Page 17 10 : Keep pulling until there is only one loop left. 13 : Get the strap surplus under the hoop. 14 : If necessary, tie and cover the surplus strap in the following manner. Kangook Paramotors User Guide – February 2020 – V3.0 Copyright 2020 All Rights Reserved.
  • Page 18 3 : Pull the strap through the first buckle. Do not over 4 : Pull the strap through the second buckle, do not tighten. over tighten. Kangook Paramotors User Guide – February 2020 – V3.0 Copyright 2020 All Rights Reserved.
  • Page 19 5 : Using pliers, pull the end of the strap. 6 : Tighten the first buckle as much as possible. 7 : Tighten the strap snug to the fram and then rotate the harness forward. Kangook Paramotors User Guide – February 2020 – V3.0 Copyright 2020 All Rights Reserved.
  • Page 20 1 : Identify the portage strap (red arrow). 2 : Unfasten the quick release buckle then attach it on the bottom of the frame. 3 : Fasten the portage strap. Kangook Paramotors User Guide – February 2020 – V3.0 Copyright 2020 All Rights Reserved.
  • Page 21 2: Unfasten the quick release buckle then attach it at 1 : Identify the retaining strap (green arrow). the specified location. 3 : Fasten the quick release buckle. Kangook Paramotors User Guide – February 2020 – V3.0 Copyright 2020 All Rights Reserved.
  • Page 22 Final result of a Split Leg Harness attached to the frame: Kangook Paramotors User Guide – February 2020 – V3.0 Copyright 2020 All Rights Reserved.

  • Page 23: Attachment Arms And Frame System

    Attachment Arms and Frame System In order to adapt to each pilot’s flying style and needs, Kangook offers six basic types of attachment arms. These include the (1) Fixed J-Bar in either aluminum or stainless steel, (2) the Low Swing arm, (3) the Intermediate Swing Arm, (4) the High Swing Arm, (5) the Kobra Fixed Arm and the (6) Swan Neck Arm in either Tubular, CNC Painted or the CNC Deluxe option.
  • Page 24 1: Pass the bar between the two straps. straps. 3: Place the rivet as shown and then set it with the 2: Put the bar into the strap opening. riveting machine. Kangook Paramotors User Guide – February 2020 – V3.0 Copyright 2020 All Rights Reserved.
  • Page 25 For this step, it will be necessary to use a winch in order to carry out a hang test. Proceed in the same way on both sides. 1: To adjust the straps to the right length, remove that buckle. Kangook Paramotors User Guide – February 2020 – V3.0 Copyright 2020 All Rights Reserved.
  • Page 26 Reminder: the plane of rotation of the propeller must be tilted between 5 and 10 degrees. 4: Replace the buckle on the mark in the opposite direction: it must be downwards. Kangook Paramotors User Guide – February 2020 – V3.0 Copyright 2020 All Rights Reserved.
  • Page 27 Finally, reposition the carabiner in the following manner. Kangook Paramotors User Guide – February 2020 – V3.0 Copyright 2020 All Rights Reserved.

  • Page 28: Low Swing Attachment Arms

    Tools needed :  Drill  Staged drill bit (1/4" – 3/4")  13/64" drill bit  13 mm spanner  6 mm Allen key Assembly : Kangook Paramotors User Guide – February 2020 – V3.0 Copyright 2020 All Rights Reserved.
  • Page 29 Step 3: Kangook Komfort Harness and Low Swing Attachment Arm connection Be careful, this step is only intended for Kangook Komfort harness users. Split Leg harness users must refer to page 32. 1 : Make sure that the components of the connector are set in the right order (picture).
  • Page 30 6 : Identify the buckle A as above (red 7 : In A, pass a shackle and the buckle of the blocking strap arrow). Kangook Paramotors User Guide – February 2020 – V3.0 Copyright 2020 All Rights Reserved.
  • Page 31 10 : Pull the strap through the second buckle. 11 : Pull the strap through the first buckle again. Kangook Paramotors User Guide – February 2020 – V3.0 Copyright 2020 All Rights Reserved.
  • Page 32 14 : Finally, you can remove the buckle shown on the picture, useless with this type of arms. Repeat Step 3 for the other Low Swing Arm. Kangook Paramotors User Guide – February 2020 – V3.0 Copyright 2020 All Rights Reserved.
  • Page 33 Step 3: Harness and Swan Neck Attachment Arms connection for Split Leg High Hook-In setup. Be careful, this step is only intended for Split Leg harness users. Kangook Komfort harness users must refer to page 27. 1 : Make sure that the components of the connector are 2 : Position the arm as in the picture.
  • Page 34 6 : Pass the blocking strap through a shackle. 7 : Then, pass the shackle in the buckle as shown (green arrow). Kangook Paramotors User Guide – February 2020 – V3.0 Copyright 2020 All Rights Reserved.
  • Page 35 7 : Pass the strap through the second 8 : Pass the strap through the first 9 : Once the strap adjusted, cut the buckle. buckle again. surplus. Kangook Paramotors User Guide – February 2020 – V3.0 Copyright 2020 All Rights Reserved.
  • Page 36 10 : Final result. Repeat Step 3 on the other side of the harness Kangook Paramotors User Guide – February 2020 – V3.0 Copyright 2020 All Rights Reserved.

  • Page 37: Intermediate Swing Attachment Arms

    2 blocking straps Tools needed :  Drill  Staged drill bit (1/4" – 3/4")  13/64" drill bit  13 mm spanner  6 mm Allen key Kangook Paramotors User Guide – February 2020 – V3.0 Copyright 2020 All Rights Reserved.
  • Page 38 2 : Use the staged drill bit to enlarge the drilling. connector. 3 : Keep on drilling until you are able to insert the connector. Repeat the step on the other side of the frame. Kangook Paramotors User Guide – February 2020 – V3.0 Copyright 2020 All Rights Reserved.
  • Page 39 It is useless to fully drill the bar. 3 : Make sure you obtained the correct result (see picture). Repeat the step on the other side. Kangook Paramotors User Guide – February 2020 – V3.0 Copyright 2020 All Rights Reserved.
  • Page 40 Step 3 : Kangook Komfort Harness and Intermediate Swing Arm connection Note: this step is only intended for Kangook Komfort harness users. Split Leg harness users must refer to page 42. 1 : Make sure that the connector components are set in the correct order (see picture).
  • Page 41 8 : Pass the strap through the first buckle again. 7 : Pass the strap through the second buckle. Kangook Paramotors User Guide – February 2020 – V3.0 Copyright 2020 All Rights Reserved.
  • Page 42 11 : To calibrate the paramotor, adjust the straps thanks to the two buckles (green arrows). For more information about calibration, refer to page 24 (Hang test). Kangook Paramotors User Guide – February 2020 – V3.0 Copyright 2020 All Rights Reserved.
  • Page 43 Step 3 : Split Leg High Hook-in Harness and Intermediate Swing Arm Attachment connection Be careful, this step is only intended for Split Leg harness users. Kangook Komfort harness users must refer to page 39. 1 : Make sure that the components of the connector are set in the right order (see picture).
  • Page 44 10 : Identify the buckle shown by the blue arrow remove the surplus. aobve and clip to the carabiner. Adjust the strap to the metal buckle (red arrow as shown above. Kangook Paramotors User Guide – February 2020 – V3.0 Copyright 2020 All Rights Reserved.

  • Page 45: Swan Neck Attachment Arms

     2 aluminium connectors (left and right)  2 connecting straps Tools needed :  Drill  Staged drill bit (1/4" – 3/4")  13mm spanner  6mm Allen key Kangook Paramotors User Guide – February 2020 – V3.0 Copyright 2020 All Rights Reserved.
  • Page 46 Direct drive motors pull to the left while belt drive motors pull right.: This picture shows the correct assembly for a belt drive engine. Kangook Paramotors User Guide – February 2020 – V3.0 Copyright 2020 All Rights Reserved.
  • Page 47 Step 2: Swan Neck Attachment Arm assembly Assemble the left swan neck arm following the pictures. Do the same for the right one. Kangook Paramotors User Guide – February 2020 – V3.0 Copyright 2020 All Rights Reserved.
  • Page 48 Adjust depending on the weight and comfort of the pilot). 5 : To be safer, get the ring inside the shackle to prevent undesired loosening (pictures 5 and 6). Kangook Paramotors User Guide – February 2020 – V3.0 Copyright 2020 All Rights Reserved.
  • Page 49 4 : The end result should look like this around the horizontal strap. 5 : Connect the shackle with the swan neck arm and (adjust depending on the weight of the pilot). Kangook Paramotors User Guide – February 2020 – V3.0 Copyright 2020 All Rights Reserved.
  • Page 50 3 : Loop back around the frame and insert the strap into A. 6 : Finally, insert it into A again. 5 : Insert the strap into B. Kangook Paramotors User Guide – February 2020 – V3.0 Copyright 2020 All Rights Reserved.
  • Page 51 8 : Heat seal the end of the strap. 9 : Attach the strap located at the middle of the harness to the back of the frame. Kangook Paramotors User Guide – February 2020 – V3.0 Copyright 2020 All Rights Reserved.

  • Page 52: Pre-Flight Check

     Gas handle: easy to squeeze closed to the slow position. Ensure the stop button (kill switch) is functional.  Ensure the Cruise control off (if one is used) Kangook Paramotors User Guide – February 2020 – V3.0 Copyright 2020 All Rights Reserved.

  • Page 53: Checklist

     Flight instruments (radio, GPS, altimeter) fastened and secured  Radio on, volume tested  Avoid engine exhause from blowing on the wing prior to takeoff. Kangook Paramotors User Guide – February 2020 – V3.0 Copyright 2020 All Rights Reserved.
  • Page 54  Ensure the Take-off area and and sky are clear of traffic START YOUR MOTOR, RUN OR TRIKE YOUR WAY INTO THE SKY AND ENJOY YOUR FLIGHT! Kangook Paramotors User Guide – February 2020 – V3.0 Copyright 2020 All Rights Reserved.

  • Page 55: Definitions

    The frame is used to mount various types of engines. A mounting plate made for the specific engine will be used to connect the motor to the frame. Also some motors are attached directly to the frame. Kangook Paramotors User Guide – February 2020 – V3.0 Copyright 2020 All Rights Reserved.

  • Page 56: Recommended Tools

    13/64" drill bit  Needle Nosed Pliers  Rivets o 3/16 o 1/8  Riveting Machine  Scissors  Wrench (Spanner) o Adjustable o 13mm Kangook Paramotors User Guide – February 2020 – V3.0 Copyright 2020 All Rights Reserved.
