  • Page 1 Service Manual TCM Endo R11 Nouvag AG · St.Gallerstr. 23–25 · CH-9403 Goldach Phone +41 (0)71 846 66 00 · Fax +41 (0)71 846 66 70 info@nouvag.com · www.nouvag.com DE: Technische Änderungen vorbehalten. Durch Weiterentwicklungen können Abbildungen und technische Daten geringfügig abweichen.

  • Page 2: Table Of Contents

    DEMONTAGE / DISMANTLING CONTRA ANGLE ART.1683 ZEICHNUNGEN / DRAWINGS FEHLER ANALYSE / TROUBLESHOOTING 10. ELEKTRONISCHE REPARATUR / ELECTRONIC REPAIRS 11. STK / ELECTRICAL SAFETY TEST FOR TCM ENDO R11 Service Manual TCM Endo R11, Ref.31582, V1/15 - 1 - Distribuidor: DepoDent España depósito dental DepoDent España - 902 767 118 -...

  • Page 3: Allgemeine Information / General Information

    It should be noted that the manufacturer accepts no liability for any harm or injury which patients may incur due to improper or unauthorized repairs/changes to the device. The warranty would, of course, also be void in such a case. Service Manual TCM Endo R11, Ref.31582, V1/15 - 2 - Distribuidor: DepoDent España depósito dental DepoDent España - 902 767 118 -...

  • Page 4: Kleiner Check / Small Check

    Does the plug look OK ? Does the motor run in response to the pedal Foot pedal being pressed ? Service Manual TCM Endo R11, Ref.31582, V1/15 - 3 - Distribuidor: DepoDent España depósito dental DepoDent España - 902 767 118 -...

  • Page 5: Funktions Test / Function Test

     Pedal loslassen Funktioniert das Gerät nicht, so schlagen Sie bitte im Kapitel 8 Fehler Analyse nach Service Manual TCM Endo R11, Ref.31582, V1/15 - 4 - Distribuidor: DepoDent España depósito dental DepoDent España - 902 767 118 - ventas@depodent.es...
  • Page 6  Disburden the pedal If the unit does not work, please refer to and afterwards again clockwise Chapter 8 Troubleshooting Service Manual TCM Endo R11, Ref.31582, V1/15 - 5 - Distribuidor: DepoDent España depósito dental DepoDent España - 902 767 118 -...

  • Page 7: Explosionszeichnung / Technical Drawins For

    TCM Endo R11 4. Explosionszeichnung / Technical drawins for TCM Endo R11 Art. No.1514 Service Manual TCM Endo R11, Ref.31582, V1/15 - 6 - Distribuidor: DepoDent España depósito dental DepoDent España - 902 767 118 - ventas@depodent.es...

  • Page 8: Stückliste / Parts List Foot Pedal (Art. No.1479Nou)

    Micro-switch D2vw IP67 3a/250V 21403 Druckfeder Fusschalter Tension spring 21408 Befestigungsplatte Plate for pedal 21410 Schalthebel Pedal lever for microswitch Service Manual TCM Endo R11, Ref.31582, V1/15 - 7 - Distribuidor: DepoDent España depósito dental DepoDent España - 902 767 118 - ventas@depodent.es...
  • Page 9 TCM Endo R11 Service Manual TCM Endo R11, Ref.31582, V1/15 - 8 - Distribuidor: DepoDent España depósito dental DepoDent España - 902 767 118 - ventas@depodent.es...

  • Page 10: Mikromotor / Micromotor (Art. No.1902)

    O-Ring Silikon 12,0x1,5 O-ring, silicone 12x1,5 26791 Schnappring Snap ring 76145 Motorkabel vormont. Motor cord pre assembled Service Manual TCM Endo R11, Ref.31582, V1/15 - 9 - Distribuidor: DepoDent España depósito dental DepoDent España - 902 767 118 - ventas@depodent.es...
  • Page 11 Stecker 2 pol , schwarz, Udel Plug autoclaveable 19992 Zugentlastung Strain relief 20188 Kabeltülle sterili. grau Cablebush autoclaveable Service Manual TCM Endo R11, Ref.31582, V1/15 - 10 - Distribuidor: DepoDent España depósito dental DepoDent España - 902 767 118 - ventas@depodent.es...

  • Page 12: Demontage / Dismantling Contra Angle Art.1683

    For exchange parts inside from the push-button head  Clamping tool on threaded ring 17156 fixing for open the head  All other parts can we now easy exchange Service Manual TCM Endo R11, Ref.31582, V1/15 - 11 - Distribuidor: DepoDent España depósito dental DepoDent España - 902 767 118 -...

  • Page 13: Zeichnungen / Drawings

    Washer stainless 75845 Kupplungsbüchse WST X-Smart Gear box 4:1 75847 Kopf 2:1 PEEK Head 2:1 pre-assembled PEEK Service Manual TCM Endo R11, Ref.31582, V1/15 - 12 - Distribuidor: DepoDent España depósito dental DepoDent España - 902 767 118 - ventas@depodent.es...
  • Page 14 17228 Kopfstück bearbeitet Head 17391 Zahntrieb 2:1 Output spindle 2:1 32986 Übertrieb 2:1 komplett Shaft 2:1 pre-assembled Service Manual TCM Endo R11, Ref.31582, V1/15 - 13 - Distribuidor: DepoDent España depósito dental DepoDent España - 902 767 118 - ventas@depodent.es...
  • Page 15 Pin 1 x 4,5, hardened 17234 Getriebewelle 1:1 rostfrei Drive shaft stainless 20124 Kugellager 5/10x4 Ball bearing 5/10x4 Service Manual TCM Endo R11, Ref.31582, V1/15 - 14 - Distribuidor: DepoDent España depósito dental DepoDent España - 902 767 118 - ventas@depodent.es...

  • Page 16: Fehler Analyse / Troubleshooting

    •Selection of different keys •PCB is defective •Exchange the PCB does not work Service Manual TCM Endo R11, Ref.31582, V1/15 - 15 - Distribuidor: DepoDent España depósito dental DepoDent España - 902 767 118 - ventas@depodent.es...

  • Page 17: Elektronische Reparatur / Electronic Repairs

    Wenn das Pedal gedrückt wird, ist als Bestätigung des Eingangs ein kurzer Signalton hörbar. Testing the pedal input signal If we push down the pedal is sort a signal ton audible which the input from the pedal confirmed Service Manual TCM Endo R11, Ref.31582, V1/15 - 16 - Distribuidor: DepoDent España depósito dental DepoDent España - 902 767 118 -...
  • Page 18 Durch drücken der beiden „Torque“ Tasten gleichzeitig. Check from the Software version Push both „Torque“ button at the same time. Service Manual TCM Endo R11, Ref.31582, V1/15 - 17 - Distribuidor: DepoDent España depósito dental DepoDent España - 902 767 118 - ventas@depodent.es...
  • Page 19 The display brightness is not possible to adjust over the menu. So is the writing not clear readably we must exchange the display complete. Here for we open careful four black plastic nuts. The display self is only clipped on the board. Service Manual TCM Endo R11, Ref.31582, V1/15 - 18 - Distribuidor: DepoDent España depósito dental DepoDent España - 902 767 118 -...

  • Page 20: Stk / Electrical Safety Test For Tcm Endo R11

    The measurement PE against the check point will fail (no current). This is the correct test result! If uncertainties about this topic exists please contact the Nouvag service center. 1. Power switch OFF. 2. Device disconnected from power.
  • Page 21 TCM Endo R11 Service Manual TCM Endo R11, Ref.31582, V1/15 - 20 - Distribuidor: DepoDent España depósito dental DepoDent España - 902 767 118 - ventas@depodent.es...
  • Page 22 TCM Endo R11 Beispiel Sicherheitstest / Sample from a printout safety test Service Manual TCM Endo R11, Ref.31582, V1/15 - 21 - Distribuidor: DepoDent España depósito dental DepoDent España - 902 767 118 - ventas@depodent.es...
  • Page 23 Review/Freigabe Bereich Name Datum Unterschrift Entwicklungsleiter Claudio Schmid Änderungsprotokoll Datum Version Autoren Modifikationen Seiten 26.11.2015 Erstellung Alles Service Manual TCM Endo R11, Ref.31582, V1/15 - 22 - Distribuidor: DepoDent España depósito dental DepoDent España - 902 767 118 - ventas@depodent.es...
