UTV Hopper Spreader
V-Pro™ SP-2000
Installation Instructions
CAUTION
Read this document before installing
or operating the spreader.
These Installation Instructions are for SnowEx
V-Pro SP-2000 UTV hopper spreaders
®
with serial numbers beginning with 160901 and higher.
A DIVISION OF DOUGLAS DYNAMICS, LLC
Advertisement
Table of Contents
Related Manuals for Douglas Dynamics SnowEx V-Pro SP-2000
Summary of Contents for Douglas Dynamics SnowEx V-Pro SP-2000
- Page 1 V-Pro™ SP-2000 Installation Instructions CAUTION Read this document before installing or operating the spreader. These Installation Instructions are for SnowEx V-Pro SP-2000 UTV hopper spreaders ® with serial numbers beginning with 160901 and higher. A DIVISION OF DOUGLAS DYNAMICS, LLC...
-
Page 3: Safety Definitions
SAFETY SAFETY DEFINITIONS WARNING/CAUTION LABELS Become familiar with and inform users about the WARNING warning and caution labels on the spreader. Indicates a potentially hazardous situation that, if not avoided, could result in death or NOTE: If labels are missing or cannot be read, see serious personal injury. -
Page 4: Serial Number Label
SAFETY ROTATING AUGER CAN CAUSE SERIOUS INJURY OR DEATH • Keep arms, hands, and loose clothing away from auger. • Shut off control and unplug spreader before servicing. D6335 SERIAL NUMBER LABEL Code Defi nition 2-Digit Year 2-Digit Month 2-Digit Day 2-Digit Location Code XXXX 4-Digit Sequential Number... -
Page 5: Safety Precautions
SAFETY SAFETY PRECAUTIONS CAUTION • Do not operate a spreader in need of Improper installation and operation could cause maintenance. personal injury and/or equipment and property damage. • Before operating the spreader, reassemble Read and understand labels and the Owner's Manual any parts or hardware removed for cleaning before installing, operating, or making adjustments. -
Page 6: Personal Safety
SAFETY PERSONAL SAFETY BATTERY SAFETY • Remove ignition key and put the vehicle in PARK CAUTION or in gear to prevent others from starting the Batteries normally produce explosive gases vehicle during installation or service. which can cause personal injury. Therefore, •... -
Page 7: Material Weights
LOADING These instructions cover vehicles that have been DETERMINING VEHICLE PAYLOAD recommended for carrying the hopper spreader. Please see your local dealer for proper vehicle applications. 1. Install the hopper spreader and optional equipment according to the instructions. WARNING 2. Install or attach any other equipment that will be Overloading could result in an accident or on the vehicle while the hopper spreader will be in damage. -
Page 8: Mounting The Spreader
MOUNTING THE SPREADER MOUNTING SPREADER 4. Install the chute/defl ector assembly to the spinner assembly using the four 5/16" x 1-1/2" tapping screws and 5/16" locknuts in the supplied NOTE: Periodically throughout the snow and ice hardware kit to complete the drive assembly. control season, verify that mounting devices are secure. - Page 9 MOUNTING THE SPREADER 8. Looking at the inside corners of the spreader NOTE: Pay special attention when drilling or frame, you will notice four holes in the bottom of clamping dissimilar metals to aluminum bodies. the frame. Using a paint pen or similar marking Galvanic corrosion can occur if not handled device, mark the hole locations on the vehicle bed.
-
Page 10: Wiring Instructions
WIRING AND HARNESS INSTRUCTIONS WIRING INSTRUCTIONS 5. Route the ignition wire and connect it. Consult UTV wiring diagram to locate a suitable ignition wire connection. Secure the harness from the rear 1. Remove the vehicle fl oor pan and battery cover. If to the battery using heavy-duty cable ties or frame possible, tip up the bed and lock it in place. - Page 11 WIRING AND HARNESS INSTRUCTIONS Vehicle Control Harness Installation 5. Push the ON/OFF switch on the control to check for power. After power has been confi rmed, push the ON/OFF switch again to turn the control Choose a mounting location where the control will OFF.
-
Page 12: Harness Wiring Diagram
HARNESS WIRING DIAGRAM Spreader Control 1/4" x 1/2" Cap Screw Control Mounting Bracket UTV Harness Spreader Harness Power Cable Lit. No. 76451/76452/76453, Rev. 04 February 24, 2020... -
Page 13: Harness Diagram
HARNESS DIAGRAM Spreader Harness Vibrator Auger Chute Vibrator POSITIVE (+) Vibrator NEGATIVE (–) Auger POSITIVE (+) Auger NEGATIVE (–) NEGATIVE (–) POSITIVE (+) Spinner POSITIVE (+) Spinner NEGATIVE (–) Load Load View View Control Vibrator Red POSITIVE (+) Vibrator Black NEGATIVE (−) Auger Black NEGATIVE (−) Auger... -
Page 14: Electrical Routing
ELECTRICAL ROUTING Under side of spinner and trough. Spinner Main Input Auger and vibrator not shown. Lit. No. 76451/76452/76453, Rev. 04 February 24, 2020... -
Page 15: Final Adjustments
FINAL ADJUSTMENTS FINAL CHECKLIST Verify that dielectric grease is applied to all electrical connections. Verify that wire harnesses and battery cables are properly secured away from sharp, hot, or moving parts. Verify that the vehicle wiring harness has suffi cient ground clearance when the spreader is removed from the UTV. - Page 16 A DIVISION OF DOUGLAS DYNAMICS, LLC Copyright © 2020 Douglas Dynamics, LLC. All rights reserved. This material may not be reproduced or copied, in whole or in part, in any printed, mechanical, electronic, fi lm, or other distribution and storage media, without the written consent of TrynEx International, LLC.
