- Page 1 Owner’s Manual Generationx2 SiriusXM Satellite Radio interface SXV300 SiriusXM Tuner required Model GSR-TY51 TOYOTA Copyright (C) 2003-2018 VAIS Technology Published April 28, 2018...
- Page 2 VAIS Technology, 8811 American Way, Englewood, CO 80112 www.vaistech.com Phone: 720-733-2348 info@vaistech.com...
- Page 3 Installation SiriusXM Source Selection User Interface - Channels, Presets, Categories Warranty...
- Page 4 Before You Start WARNING DO NOT DISASSEMBLE OR ALTER Doing so may result in an accident, fire or electric shock Do not block the airbag Do not mount product or any added audio and/or video equipment where it can obstruct the operation of any safety devices such as the airbag.
- Page 5 Installation What’s Included GSR-TY51 Interface Adapter Power and steering wheel control harness USB Connector Brown (M) to USB Connector Gray (M) cable Vehicle Antenna and SiriusXM Tuner SXV300 are included in GSR-TY51 SiriusXM Tuner Tuner Kit only SXV300 Vehicle Antenna GSR Connectors and Ports Model: GSR-TY51 Brown USB...
- Page 6 Installation Connecting GSR To SiriusXM Tuner SXV300 Brown Connector To USB Connector on the radio (gray connector) GSR Power Connector Factory USB Connector from the Radio (gray connector) Power/Steering Wheel Control Harness Connection To Radio Power Connector To Factory Radio Harness To Factory Power harness from the Radio To GSR...
- Page 7 SiriusXM Source Selection SETUP AUDIO SETUP AUDIO View all Audio Sources available...
- Page 8 SiriusXM Source Selection Touch to select “SiriusXM” Audio Source...
- Page 9 SiriusXM Source Selection SETUP SiriusXM AUDIO Mute/Unmute Tuning Knob - switch to next available channel, depending on direction of rotation. (Tuning knob may not be available while radio is loading channel list.) “Track Seek+” and “Track Seek-” switch to next available channel. Long Touch on “Track Seek+”...
- Page 10 User Interface - Channels, Presets, Categories 1 C 000 Radio ID ABCD1234 2 C 001 SiriusXM Preview Songs 3 C 002 Hits 1 4 C 003 Venus CH004 50s on 5 This list has all channels Artists 1 CH025 Classic Rewind 2 CH033 1st Wave Presets 3 CH002 Hits 1...
- Page 11 User Interface - Channels, Presets, Categories 11 Artists 1 CH019 Elvis 2 CH020 E Street Radio Tune Presets/Channels 3 CH021 Underground Garage Browse by Category 4 CH022 Pearl Jam Radio System Information Rock R&B Artists 1 SiriusXM Radio ID ABCD1234 Tune Presets/Channels Some radios require to “click”...
- Page 12 Warranty is available for download: To request a paper warranty copy please contact us: VAIS Technology Warranty Department 8811 American Way Unit 125 Englewood, CO 80112 720-733-2348 info@vaistech.com...
