- Page 1 Argos 3D - P33X Quick Start Guide Version 1...
- Page 2 This document is protected by copyright. All rights reserved. No part of this document may be reproduced or transmitted for any purpose in any form or by any means, electronically or mechanically, without expressly written permission by BECOM BLUETECHNIX GmbH. Windows is a registered trademark of Microsoft.
-
Page 3: Table Of Contents
Support website ........................8 Start-up screen ......................... 9 Prepare your Network Interface Card (NIC) ................10 Start using your Argos3D–P33X with ‘BltTofSuite’ ................ 11 System Requirements & Support ....................12 Support ........................... 12 Document Revision History ......................13 © BECOM BLUETECHNIX 2017... - Page 4 BECOM BLUETECHNIX takes no liability for any damages and errors causing of the usage of this product. The user of this product is responsible by himself for the functionality of his application. He is allowed to use the product only if he has the qualification.
-
Page 5: Unboxing
Argos3D–P33X sensor! Opening your Argos3D–P33X To access the connector compartment unscrew the two screws on the Argos3D-P33X front and take off the connector compartment lid. Figure 1-1: Argos3D–P33X connector compartment screw positions © BECOM BLUETECHNIX 2017 Page 5 | 13... -
Page 6: Connecting Your Argos3D-P33X
Modulation Light Interface k. Status LED Trigger Marks Pin #1 Figure 1-2: Argos3D–P33X connectors and interfaces Note Please follow the next steps in the right order to get your ‘Argos3D-P33X’ up and running correctly. © BECOM BLUETECHNIX 2017 Page 6 | 13... -
Page 7: Connecting The Power Supply
1.4.2 Connecting the Ethernet Cable Plug in the Ethernet cable (b) and connect your Argos3D–P33X to your PC. Figure 1-3: Argos3D–P33X with connected power supply and Ethernet cable © BECOM BLUETECHNIX 2017 Page 7 | 13... -
Page 8: Downloading The Evaluation Software
Downloading the Evaluation Software Please log in to our support website at https://support.bluetechnix.com/ and download the Argos-P33X customer software package. This package also includes the Bluetechnix ToF-Suite. Support website Select ‚free access‘ Figure 2-1: Download Evaluation Package © BECOM BLUETECHNIX 2017... -
Page 9: Start-Up Screen
Quick Start Guide - Argos 3D - P33X Last change: 22 June 2017 Version 1 Start-up screen Figure 2-2: Start-up screen Please select your product: Argos3D – P33X Please follow the instructions on the WEB-Site © BECOM BLUETECHNIX 2017 Page 9 | 13... -
Page 10: Prepare Your Network Interface Card (Nic)
Once you have connected your Argos3D–P33X to a Network Interface Card (NIC) of your PC give this NIC the IP-Address 192.168.0.1 with a subnet mask of 255.255.255.0. No driver must be installed on your PC! The Argos3D–P33X uses IP-Address 192.168.0.10 with subnet mask 255.255.255.0. © BECOM BLUETECHNIX 2017 Page 10 | 13... -
Page 11: Start Using Your Argos3D-P33X With 'Blttofsuite
Using this software you can simply display the depth image and the amplitude image of the Argos3D–P33X. For a detailed introduction to the software, please read the ‘Bluetechnix ToF Suite - Quick Start Guide’ Place the Argos3D–P33X on your desk approximately 50 cm in front of you. -
Page 12: System Requirements & Support
Dual-core 2 GHz or faster CPU Dedicated Ethernet port 2GByte RAM Support For answers to common questions, troubleshooting steps and further documentation visit our Bluetechnix support website or using the direct link: https://support.bluetechnix.at/wiki/Argos_3D-P33x © BECOM BLUETECHNIX 2017 Page 12 | 13... -
Page 13: Document Revision History
Quick Start Guide - Argos 3D - P33X Last change: 22 June 2017 Version 1 Document Revision History Version Date Document Revision 2017 06 22 Company information updated 2016 11 01 First draft Table 5.1: Revision history © BECOM BLUETECHNIX 2017 Page 13 | 13...
