Heat tracing kit to maintain temperature of 70 ºc on hoppers

Advertisement

Quick Links

E GB
7222H001 Ed.01
AKO-TOLVA
KIT PARA MANTENER LA TEMPERATURA DE 70 °C EN TOLVAS
KIT TO MAINTAIN TEMPERATURE OF 70 ºC ON HOPPERS
Índice
1- Utilización de estas instrucciones
2- Composición
3- Potencia e intensidad
4- Advertencias
5- Instalación
6- Verificaciones antes del calorifugado
1- Utilización de estas instrucciones
Estas instrucciones están concebidas únicamente, para la instalación, verificación y
Mantenimiento de sistemas de
TRACEADO eléctrico AKO-TRACE
®
eléctrico, con cables calefactores paralelo de potencia constante, en tolvas que disponen
de un aislamiento térmico. Rogamos nos consulten cualquier información relacionada con
otras aplicaciones.
2- Composición

/ Components

Cable calefactor 35 W/m a 230 V / Heating cable 35 W/m at 230 V
AKO-71035:
Rollo 50 m cinta adhesiva de aluminio / 50 m roll of aluminium adhesive tape
AKO-717440:
Soporte para cable calefactor / Support for heating cable
AKO-71630:
Termostato hasta 350 °C, relé 20 A SPST / Thermostat up to 350 °C, 20 A SPST relay
AKO-1530:
Sonda Pt 100, de -50 a 200 °C, 1.5 m / Pt 100 probe, from -50 to 200 °C, 1.5 m
AKO-15595:
Soporte fijación / Fixing support
AKO-717425:
Juego
etiquetas señalización
AKO-717445:
5
Tornillos / Screws
AKO-717440
AKO-717445
AKO-717425
2 Tornillos
2 Screws
7- Calorifugado (Aislamiento)
8- Verificaciones de puesta en marcha
9- Mantenimiento
10- Reparaciones
11- Guía para la detección y reparación
de averías
de calentamiento
Set of
signalling labels
AKO-TRACE /
5 AKO-TRACE
230 V
Index

1- Use of these instructions

2- Components
1- Use of these instructions
These instructions are only conceived to install, test and maintain, electrical heat tracing
®
TRACEADO eléctrico AKO-TRACE
systems, with constant wattage parallel heating
cables on hoppers that are usually thermal insulated. Please ask for any information about
other applications.
Kit
AKO-TOLVA-5M2
AKO-TOLVA-12M2
60 m
100 m
2
3
1
2
1
1
1
1
1
1
1
1
2
2
AKO-TOLVA-20M2
AKO-TOLVA-30M2
50 m + 100 m
100 m + 100 m
4
5
3
4
2
2
2
2
2
2
1
1
4
4
AKO-71035
AKO-71630
AKO-15595
AKO-1530
1.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AKO-TOLVA-5M2 and is the answer not in the manual?

Questions and answers

Summary of Contents for AKO AKO-TOLVA-5M2

  • Page 1 1- Use of these instructions Estas instrucciones están concebidas únicamente, para la instalación, verificación y These instructions are only conceived to install, test and maintain, electrical heat tracing mantenimiento de sistemas de TRACEADO eléctrico AKO-TRACE de calentamiento ® ® TRACEADO eléctrico AKO-TRACE systems, with constant wattage parallel heating eléctrico, con cables calefactores paralelo de potencia constante, en tolvas que disponen...
  • Page 2 - Asegurar que la tolva no tenga rebabas, superficies rugosas o aristas que pudieran dañar damage the cable. In that case, debur or cover them with AKO-717440 aluminium el cable, de existir, desbarbarlas o cubrirlas con la cinta adhesiva de aluminio AKO-717440. adhesive tape.
  • Page 3 5- Instalación / Installation 5.1- Montar soportes para cable calefactor / Fix supports fot heating cable: d < 1500 mm d < 1500 mm 5.2- Montar soporte para termostato / Fix support for thermostat: AKO-TOLVA-20M2 AKO-TOLVA-5M2 AKO-TOLVA-12M2 AKO-TOLVA-30M2...
  • Page 4 5.4- Instalar el cable calefactor / Install the heating cable: d (mm) Distancia/Distance Para superficie nominal Para otras superficies For nominal surface For other surfaces 16 x S AKO-TOLVA-5M2 10 x S AKO-TOLVA-12M2 S (m ): (mm) Superficie / 7 x S AKO-TOLVA-20M2...
  • Page 5 5.6- Instalar el sensor / Install the sensor: AKO-TOLVA-5M2 AKO-TOLVA-20M2 AKO-TOLVA-12M2 AKO-TOLVA-30M2 Fijar el sensor de temperatura Fijar el sensor de temperatura con la cinta adhesiva de con la cinta adhesiva de aluminio aluminio AKO-717440 AKO-717440 Fix the temperature sensor with...
  • Page 6 La reparación de un cable calefactor, sólo debe hacerse con los kits y componentes A heating cable should be repaired with original AKO kits and components according to originales AKO, respetando las instrucciones que en ellos se suministran. Se procederá...
  • Page 7 Ficha de ensayo y verificación / Test and check sheet Fecha / Date: Fecha / Date: Fecha / Date: Antes del calorifugado Resistencia de aislamiento a 1000 V= Before lagging Insulation resistance at 1000 V= Resistencia eléctrica Electric resistance Puesta en marcha Resistencia de aislamiento a 1000 V= Start-up Insulation resistance at 1000 V=...
  • Page 8 Av. Roquetes, 30-38 | 08812 Sant Pere de Ribes | Barcelona | España AKO ELECTROMECÀNICA, S.A.L. Tel. (34) 938 142 700 | Fax (34) 938 934 054 | e-mail: ako@ako.com | www.ako.com Nos reservamos el derecho de suministrar materiales que pudieran diferir levemente de los Apartado (P.O.
