MAINTENANCE OF THE
HAND-OPERATED SIMPLE PUMP
LAST UPDATED: June 25, 2018
If you are a homeowner, you must have a helper for uninstalling or installing any pump.
READ EACH SECTION CAREFULLY BEFORE PROCEEDING.
FOLLOW INSTRUCTIONS STEP BY STEP.
Pay particular attention to anything marked ***.
(The following instructions should tell you everything you need
to know. If you have questions, please phone 775-267-1093.)
SIMPLE PUMP COMPANY
2516 Business Par kway, Unit B / Minden, NV 89423 / USA
Phone: 877-492-8711 (toll free) or 775-267-1093
Mon-Fri: 8am-5pm PST (GMT/UTC -8hours)
Fax: 888.826.1444 (toll-free)
www.simplepump.com
1
