- Page 1 Retractable Hose Reel 15M/25M Models Instruction Manual Installation, Hose Replacement, Care & Troubleshooting 1215H – Product Dimensions(mm): W:430 H:370 L:180 Weight: 7.00kg 1225H – Product Dimensions(mm): W:440 H:410 L:220 Weight: 10.6kg...
- Page 2 Introduction Thank you for purchasing this HOLMAN Retractable Hose Reel. This product uses a 12mm reinforced hose for added strength and durability, and includes a multi-function hose gun. (Hose Gun styling is subject to change) For your information, please read these installation instructions before using the Retractable Hose Reel.
- Page 3 It is very important to use the correct size drill bit, 15m/25m (1215H/1225H) so a very secure fit of the wall bracket is made before installing the Retractable Hose Reel.
- Page 4 Retractable Hose Reel - Instruction Manual Place the bracket in position over the four wall plugs and screw each hexagonal coach bolt into your wall or wooden post. Screw in each bolt until all four have a secure hold on the bracket against the surface.
- Page 5 Hose Replacement - 1215H/1225H Models Hose Replacement Guide Lift the viewing panel to see the locking bars in Before placing the locking bars in the auto a secure position, having pulled the hose out to wheel, remove the viewing panel for ease of its limit (retraction wheel must lock so the hose access.
- Page 6 Hose Replacement - 1215H/1225H Models Hose Replacement Guide Unscrew the clamp holding the hose in place on Ensure you fully unscrew both sides of the the auto retraction wheel. clamp before proceeding. Keep the clamp and screws together away from Detach the hose connector from the ‘quick...
- Page 7 Hose Replacement - 1215H/1225H Models Hose Replacement Guide Unscrew the hose connector from the hose, Pull the old hose back through the auto ensuring you keep all the parts together. retraction guide hole, ready to fit the new hose. Feed the new hose through the guide hole Connect the clip back onto the fitting and ready to attach the hose connector.
- Page 8 Hose Replacement - 1215H/1225H Models Hose Replacement Guide - 15m & 25m only Repeat the hose removal process in reverse. Take the locking bars out of the retraction Attach the hose connector, plug the hose wheel and secure them inside the hose connector on to the white plastic adaptor and wheel unit.
- Page 9 Care & Troubleshooting Locking bars in the CORRECT position, You will find an indication sticker 1 metre before the maximum length. Do not pull the hose past clipped to the outer casing. this point (unless when replacing the hose). When walking the hose back to the unit, turn off the tap, press the lever on the watering gun to release the water pressure in the hose.
-
Page 10: Spare Parts
Spare Parts Plastic wall bracket Tap to reel hose Mounting Tube Hose stopper To order spare parts please call our customer service team on 1300 716 188. - Page 11 Notes...
- Page 12 1300 716 188 or visit www.holmanindustries.com.au Holman offer a 2 year replacement warranty from the original date of purchase. To claim warranty the product must be returned to the place of purchase with a copy of the original receipt.
