  • Page 1 User's Manual Turbidity/TSS/MLSS Controller Headquarters 5th floor,Building 4,Singapore Hangzhou Science Technology Park,No. 6 street, Hangzhou Economic Development Area,Hangzhou 310018,China Singapore 2 Venture Drive #11-30 Vision Exchange Singapore Philippines Majestic Subdivision, Lot 1, 1800 Rainbow St, Marikina, 1811 Metro Manila, Philippines info@supmea.com...
  • Page 2 Preface Thank you for purchasing . Please Turbidity/TSS/MLSS controller read this manual carefully before operating and using it correctly to avoid unnecessary losses caused by false operation. Note Modification of this manual’s contents will not be notified as a result of some factors, such as function upgrading.
  • Page 3 Safety Precautions In order to use this product safely, be sure to follow the safety precautions described here. About this manual Please submit this manual to the operator for reading. Please read the operation manual carefully before applying the instrument. On the precondition of full understanding. This manual only describes the functions of the product.
  • Page 4 If you need to replace parts of the product, please use the model specifications specified by the company. This product is not intended for use in systems that are directly related to personal safety. Such as nuclear power equipment, equipment using radioactivity, railway systems, aviation equipment, marine equipment, aviation equipment and medical equipment.
  • Page 5 Thunder prevention engineering facilities must be well managed: the shared grounding network shall be grounded at is-electric level, shielded, wires shall be located rationally, SPD surge protector shall be applied properly. Some inner parts may carry high voltage. Do not open the square panel in the front except our company personnel or maintenance personnel acknowledged by our company, to avoid electric shock.
  • Page 6 Please strictly follow the instructions in this manual,  otherwise the product's protective device may be damaged. Do not use the instrument if it is found damaged or deformed at opening of package. Prevent dust, wire end, iron fines or other objects from entering the instrument during installation, otherwise, it will cause abnormal movement or failure.
  • Page 7 After opening the box, please confirm the package contents before starting the operation. If you find that the model and quantity are incorrect or there is physical damage in appearance, please contact us. Chart 1 Product contents Item Quantity Remarks Turbidity/TSS/MLSS sensor Turbidity/TSS/MLSS controller Manual Certificate...

  • Page 8: Table Of Contents

    Contents Chapter I Introduction................. 1 1.1.Turbidity/TSS/MLSS sensor..............1 1.2.Turbidity/TSS/MLSS controller............2 Chapter II Installation..................4 2.1.Instrument installation................. 4 2.2.Sensor installation................6 2.3.Instrument wiring.................7 Chapter III Key Operation................9 Chapter IV System menu................11 Chapter V Communication................17 Chapter VI Calibration of MLSS/TSS............20 Chapter VII Maintenance................22...

  • Page 9: Chapter I Introduction

    ISO7027 method can be used to accurately determine the turbidity, TSS and MLSS. The main parameters of the sensor showed as table 2: Table 2 the main parameters of the Turbidity/TSS/MLSS sensor Dimension 60mm*256mm (D*L) Weight 1.65KG...

  • Page 10: Turbidity/Tss/Mlss Controller

    10m standard cable, can be extended up to 100m Sensor dimension 1.2.Turbidity/TSS/MLSS controller This Turbidity/TSS/MLSS controller is a smart online chemical analyzer, widely used in Thermal power, chemical fertilizer, metallurgy, environmental protection, pharmaceutical, biochemical, food, tap water and other industries.
  • Page 11 Chapter I Introduction Measuring Turbidity/TSS/MLSS variable Turbidity ： 0.00 ~ 4000NTU Measuring range TSS/MLSS ： 0.1 ~ 20000 mg/L 、 0.1 ~ 45000 mg/L 、 0.1 ~ 120000 mg/L Turbidity ： < ± 2% FS or ± 0.1NTU (max value) Accuracy MLSS/TSS ：...

  • Page 12: Chapter Ii Installation

    Chapter II Installation Chapter II Installation 2.1.Instrument installation Specify the installation site and installation method of this instrument. Please be sure to read this part when installing. Notes for installation The instrument is panel mounted. Please install it indoors and avoid wind and rain and direct sunlight. Please install it in a well-ventilated place to prevent rise of the internal temperature of this instrument.
  • Page 13 Chapter II Installation Figure 1 Figure 2 Insert the instrument into the mounting hole and then buckle up the butterfly style buckle ， as figure 3 showed ： Figure 3...

  • Page 14: Sensor Installation

    Chapter II Installation 2.2.Sensor installation Install steps Specific install steps showed as figure 4: 1. Use 1 (M8U buckle) to fix 8 (installation panel) on the pipe near the pool where the sensor is installed. 2. Connect 9 (converter) and 2 (DN40) PVC pipe with glue, and put the sensor cable through PVC pipe, screw the sensor into 9 (converter), and make sure that water resistance have been done.

  • Page 15: Instrument Wiring

    Chapter II Installation Table 4 accessories of sensor installation 1 、 M8 U shape buckle (DN60) 2 、 DN40 pipe 3 、 Hexagon socket bolt M6*120 4 、 DN42 U-shape pipe clip 5 、 M8 Gasket (8*16*1) 6 、 M8 Gasket （ 8*24*2 ） 7 、...
  • Page 16 Chapter II Installation 485A+: RS485 communication interface A ﹢ 485B-: RS485 communication interface B ﹣ I+: 4-20mA output + I-: 4-20mA output - HO: High alarm normally open HC: High alarm normally closed COM: Common terminal LO: Low alarm normally open relay LC: Low alarm normally close relay COM: Common terminal 220V L: AC220V live wire...

  • Page 17: Chapter Iii Key Operation

    Chapter III Key Operation Chapter III Key Operation Key locations Figure 6 Key definition Table 5 Sign Name of the key Function description Enter the menu under the "Monitoring Interface" MENU Exit the menu under the "Menu Interface" View the related alarm state under the "Monitoring Interface"...
  • Page 18 Chapter III Key Operation under the "Monitoring Interface" Select the related menu under the "Menu Interface" DOWN Modify the relative values in the setting status Enter the submenu or confirm the ENTER modification under the "Menu Interface"...

  • Page 19: Chapter Iv System Menu

    Chapter IV System menu Chapter IV System menu Turbidity Monitoring screen Figure 7 MLSS/TSS Monitoring screen Figure 8 bottom to enter password page, enter the correct password to enter main menu. bottom to enter alarm page, to see the current setting of alarm.
  • Page 20 Chapter IV System menu Password verification screen Figure 9 The initial password is 0000, which can be modified by using the change password function. Main menu screen Figure 10 System Setting: Setting of language, buzzer and backlight. Signal Setting: Electrode switching, and setting of turbidity and MLSS/TSS factors, scraping and response time.
  • Page 21 Chapter IV System menu System Setting Figure 11 Language: Chinese or English. Buzzer: ON/OFF setting Backlight setting:ON/OFF setting Change Password: password modification and log-in with new password. Factory setting: return to factory settings Signal Setting Figure 12 Electrode Switch: Switching the electrode type, turbidity or MLSS/TSS. TUR Factor: Setting the turbidity factor in the range of 0.1 ～...
  • Page 22 Chapter IV System menu MLSS Factor: Setting the MLSS/TSS factor in the range of 0.1 ~ 10. Response Time: Setting the signal response time in the range of 1 ～ 60s. Brush Time: Setting the time interval for electrode scraping (1, 5, 15, 30, 60(1h), 240(4h), 720(12h), 1440(1D), 4320(3D), 10080(7D) in min).
  • Page 23 Chapter IV System menu Alarm Setting Figure 15 TUR High Alarm: When the measured value is larger than the high alarm pick-up value, the high alarm relay is picked up and when the measured value is less than the high alarm breaking value, the high alarm relay is disconnected.
  • Page 24 Chapter IV System menu Version Query Figure 16 Version Query: Query the current hardware and software version.

  • Page 25: Chapter V Communication

    Chapter V Communication Chapter V Communication The instrument provides a standard RS485 serial communication interface, and uses the general international standard MODBUS - RTU communication protocol. MODBUS standard format (No. 03 reading and holding register command) Command format: Table 6 Command format Function Register Data...
  • Page 26 Chapter V Communication Turbidity value (in NTU, the 0x0000 long 4 bytes 0x03 obtained value Read-only needs to be divided by 100). MLSS/TSS value (in mg/L, the obtained 0x0002 long 4 bytes 0x03 Read-only value needs to be divided by Example of turbidity reading: Sent from computer: 00 03 00 00 00 02 C5 DA Returned by dissolved oxygen meter: 00 03 04 00 00 00 00 EA F3...
  • Page 27 Chapter V Communication 04 is the data length of returned MLSS/TSS value, which is 4 bytes; 00 00 00 00 is the returned MLSS/TSS value 0.0mg/L, and the obtained value divided by 10 is the current MLSS/TSS value. The range is 0.0-120000mg/L;...

  • Page 28: Chapter Vi Calibration Of Mlss/Tss

    Chapter VI Calibration of MLSS/TSS Chapter VI Calibration of MLSS/TSS The MLSS/TSS sensor has been factory calibrated before delivered, and the self-calibration can be carried out according to the following steps if required. The use of standard liquid is required for the calibration of the MLSS/TSS , taking two-point calibration as an example: 1.
  • Page 29 Chapter VI Calibration of MLSS/TSS The four-point correction step is basically the same as the two-point correction, and the selection of the correction points can be determined according to the actual measurement environment. They are usually the zero point, 0.25 times the range point, 0.5 times the range point and the full range point.

  • Page 30: Chapter Vii Maintenance

    Chapter VII Maintenance Chapter VII Maintenance Cleaning of sensors Two lenses on the sensor need to be cleaned. Please regularly carry out cleaning and maintenance in accordance with actual use to ensure the accuracy of the measurement. Rinse it with clean water first and then wipe it with cleaners and rag to remove stubborn stains.

  • Page 31: Chapter Viii Troubleshooting

    Chapter VIII Troubleshooting Chapter VIII Troubleshooting 1. No display of the controller? A: Check whether the power line is connected correctly and whether the power supply is connected. 2. Displaying figures jumping up and down? A: Check whether there is any interference equipment such as the frequency converter.
