Summary of Contents for FE Powertools FE 30
-
Page 2: Table Of Contents
Table of contents 1. Table of contents 2. Instructions Before Use - Safety Warning Explanation 3. Technical overview / Before Use: Fundamental Safety Precautions 4. Operating manual 4.1 Hole cutter selection 4.2 How to mount tools or adapters in a Weldon arbor 4.3 Drilling with hole cutters 4.4 Drilling with twist drills 4.5 Speed and/or torque setting... -
Page 3: Instructions Before Use - Safety Warning Explanation
2. Instructions Before Use - Safety Warning Explanation Safety Warning Explanation Following warnings are present in this manual DANGER A warning of this category draws attention to an impending dangerous situation. If the dangerous situation is not avoided, it may lead to serious injury or even death. ... - Page 4 NOTE If used commercially, pay attention to compliance with the accident prevention regulations and the Safety at Work Ordinance. Liability Disclaimer All technical information, data and instructions for commissioning, operation and care of the machine contained in these operating instructions represent the latest status at the time of printing.The manufacturer assumes no liability for damage or injury resulting from failure to observe the operating instructions, use for other than the intended purpose, unprofessional repairs, unauthorised modifications or use of non-approved spare parts and accessories, tools and lubricants.
-
Page 5: Technical Overview / Before Use: Fundamental Safety Precautions
Technical overview / Before Use: Fundamental Safety Precautions... - Page 6 Fundamental Safety Precautions Do not use the machine in flammable or potentially explosive environments. Persons who due to their physical, mental or motor response abilities are unable to operate the machine safely may only use the machine under supervision or instruction by a responsible person. ...
- Page 7 WARNING Improper handling of the machine increases the risk of injury! Observe the following safety precautions to avoid injuring yourself and/or others: Operate the machine only with the protective equipment stipulated in these operating instructions (see section Personal protective equipment). ...
- Page 8 Installed Safety Features Restart Protection NOTE The machine stops automatically of the magnetic clamp is switched off or in the event of a power failure. In order to prevent unexpected starting of the machine when the magnetic clamp is switched on again or when the power supply returns after a power failure ("restarting protection"), the machine must be switched on at the ON/OFF switch again.
- Page 9 Personal Protective Equipment Wear the following protective equipment at all times when working with the machine: Symbol Meaning Close-fitting work protection clothing with a low tearing resistance Goggles for protecting eyes against flying parts and liquids and ear protection in areas with noise emission >80 dB(A) Safety shoes to protect the feet from falling objects Wear the following additional protective equipment during special operations...
-
Page 10: Hole Cutter Selection
4.1 Hole cutter selection Before starting to drill make sure the cutter of your choice is the right one for the job you want to do. Following cutters are available in the Fe Powertools program:... -
Page 11: How To Mount Tools Or Adapters In A Weldon Arbor
4.2 How to mount tools or adapters in a Weldon arbor? WARNING Risk of injury from incorrectly inserted tool or tool mounting . Check by briefly turning the tool whether the collet is engaged. 1) Make sure the machine is disconnected from the power supply. 2) Put the center pilot in the cutter hole. - Page 12 Fill the arbor with lubrification/cutting oil in the special meant holes. Always use cutting oil from your dealer. Set the right RPM by adjusting the gear switch and/or variable speed control.. The gear switch can be found on the side of the gear box. CAUTION ...
-
Page 13: Drilling With Twist Drills
4.4 Drilling with twist drills There are several accessories available to be able to use twist drills with your magnetic drill. Adapter Morse taper 2 – B16 taper connection Adapter Morse taper 2 – B18 taper connection These taper adapters will allow you to attach a drill chuck on to the hole cutter arbor. Model FE 50 X is equipped with a Weldon Morse taper adapter. - Page 14 1.5 Speeds and Settings Fe Powertools magnetic drills are provided with following speeds (load) FE 30 460 min FE 32 X 460 min FE 50 X 250 min 450 min FE 50 X 50-250 min 100-450 min FE 60 RLX...
- Page 15 5. Blockage WARNING Risk of injury from incorrectly inserted tool or tool mounting . Check by briefly turning the tool whether the collet is engaged. Blockages caused by a broken tool: Switch off the machine. Remove plug from the mains socket. ...
- Page 16 Tighten the adjusting screws uniformly. Tighten the clamping bolts again. Replacing the carbon brushes Replacement of the carbon brushes may only be carried out by Fe Powertools or by an authorised repair workshop. Unauthorised repairs will void the warranty. After-Sales Service/Service Should you have any questions about after-sales service or service, please contact Fe Powertools.
- Page 17 Troubleshooting Faults - causes and remedies NOTE If you cannot resolve the problem with the steps described above, please contact After- Sales Service. Fault Possible cause Remedy Plug not inserted into socket. Insert plug. Automatic circuit breaker Switch on the automatic circuit breaker again. tripped.
- Page 18 Storage/disposal If you do not intend to use the machine for a longer period of time, clean it as described in chapter Cleaning. Store the machine and all the accessories in the transport case in a dry, clean and frostfree location.
- Page 19 Magnetic core drilling machine Model: Type: FE 30 – FE 32 X - FE 36 S - FE 50 X – FE 50 RLX – FE 100 R/L Conforms to the following relevant regu lations: ■ EC Directive 2006/42/EC on Machinery The following harmonised standards were applied in whole or in part: ●...
Need help?
Do you have a question about the FE 30 and is the answer not in the manual?
Questions and answers
Здравствуйте, какая защита на данном станке при заклинивании сверла в металле и где она расположена
The FE Powertools FE 30 has two safety features related to drill jamming:
1. Restart Protection – Located in the machine's control system. If the magnetic clamp is switched off or there is a power failure, the machine stops automatically and does not restart until the ON/OFF switch is manually turned on again.
2. Thermal Overload Protection – Integrated into the motor. If the machine overheats, it shuts off automatically. To resume operation, remove any blockages and let the machine run at no-load speed for about 2 minutes.
This answer is automatically generated
Здравствуйте, подскажите пожалуйста характеристики кнопок включения и выключения.чтобы заменить сломанные
