do not use the wrench unless you have been instructed in its use by a qualified person.
8
do not operate the wrench where there are solvent fumes or flammable gases, liquids or solids.
8
do not leave the wrench operating unattended.
8
do not carry wrench with your finger on the trigger. Keep direction switch in 'locked' position when not in use.
8
do not use the wrench for a task it is not designed to perform.
8
do not operate the wrench when you are tired or under the influence of alcohol, drugs or intoxicating medication.
8
do not get the wrench or battery charger wet or use in damp or wet locations.
8
Keep wrench and charger in the case and store in a safe, dry, childproof area where the temperature will not exceed 104°F (40°C)
9
1.3.

battery safety

Charge the battery pack prior to first use. The battery pack will have been shipped in a low charge state.
9
use only the charger provided to charge the battery pack.
9
do not charge the battery pack when room temperature is below 50°F (10°C) or above 95°F (35°C).
8
do not attempt recharging the pack by means of an engine generator or a dc power source.
8
do not short-circuit the battery pack by touching both terminals at the same time with a metal object, or your fingers etc.
8
do not store battery pack or tool in locations where the temperature may exceed 104°F (40°C ) e.g. in sheds, above heaters etc.
8
▲ danGer! do not attempt to dismantle the battery pack. for safety and environmental reasons do not discard in domestic
waste or by burning. onlY discard or recycle according to local authority regulations.
warninG! do not allow a leaking battery to contact your person. in case of contact with battery liquid take the following
8
immediate action:
a) Skin contact: Wash immediately with cool, clean running water for at least 15 minutes.
b) Eye contact: If acid enters eye, flush eye immediately with cool, clean running water for at least 15 minutes and seek immediate
medical attention.

2. introduction

Powerful compact cordless impact wrench with forward and reverse control integrated into the housing for ease of use. Produces up to
650Nm (480lb.ft) torque, making this tool one of the most powerful available on the market. Suitable for removing the most stubborn wheel
nuts. features battery condition indicator, integral led work light and variable speed control switch for added control. suitable for workshop,
bodyshop, and tyre shop applications. Supplied with two 18V Lithium-ion battery packs, and 90 minute mains charger.

3. specification

model number........................................................... CP3005
Battery ............................................................18V 4Ah Li-ion
drive ........................................................................... 1/2"Sq
no load speed ........................................................ 1900rpm
impact rate ............................................................. 2200bpm
maximum torque ......................................... 650Nm (480lb.ft)
1
2
3
4
7
7
8
1 ..................................................................................... Anvil
2 ........................................................................... Anvil collar
3 ...................................................................... LED Worklight
4 ..................................................................................trigger
5 ....................................................Forward/Reverse Selector
6 .........................................................................Battery Pack
7 .......................................................Battery Release Buttons
8 .........................................................charge indicator Panel
© Jack sealey limited
Replacement Battery ...................................................CP3005BP4
Weight .......................................................................................3kg
Noise Power ..................................................................... 112db(A)
Noise Pressure .................................................................101db(A)
Vibration ............................................................................15.3m/s
Uncertainty ......................................................................... 1.5m/s
5
3
6
Original Language Version
fig.1
cP3005.V2 | Issue 3 08/03/17
