- Page 1 USER RP·TROTTER MANUAL TROTTER E·SCOOTER...
-
Page 2: Table Of Contents
IMPORTANT NON-COMPLIANCE WITH SAFETY INSTRUCTIONS COULD CAUSE SERIOUS BODY DAMAGE AND IN EXTREME CASES, DEATH. WELCOME Thank you for your purchase of the Roller-Pro Trotter E-Scooter! The Roller-Pro Trotter E-Scooter takes the power of electricity, the style of a traditional scooter, adds them together, and tops it off with a bit of swag. To ensure your safety and the safety of others, please read and follow the guidelines in this user manual carefully and thoroughly before and during riding. -
Page 3: General Information
GENERAL INFORMATION Before operating this vehicle, please read all instructions. This manual will guide you through the functions, usage, and proper care of your Roller-Pro Trotter E-Scooter. If you have any questions or cannot find the information you need in the manual, please contact your place of purchase or our customer service center. - Page 4 Keep the packaging in a safe place in case it needs to be used later for transportation. Verify that all parts of the product are available. If any part is missing, contact Roller Pro customer service center. If any ports or cables or surrounding parts are damaged, do not use the product.
- Page 5 Do not attempt to open or modify your Trotter E-scooter as doing so will void the manufacturer´s warranty and could lead to serious injuries or death. Do not use your Trotter E-scooter in situations or places where you can cause danger or an accident to people around you. Never ride your Trotter E-scooter under the influence of drugs or alcohol.
- Page 6 Do not ride your Trotter E-scooter while talking on the phone, writing a message or conversing with someone. This could cause an accident. Do not ride your Trotter E-scooter on highways, bicycle lane, bus lane, near cars. It is important you check the local laws before starting to use your E-scooter.
- Page 7 Always calculate the distance required for braking. The Trotter E-scooter employs an electronic brake which reacts gradually. Therefore, it is extremely important to apply the brakes on time in order to avoid any collision. Do not ride your Trotter E-scooter in dark areas where there is no light.
-
Page 8: Main Specifications
of the entire unit at or through an e-waste recycling center, program, or facility. Local regulations and laws pertaining to the recycling and disposal of lithium-ion batteries and/or products containing them will vary according to country, state, and local governments. You must check laws and regulations corresponding to where you live in order to dispose of the battery and/or unit properly. - Page 9 Maximum speed 24 km/h Range 8 - 12 Km Maximum incline 15° Operating temperature 0 °C to +40 °C Storage temperature -10 °C to 40 °C Protection class IP54 Battery voltage 25,2V. - 4.0Ah Maximum Output voltage DC 29,4V. 1.5Ah Rated capacity 101 w/h Motor power...
-
Page 10: Parts & Features
local, state and federal laws in regards to recycling, handling and disposing of Lithium Ion batteries. The scooter should only be shipped in its original packaging. Do not throw away your box as you need you scooter packaging for future use. PARTS &... -
Page 11: Control Panel
CONTROL PANEL Increase speed level + Power key Switch display mode Reduce speed level - Speed range 1: 1-5 km/h Speed range 2: 5–15 km/h Speed range 3: 15–24 km/h... -
Page 12: Folding & Assembly
FOLDING & ASSEMBLY Make sure the Roller-Pro Trotter E-scooter is turned off before working with any of its parts. The scooter comes mostly assembled within the package. Some minor assembly is required before riding. All parts and tools are included. Assembling: Install the Handlebars and tighten the handles. - Page 13 Height-limit button Close the lock buckle. Note: The extensive height is prohibited to exceed the first upper Limit hole. Limit ball must be perfectly placed into the limit hole when the extensive height is finalized. Before riding, it's a must to fasten lock buckle first. Any operation violating above instructions causes falling down by the loose front pole.
-
Page 14: Charging The Battery
CHARGING THE BATTERY Ensure the scooter is turned off before proceeding to charge the battery. Locate the charging port on the bottom part of the scooter. Use the supplied charger to connect it to the charging port and to the wall outlet. While the scooter is charging, the adaptor indicator light will turn red. -
Page 15: Usage
USAGE Read the following information before attempting to ride your Roller-Pro Trotter E-scooter. The Roller-Pro Trotter E-scooter supports up to 90Kg. Do not carry passengers. Only operate the Roller-Pro E-scooter where permitted. Local laws may restrict where you may ride. Please consult your local area laws and restrictions. The Roller-Pro Trotter E-Scooter contains a motor and may be classified as a motor vehicle under local laws in your area. - Page 16 brake does not work properly. DO NOT step on rear brake for a long time as it will tear the tire and break the fender. Step 5: Turn off the scooter when finish using the product. Power key Light function The front light includes 3 different light modes.
-
Page 17: Maintenance
Speed and Driving Style: Maintaining a moderate speed will increase your distance; while travelling at high speeds for extended periods, frequent starts, stops, idling, along with frequent acceleration and deceleration will reduce your overall distance. MAINTENANCE Do not perform any maintenance when the power is on, or the battery is charging. After each ride, especially if you have travelled a long distance, inspect your scooter. - Page 18 must bring the scooter into a warmer environment before charging. Check under Battery Information and Specifications for more details. To prevent dust from getting into your scooter, try wrapping it or sealing it with its original packaging. Store your scooter indoors, in a dry and suitable temperature. Battery maintenance: Do not use third party batteries;...
-
Page 19: Declaration Of Conformity
Camarma de Esteruelas, 28816 Madrid Tel: 902 430 967 Fax: 91 8864285 NIF: B83254763 Manufacturing country: China Description: Roller-Pro Electric Bike Roller Pro® RP-TROTTER complies with the following directives: EMC Standards: Directive 2014/30/UE EN55014-1: 2017 EN55014-2: 2015 EN6100-3-2: 2014 EN6100-3-3: 2013... - Page 20 Directive : 2013/56/EU Signed: Ajeet Nebhwani Utamchandani Sole Administrator www.rollerpro.es...
