GENERAL
The Yamatake-Honeywell EC7890A,B/RM7890A,B is a micro-
processor based integrated burner control for automatically fired
gas, oil or combination fuel single-burner applications. Except where
necessary, the relay module will be called the 7890A,B throughout
this publication. The 7890A,B consists of the Relay Module.
Subbase and Amplifier are required to complete the system. Options
include Keyboard Display Module, Personal Computer Interface,
DATA CONTROLBUS MODULE™, Remote Display Module and
COMBUSTION SYSTEM MANAGER® Software.
The 7890A,B is programmed to provide a level of safety,
functional capability and features beyond the capacity of
conventional controls.
Functions provided by the 7890A,B include automatic burner
sequencing, flame supervision, system status indication, system
or self-diagnostics and troubleshooting.
FEATURES
Safety features:
- Dynamic self-check logic.
- Internal hardware status monitoring.
- Tamper resistant timing and logic.
Access for external electrical voltage checks.
Application flexibility.
Communication interface capability.
Dependable, long-term operation provided by
microcomputer technology.
® U.S. Registered Trademark
Copyright © 1996 Honeywell Inc. • All Rights Reserved
7800 SERIES EC7890A,B/
RM7890A,B Relay Module
First-out annunciation and system diagnostics are
provided by a 2 row by 20 column Vacuum Fluorescent
Display (VFD) located on the optional Keyboard
Display Module.
Five (LEDs) for sequence information.
Interchangeable plug-in flame amplifiers.
Local or remote annunciation of 7890 operation and fault
information (optional).
Nonvolatile memory; 7890 retains history files and
sequencing status after loss of power.
Remote reset (optional).
Report generation (optional).
Selectable relight or lockout on loss of flame.
Shutter drive output (EC7890B, RM7890B).
Burner controller data (optional):
- Expanded annunciator status.
- Flame signal strength.
- Hold status.
- Lockout/alarm status.
- Sequence status.
- Sequence time.
- Total cycles of operation.
- Total hours of operation.
- Fault history providing the six most recent faults:
- Cycles of operation at the time of the fault.
- Fault message and code.
- Hours of operation at the time of the fault.
- Sequence status at the time of the fault.
- Sequence time at the time of the fault.
- Diagnostic information:
- Device type.
- Flame amplifier type.
- Flame failure response time.
- Manufacturing code.
- On/Off status of all digital inputs and outputs.
- Software revision and version of 7890 and optional
Keyboard Display Module.
- Status of configuration jumpers.
General ....................................................................................
Features ...................................................................................
Specifications ...........................................................................
Ordering Information ................................................................
Principle Technical Features ....................................................
Safety Provisions .....................................................................
Installation ................................................................................
Wiring ....................................................................................... 11
Assembly ................................................................................. 14
Operation ................................................................................. 17
Static Checkout ........................................................................ 18
Checkout .................................................................................. 20
Troubleshooting ....................................................................... 26
PRODUCT DATA
Contents
1
1
2
2
8
8
9
65-0204-1

Advertisement

Table of Contents
loading

Summary of Contents for Yamatake-Honeywell 7800 Series

  • Page 1: Table Of Contents

    GENERAL — Lockout/alarm status. — Sequence status. — Sequence time. The Yamatake-Honeywell EC7890A,B/RM7890A,B is a micro- — Total cycles of operation. processor based integrated burner control for automatically fired — Total hours of operation. gas, oil or combination fuel single-burner applications. Except where —...
  • Page 2 Can also be 65 VA pilot duty with motorized valve, 1150 VA inrush, 460 VA open, 250 VA hold. ORDERING INFORMATION When purchasing replacement and modernization products from your 7800 SERIES distributor, refer to the TRADELINE® Catalog for complete ordering number.
  • Page 3 7800 SERIES EC7890A,B/RM7890A,B RELAY MODULE Table 1B. EC7890 Terminal Ratings. Terminal No. Description Ratings Flame Sensor Ground Earth G Earth Ground L2(N) Line Voltage Common Line Voltage Supply (L1) 200 Vac (+10/-15%), 50 or 60 Hz (+/- 10%). Alarm 200 Vac, 1A pilot duty.
  • Page 4 7800 SERIES EC7890A,B/RM7890A,B RELAY MODULE Table 2. Flame Detection Systems. Plug-in Flame Signal Amplifiers Applicable Flame Detectors Flame Failure Response Type Color Self-Checking Model Time Fuel Type Models Rectification Green R7847A .8 or 3 sec Rectifying Flame C7004, C7007, C7011.
  • Page 5 7800 SERIES EC7890A,B/RM7890A,B RELAY MODULE Sequence Timing for Normal Operation: Device Initiate Standby PilotFlame Establishing Period 7890A 10 sec 4 or 10 sec * STANDBY and RUN can be an infinite time period. Approvals: Accessories: RM7890: Optional: Underwriters Laboratories Inc. Listed, File No. MP268, COMBUSTION SYSTEM MANAGER™, part no.
  • Page 6 7800 SERIES EC7890A,B/RM7890A,B RELAY MODULE BURNER CONTROL (127) POWER PILOT FLAME MAIN ALARM RESET 6-3/32 (155) 5 (127) REMOVE ONLY FOR TERMINAL TEST ACCESS. M11134 Fig. 2. Mounting dimensions of 7890 Relay Module and Q7800B Subbase in in. (mm). IGNITION MOUNTING FLANGE 3/4–14 NPT...
  • Page 7 7800 SERIES EC7890A,B/RM7890A,B RELAY MODULE 4-1/8 (105) 4 (102) 6 FOOT (1.83 METER) LEADWIRES (2) COLLAR WITH 2 (51) 1/2-14 NPSM 3-1/2 (89) INTERNAL THREADS 1–11-1/2 NPSM 1-3/16 INTERNAL (30) THREADS 1-1/16 (27) 31/32 1-1/2 (25) (38) COLLAR WITH 1/2-14 NPSM...
  • Page 8: Closed Loop Logic Test

    7800 SERIES EC7890A,B/RM7890A,B RELAY MODULE 11-13/16 (300) 2-5/32 1-27/32 1 INCH NPT 7-13/16 (198) 5-13/16 (147) (55) (47) 15/16 [24] DIA. 5-13/16 6-7/32 (147) (158) 2-1/2 (64) 6-19/32 (168) 1 (25) 15/16–18 UNC (2 EACH) 2 (51) M5084A C7076D Fig. 4. Ultraviolet detectors (Continued).
  • Page 9: Dynamic Ampli-Check

    7890 are isolated and loads will be de-energized. reported by the optional Keyboard Display Module. See the 7800 SERIES System Annunciation Diagnostics and Expanded Safe-Start Check Troubleshooting, form 65-0118. The conventional safe-start check, which prevents burner...
  • Page 10 7800 SERIES EC7890A,B/RM7890A,B RELAY MODULE used in accordance with the instructions, may CAUTION cause interference to radio communications. It has been tested and found to comply with the Disconnect the power supply before beginning limits for a Class A computing device pursuant to...
  • Page 11: Wiring

    7800 SERIES EC7890A,B/RM7890A,B RELAY MODULE fuse (or breaker) in event of an internal short Mounting Wiring Subbase circuit. The 7890 needs a low impedance ground connection to the equipment frame which, in turn, NOTE: For installation dimensions, see Fig. 1 or 2.
  • Page 12 7800 SERIES EC7890A,B/RM7890A,B RELAY MODULE Q7800 (L1) 100 VAC ALARM BURNER CONTROLLER/LIMITS INTERMITTENT PILOT/IGNITION MAIN FUEL VALVE(S) IGNITION RECTIFYING FLAME ROD, RECTIFYING (HOT) PHOTOCELL, OR INFRA- RED (LEAD SULFIDE) FLAME DETECTOR MASTER SWITCH C7027A, C7035A, OR BLUE WHITE C7044A ULTRAVIOLET...
  • Page 13 7800 SERIES EC7890A,B/RM7890A,B RELAY MODULE Q7800 (L1) 200 VAC ALARM BURNER CONTROLLER/LIMITS INTERMITTENT PILOT/IGNITION MAIN FUEL VALVE(S) IGNITION RECTIFYING FLAME ROD, RECTIFYING (HOT) PHOTOCELL, OR INFRA- RED (LEAD SULFIDE) FLAME DETECTOR MASTER SWITCH C7027A, C7035A, OR BLUE WHITE C7044A ULTRAVIOLET...
  • Page 14: Assembly

    7800 SERIES EC7890A,B/RM7890A,B RELAY MODULE ASSEMBLY Mounting 7890 NOTE: For installation dimensions, see Fig. 1 or 2. Relay Module Mounting Mount the 7890 vertically, see Figs. 9 or 10, or mount horizontally with the knife blade terminals pointing downward. When mounted on the Q7800A, the 7890 must be in an electrical enclosure.
  • Page 15 7800 SERIES EC7890A,B/RM7890A,B RELAY MODULE Installing Plug-In Flame Signal Amplifier Installing The Flame Detector Disconnect the power supply before beginning installation to prevent electrical shock and equipment NOTE: Table 2 and Fig. 13 list the flame detection systems damage. More than one disconnect may be involved.
  • Page 16 7800 SERIES EC7890A,B/RM7890A,B RELAY MODULE C7076A,D ULTRAVIOLET DETECTOR INFRARED (C7015) REMOTE SENSOR WHITE EARTH GROUND BROWN SHUTTER C7076A C7076D SHUTTER TERMINAL BLOCK ULTRAVIOLET (C7027/C7035/C7044) L1 (HOT) L2 (COMMON) BLUE 7800 SERIES WHITE SOLID STATE SELF-CHECKING SOLID STATE ULTRAVIOLET (C7012E,F) ULTRAVIOLET (C7012A,C)
  • Page 17: Operation

    7800 SERIES EC7890A,B/RM7890A,B RELAY MODULE OPERATION Normal Start-Up Safe-Start Check The 7890 verifies that a flame does not exist and proceeds into the Ignition Trial. If a flame is present, the 7890 will Sequence of Operation recycle to the STANDBY period. If the critical loads are not in The 7890 has the following operating sequences, see Fig.
  • Page 18: Static Checkout

    7800 SERIES EC7890A,B/RM7890A,B RELAY MODULE Table 3. Site-Configurable Jumper Options. CAPTIVE MOUNTING Jumper 7890 SCREW Number Description Intact Clipped Type Pilot Flame 10 sec 4 sec DUST Establishing COVER Period SEQUENCE RELAY Flame Failure Relight Lockout STATUS MODULE LEDs Action The Relight feature (JR2 intact) requires a 0.8 sec FFRT...
  • Page 19 7800 SERIES EC7890A,B/RM7890A,B RELAY MODULE Equipment Recommended Read the voltage between the subbase wiring terminals listed in the Voltmeter column of Table 4. Voltmeter (1M ohm/volt minimum sensitivity) set on the If there is no voltage or the operation is abnormal, 0-300 Vac scale.
  • Page 20: Checkout

    If an 7890 is replaced with a lower or higher Flame detector(s) is clean, installed and positioned functioning 7800 SERIES Relay Module, the burner properly. Consult the applicable Instructions. will not sequence unless wiring changes are made. Correct combination of amplifier and flame detector(s) is used.
  • Page 21 7800 SERIES EC7890A,B/RM7890A,B RELAY MODULE Table 5. Flame Signal (See Fig. 18). Minimum Acceptable Maximum Expected Flame Detector Flame Signal Amplifier Steady dc Voltage dc Voltage Flame Rod Photocell R7847A,B 1.25 Vdc 5.0 Vdc at the Keyboard C7012A,C Display Module.
  • Page 22 7800 SERIES EC7890A,B/RM7890A,B RELAY MODULE Recycle the system to recheck lightoff and pilot flame NOTE: Low fuel pressure limits, if used, could be open. If so, bypass them with jumpers during this check. signal. When the RUN period is displayed by the MAIN LED, Open the master switch.
  • Page 23 7800 SERIES EC7890A,B/RM7890A,B RELAY MODULE If used, remove the bypass jumpers from the low fuel NOTE: Upon completing these tests, open the master switch and remove all test jumpers from the subbase pressure limit and subbase. terminals, limits/controls or switches.
  • Page 24 7800 SERIES EC7890A,B/RM7890A,B RELAY MODULE After the sequence has entered the normal burner run Ignition Interference Test (All Flame Rods) period, turn down the pilot gas pressure very slowly, Test to be sure that a false signal from a spark ignition system reading the manometer (or gauge) as the pressure is not superimposed on the flame signal.
  • Page 25 7800 SERIES EC7890A,B/RM7890A,B RELAY MODULE If the flame signal is higher than 0.5 Vdc and the setpoint of the operating controller or setting the Fuel Selector Switch to OFF. Do not open the master switch. Visually FLAME LED does come on, consult the equipment observe when the burner flame goes out.
  • Page 26: Troubleshooting

    7890 that energizes the CAUTION ALARM LED by using the optional Keyboard Display Module or 7800 SERIES System Annunciation Diagnostics and Reinstall access slot covers on the Q7800A,B Troubleshooting, form 65-0118. Subbase after performing voltage checks.
  • Page 27 7800 SERIES EC7890A,B/RM7890A,B RELAY MODULE Table 6. Sequence and Status Hold Information. NOTE: Normal sequences are in bold type, while abnormal sequences are not in bold type. Sequence Information INITIATE The LED indicates the burner status, POWER, which is a stabilization period for the 7890 to check for any fluctuations in AC line voltage inputs or control input on powerup or during normal operation.
