Rammy 120 ATV Maintenance

MAINTENANCE
Object of maintenance Operation
Lubricate the end bearings of
the auger. There are grease
fittings on the side of the
bearings. Protect the fittings
with a plug.
Check the tension of the set
screws of the bearings. Apply
glue if needed.
Tighten the fastening screws.
Check the screw connections
between the engine,
transmission and other parts.
Check the condition of the
belts. Replace a worn belt by
removing the larger pulley.
Loosen the two hex screws and
set one screw into a blank
thread. Tighten the screw to
release the lock. Install a new
belt and slide the pulley back
into the axel. Tighten the hex
nuts, in turns evenly, back into
the original places.
Check condition and fastening
of springs.
The tension of the screws on
the engine belts is 6 Nm. The
tension on the pulleys of the
auger is 32 Nm.
Check the tension of protection
pins (5 pcs) of the belt. Adjust
the clearance of the pin and
belt to 1...3 mm.
www.rammy.fi
Type Service
interval
Bearing 20 hours (about
vaseline, 10 tanks of
operating gasoline) or once
temperature - per season.
30...+60
degrees 2 hours after first
use and every 20
Thread-locking hours thereafter
glue or once per
season
