- Page 1 biosignal acquisition tool-kit for advanced research applications Electroencephalography (EEG) Sensor User Manual...
- Page 2 The information contained in this document has been carefully checked and were made every effort to ensure its quality. PLUX reserves the right to make changes and improvements to this manual and products referenced at any time without notice.
-
Page 3: Table Of Contents
Electroencephalography (EEG) User Manual TABLE OF CONTENTS General Information ......................4 1.1. General Description ......................4 1.2. Typical Unfiltered Sensor Output..................4 1.3. Sensor Specifications ......................5 1.4. Features ..........................5 1.5. Applications........................5 1.6. Transfer Function (Conversion Formula) ................5 1.7. -
Page 4: General Information
Figure 1: biosignalsplux Electroencephalography (EEG) sensor (standard version). 1.2. Typical Unfiltered Sensor Output Figure 2 shows a typical unfiltered EEG sensor output acquired while at rest. The raw digital sensor values received from the biosignalsplux device ranged between 0 and 2 -1 (n=sampling resolution) were converted into the original unit of measurement of this sensor (µV) using the transfer function... -
Page 5: Sensor Specifications
Electroencephalography (EEG) User Manual 1.3. Sensor Specifications > Gain: 41780 > Range: ±37.5µV (@ VCC = 3V) > Bandwidth: 0.8 – 48,23Hz > Consumption: ~0.500mA > Input Impedance: > 100GOhm > CMRR: 100dB 1.4. Features > Single-channel differential sensor > Unobtrusive & lightweight sensor >... -
Page 6: Physical Characteristics
Sensor also available with A2 and A3 with 30cm cable lengths. Custom cable lengths for A1, A2, and A3 are possible. For custom lengths, please contact our operations team via orders@plux.info. Figure 3: Physical characteristics of the standard Electroencephalography (EEG) sensor. -
Page 7: Application Notes & Electrode Placement
EEG acquisition in 10-20 system configuration for EEG acquisition in 10-20 system configuration After placing the EEG electrodes correctly on the skin, connect the electrode cables of the EEG sensor according to one of the following configurations: Table 1: EEG sensor electrode and electrode placement connection. -
Page 8: Using The Electrocardiography (Eeg) Sensor With Biosignalsplux & Opensignals
3.1. Connecting the sensor to biosignalsplux Systems 3.1.1. biosignalsplux 4-Channel Hubs The biosignalsplux EEG sensor is compatible with all 8 analog input channels of the 4-channel biosignalsplux hub, but incompatible with the reference/ground port. Connect the sensor the analog input to use it with this device. -
Page 9: Biosignalsplux Solo & Single-Channel Openban Devices
User Manual 3.1.3. biosignalsplux Solo & Single-Channel openBAN Devices The biosignalsplux EEG sensor is compatible with the analog input channel of the biosignalsplux Solo (openBAN) device. Connect the sensor to the analog input channel to use it with this device. - Page 10 EEG from the dropdown menu highlighted in the next screenshot. Figure 9: Set the channel type of the channel you have your EEG sensor connected to, to EEG. Activate the channel for acquisition by clicking on the circle next to the channel type (must be blue). If not done before, follow the instruction available in section 2 Application notes to learn how to apply the sensors and 3.1 Connecting the sensor to biosignalsplux Systems to learn how to connect your...
- Page 11 Electroencephalography (EEG) User Manual Figure 10: Start the acquisition whenever you’re ready. 11 of 17...
-
Page 12: Scientific Publications Using The Electroencephalography (Eeg) Sensor
Electroencephalography (EEG) User Manual 4. Scientific Publications Using the Electroencephalography (EEG) Sensor The following scientific is only a small selection extracted from the list of available publications using biosignalsplux. Please visit the following website to access the entire up-to-date list: biosignalsplux Publications List of Publications Publications... -
Page 13: Safety & Maintenance
The user should use the sensor cables with extreme caution to avoid risk of strangulation. The user should keep a safe distance between the biosignalsplux device and other devices to ensure their proper functioning. The user should only send the device to repair to qualified PLUX personnel. 13 of 17... -
Page 14: Transportation And Storage
Electroencephalography (EEG) User Manual The user should not immerse the sensors or the biosignalsplux device, nor clean with liquid or abrasives. The user should handle the biosignalsplux device with caution and not expose the device or accessories to high accelerations and vibrations. biosignalsplux devices should not be used in patients with implanted electronic devices of any kind, including pace-makers, electronic infusion pumps, stimulators, defibrillators or similar. -
Page 15: Ordering Guides, Regulatory & Legal Information
If PLUX receives notification of any such defects within the guarantee period, it will repair or substitute with the same unit\model, any products with proven defects at no cost to the client. During the repair period PLUX promises to provide a temporary replacement under the same specification. -
Page 16: Regulatory Disclaimer
Electroencephalography (EEG) User Manual 6.5. Regulatory Disclaimer biosignalsplux products are intended for use in life science education and research applications; they are not medical devices nor are they intended for medical diagnosis, cure, mitigation, treatment or prevention of disease. We expressly disclaim any liability whatsoever for any direct, indirect, consequential, incidental or special damages, including, without limitation, lost revenues, lost profits, losses resulting from business interruption or loss of data, regardless of the form of action or legal theory under which the liability may be asserted, even if advised of the possibility of such damages. - Page 17 Electroencephalography (EEG) User Manual PLUX Wireless Biosignals S.A. email: plux@plux.info web: http://www.plux.info Headquarters Zona Industrial das Corredouras, Lt. 14 – 1° 2630-369 Arruda dos Vinhos Portugal tel.: +351 263 978 572 fax: +351 263 978 902 Lisbon Office Av. 5 de Outubro, n° 70 – 2°...
