  • Page 1 Infant Car Seat + Car Seat Base This product meets or exceeds FMVSS213 (US Federal Motor Vehicle Standards)

  • Page 2: Table Of Contents

    Before You Begin Terms You Need to Know Your Child’s Safety Depends On You Product Information and Expiration Date Registering your Products and Recall Information Usage Recommendations Important Warnings Weight and Height Recommendations for Your Child Choosing a Vehicle Seating Location Choosing an Installation Method Overview Installing with the LATCH/UAS Anchorage System...
  • Page 3 Installing the Car Seat Base and Car Seat (cont’d) Rotating and Removing the Car Seat from the Car Seat Base Securing Your Child Sizing the Restraint Harness to Your Child Securing Your Child with the Restraint Harness Using the Infant Head Support Using and Traveling with Your Car Seat Using the Soft Carrier Handle Using the Sunshade...

  • Page 4: Before You Begin

    Congratulations on the purchase of your Orbit Baby Infant Car Seat + Car Seat Base. Please take the time to read through this instruction manual carefully and make sure anyone else using the Orbit Baby Infant Car Seat + Car Seat Base reads it carefully as well.

  • Page 5: Terms You Need To Know

    Terms You Need to Know ® Orbit Baby Infant Car Seat ® Orbit Baby Car Seat Base...
  • Page 6 ® erms You Need to Know : Orbit Baby Car Seat Base LATCH/UAS Connector Storage LATCH/UAS Connector Base Upright Lock-Off Clamp Belt Path Belt Guide Level Indicator SmartHub StrongArm Knob...
  • Page 7 LATCH/UAS Belt Adjuster LATCH/UAS Belt StrongArm Rotation Indicator...
  • Page 8 ® erms You Need to Know : Orbit Baby Infant Car Seat Paparazzi Shield Sunshade Extension (not shown) Sunshade Carry Handle Release Lever Rear Panel Car Seat Hub...
  • Page 9 Soft Carrier Soft Carrier Handle Handle Grip Infant Head Support Shoulder Strap Shoulder Pad Chest Clip Restraint Harness Crotch Buckle Upholstery Crotch Pad Adjuster Strap Lock (under opening) Adjuster Strap Note: The Restraint Harness is made up of the Shoulder Straps, Crotch Belt and Adjuster Strap.

  • Page 10: Your Child's Safety Depends On You

    Register car seat and car seat base with Orbit Baby the expiration date. For your records, enter the serial number and date manufactured on page 13. Orbit Baby will help you keep track of safety updates and product recalls when you register with us.
  • Page 11 Use properly in an aircraft and on the Orbit Baby Stroller and Orbit The section titled Using and Traveling with Your Car Seat Baby Rocker.

  • Page 12: Product Information And Expiration Date

    Product Information and Expiration Date Storing your instruction manual: Store this instruction manual in the rear pocket on the back of the car seat for future use (Photo A). Product information and expiration date for your car seat and car seat base: The product information label is located behind the rear pocket on the car seat (Photo B), and on the back of the base...
  • Page 13 Orbit Baby G5 Car Seat Base Serial Number Date Manufactured Expiration Date Orbit Baby G5 Infant Car Seat Serial Number Date Manufactured Expiration Date...

  • Page 14: Registering Your Products And Recall Information

    Send your name, address, e-mail address if available, and the restraint’s model number and manufacturing date to Orbit Baby, P.O. Box 699,Ventura CA 93002 by using the enclosed prepaid post card, or call 1-888-829-8427, or register online at www.orbitbabyusa.

  • Page 16: Usage Recommendations

    Before You Begin Important Warnings 17 Weight and Height Recommendations for Your Child 21 Choosing a Vehicle Seating Location 22 Choosing an Installation Method Overview 26 Installing with the LATCH/UAS Anchorage System Need Help Securing Your Car Seat and Car Seat Base?

  • Page 17: Important Warnings

    Important Warnings WARNING Death or Serious Injury Can Occur FAILURE TO FOLLOW THESE INSTRUCTIONS AND THE PRODUCT LABELS CAN RESULT IN SERIOUS INJURY OR DEATH TO YOUR CHILD. To avoid serious injury or death, proper use is required. DO NOT let others install or use the car seat or car seat base without reading all the instructions first.
  • Page 18 Important Warnings cont’d WARNING Death or Serious Injury Can Occur If using the car seat base, securely install it in the vehicle either with the vehicle’s LATCH/UAS anchorage system or the vehicle seat belt, and then lock the car seat onto the car seat base, as shown in this manual.
  • Page 19 WARNING Death or Serious Injury Can Occur Use the car seat only with children who weigh between 1.8-13.6 kg (4-30 pounds), whose height is between 48-81cm (19-32 inches), whose shoulders are above the lowest set of shoulder slots, and who can be properly secured in the restraint harness.
  • Page 20 Do not modify your car seat or car seat base. Only use products and accessories approved by Orbit Baby to ensure the safety of your child. Follow the accompanying instruction manuals for these products and ac- cessories carefully.

  • Page 21: Weight And Height Recommendations For Your Child

    For smaller newborns, including lower birth weight babies, Orbit Baby’s Lower Birth Weight Fit Kit may improve the fit for such children. The Lower Birth Weight Fit Kit is available free of charge.

  • Page 22: Choosing A Vehicle Seating Location

    Choosing a Vehicle Seating Location WARNING Death or Serious Injury Can Occur Do not place this car seat in a vehicle seating location with a front air bag. Improper placement of the car seat in a vehicle will increase the risk of serious injury or death.
  • Page 23 The Orbit Baby Infant Car Seat is certified for use with the Orbit Baby Car Seat Base. Installing the car seat WITH the car seat base : If you are installing the car seat with the car seat base, first install the car seat base, and then lock the car seat on the car seat base.
  • Page 24 Choosing a Vehicle Seating Location cont’d Options cont’d General Guidelines: • This car seat can be installed in passenger cars (such as vans), multipurpose passenger vehicles (such as sports utility vehicles), trucks, and buses with qualifying anchorage or belt systems. This car seat may NOT be installed in low-speed vehicles (such as golf carts or all-terrain vehicles) or on motorcycles.
  • Page 25 In addition, the center-rear seating location is considered the best location if ALL the following conditions are met:  Installation in this seating location is permitted by the vehicle manufacturer. LATCH/UAS belt or vehicle seat belt provides a secure installation and ...

  • Page 26: Choosing An Installation Method Overview

    Choosing an Installation Method: Overview Your car seat base can be installed with either LATCH/UAS or a vehicle seat belt. 1. With the LATCH/UAS Anchorage System : See Installing with the LATCH/UAS Anchorage System. 2. With Vehicle Seat Belt : See Installing with Vehicle Seat Belt.
  • Page 27 Refer to your vehicle owner’s manual regarding requirements for using the vehicle’s LATCH/UAS anchorages with the car seat, or contact the vehicle manufacturer for guidance. The LATCH/UAS anchorage system makes car seat installation in a vehicle easier, and does not use vehicle seat belts. LATCH stands for Lower Anchors and Tethers for Children, and is also referred to as lower Universal Anchorage System (UAS) in Canada.
  • Page 28 Installing with the LATCH/UAS Anchorage System cont’d WARNING Death or Serious Injury Can Occur LATCH/UAS connectors must be secured to the vehicle LATCH/UAS anchorages only. Connections to other vehicle components could result in an unsafe installation of the car seat. Lower LATCH/UAS anchorages identified by this symbol...
  • Page 29 The following diagrams show how to properly install and remove the LATCH/ UAS connectors included on the car seat base. To Secure : • Slide LATCH/UAS connector completely onto the vehicle LATCH/UAS anchorage. You should hear a CLICK when the connector locks onto the LATCH/ UAS anchorage.
  • Page 30 Notes...

  • Page 31: Need Help Securing Your Car Seat And Car Seat Base

    The following resources can provide assistance or check whether your car seat is properly installed: In the U.S. contact : • Orbit Baby at family@orbitbabyusa.com or 1.888.829.8427 • Your vehicle dealer may help you locate a child safety seat inspection station in your area.

  • Page 32: Installing The Car Seat Base And Car Seat

    Installing the Car Seat Base and Car Seat Choosing Installation Options Installing the Car Seat Base Overview Installing the Car Seat Base: With LATCH/UAS Un-installing the Car Seat Base: With LATCH/UAS Installing the Car Seat Base: With Vehicle Seat Belt Un-installing the Car Seat Base: With Vehicle Seat Belt Installing the Car Seat on the Car Seat Base Overview...

  • Page 33: Choosing Installation Options

    Choosing Installation Options The Orbit Baby Infant Car Seat is certified for use WITH the Orbit Baby Car Seat Base. 1. Installing the car seat WITH the car seat base: The car seat base allows convenient rear-facing installation of your car seat. The car seat base can be installed either...

  • Page 34: Installing The Car Seat Base Overview

    Installing the Car Seat Base: Overview If you are installing the car seat with the car seat base, first install the car seat base, and then dock the car seat on the car seat base. The car seat base can be installed using either LATCH/UAS, or a vehicle seat belt.

  • Page 35: Installing With The Car Seat Base: With Latch/Uas

    Installing the Car Seat Base: With LATCH/UAS Before you install the car seat base in your vehicle, make sure the vehicle is parked on level ground. The car seat base should be installed without the car seat attached (Photo A). Follow instructions in the Rotating and Removing the Car Seat from the Car Seat Base to remove the car seat from the car seat base.
  • Page 36 Installing the Car Seat Base: With LATCH/UAS cont’d be visible and facing outward when connectors are correctly routed. LATCH/UAS should slide freely behind the lock-off clamp for installation. a. Pull LATCH/UAS belt left and right to check that it can slide freely behind the lock-off clamp (Photo E).”...
  • Page 37 the window (Photo H), try any of the following: Remove the car seat base. Position a rolled towel under the car seat base (Photo I), making sure the front of the car seat base contacts the vehicle seat. The towel should be compressed as the StrongArm tightens the car seat base into place.
  • Page 38 Installing the Car Seat Base : With LATCH/UAS cont’d Attach both LATCH/UAS connectors to their corresponding vehicle anchorages. With the connector oriented with logo facing outward, push it straight onto the metal bar until you hear and feel a CLICK (Photo J). Pull out on each LATCH/UAS connector to be sure it is locked onto the vehicle anchorage.
  • Page 39 revolutions. After 10 full revolutions, check the car seat base for a tight installation. You know that you have reached the optimal tightness setting when you tug on the belt guides (Photo M) and the base upright does not move more than 2.5 cm (1 in) in any direction.

  • Page 40: Un-Installing The Car Seat Base: With Latch/Uas

    Un-installing the Car Seat Base: With LATCH/UAS To un-install the car seat base and remove it from your vehicle: Turn the StrongArm knob counterclockwise and reset the car seat base StrongArm to zero (Photo A). Push and hold the red button on each LATCH/UAS connector and pull it off the vehicle LATCH/UAS anchorage (Photo B).

  • Page 41: Installing The Car Seat Base: With Vehicle Seat Belt

    nstalling the Base: A With Vehicle Seat Belt Before you install the car seat base in your vehicle, make sure the vehicle is parked on level ground. The car seat base should be installed without the car seat attached (Photo A). Follow instructions in the Rotating and Removing the Car Seat from the Car Seat Base to remove the car seat from the car...
  • Page 42 Installing the Car Seat Base: With Vehicle Seat Belt cont’d lock the vehicle seat back into the upright position. Center the car seat base on the vehicle seat (Photo D), making sure the areas under and behind the car seat base are clear of obstructions.
  • Page 43 WARNING Death or Serious Injury Can Occur To prevent ejection, the car seat base must be properly reclined. The window indicator in the car seat base must be green when installed. If using a lap-shoulder vehicle belt to secure the car seat base, continue to Step 7. If using a vehicle lap belt, skip to Step 14.
  • Page 44 Installing the Car Seat Base: With Vehicle Seat Belt cont’d Make sure the belt is not twisted and that both belts lie flat across the belt path and the open lock-off clamp. Pull on the shoulder portion of the vehicle seat belt to tighten the lap portion on the belt path (Photo I).
  • Page 45 the open lock-off clamp. Pull on free end of the vehicle lap belt to tighten it along the belt path (Photo L). Secure the lock-off clamp firmly upon the belt by flipping the top closure down into place (Photo M). Continue on to Step 21. Turn the StrongArm knob at the front of the car seat base clockwise to activate the StrongArm mechanism (Photo N).
  • Page 46 lnstalling the Base: With Vehicle Seat Belt cont’d RE-CHECK the following to make sure that the car seat base installation is secure: a. CHECK that the car seat base installation is not loose. It should not move by more than 2.5 cm (1 in) in any direction. b.

  • Page 47: Un-Installing The Car Seat Base: With Vehicle Seat Belt

    Un-installing the Car Seat Base : A With Vehicle Seat Belt To un-install the car seat base and remove it from your vehicle: Turn the StrongArm knob counterclockwise and reset the car seat base StrongArm to zero (Photo A). Open the lock-off clamp (Photo B), unbuckle the vehicle seat belt and guide it back through the belt guides (Photo C).

  • Page 48: Installing The Car Seat On The Car Seat Base Overview

    Installing the Car Seat on the Car Seat Base: Overview Once the car seat base is installed, the car seat can be docked and locked onto the car seat base conveniently. The car seat MUST be locked in the car seat base in the rear-facing position when the vehicle is in motion.

  • Page 49: Docking The Car Seat On The Car Seat Base

    Docking the Car Seat on the Car Seat Base WARNING Death or Serious Injury Can Occur PINCH HAZARD: Ensure that your child’s fingers and hands • are clear of release levers, soft carrie handle, and other moving parts. • When installing the car seat, make sure the hands of other vehicle occupants are clear of the SmartHub area.
  • Page 50 Docking the Car Seat on the Car Seat Base cont’d the car seat into the SmartHub of the car seat base until you hear and feel a CLICK (Photo C). For increased comfort and ease of use, the car seat can be docked onto the car seat base from almost any angle.
  • Page 51 If the rotation indicators show red with every docking attempt, do not use the car seat or car seat base, and contact Orbit Baby. RECHECK that the car seat is locked into the rear-facing position by pushing down...

  • Page 52: Rotating And Removing The Car Seat From The Car Seat Base

    Rotating and Removing the Car Seat from the Car Seat Base WARNING Death or Serious Injury Can Occur FALL HAZARD : Grasp the car seat by BOTH carry handles when removing it from the car seat base. PINCH HAZARD : Clear your child’s fingers and hands from the carry handle area before removing the car seat.
  • Page 53 Notes...

  • Page 54: Securing Your Child

    For smaller newborns, including lower birth weight babies, Orbit Baby’s Lower Birth Weight Fit Kit may improve the fit for such children. The Lower Birth Weight family@orbitbabyusa.com...

  • Page 55: Sizing The Restraint Harness To Your Child

    Docking the Car Seat on the Car Seat Base WARNING Death or Serious Injury Can Occur Failure to properly position and adjust the shoulder straps to your child’s size increases the risk of serious injury or death in the event of a sharp turn, sudden stop or crash.
  • Page 56 Sizing the Restraint Harness to Your Child cont’d Positioning the shoulder strap height : Place your child in the car seat and determine which pair of shoulder strap slots are below the child’s shoulders (Photo B). Shoulder Straps MUST be below the top of your child’s shoulders (Figure C).
  • Page 57 To loosen shoulder straps, press down on the adjuster strap lock and pull on both shoulder straps (Photo D). To tighten the shoulder straps, pull on the adjuster strap that hangs from the front of the car seat (Photo E). Changing shoulder strap slots : Loosen the restraint harness by pressing the adjuster strap lock and pulling on the...
  • Page 58 Sizing the Restraint Harness to Your Child cont’d strap through the correct upholstery slots and corresponding plastic shell slots (Photo I). CHECK that the shoulder straps are thread- ed into slots at the same height and that neither shoulder strap is twisted (Photo J). Turn to the back of the car seat again.

  • Page 59: Securing Your Child With The Restraint Harness

    Securing Your Child with the Restraint Harness WARNING Death or Serious Injury Can Occur Failure to properly position and adjust the shoulder straps to your child’s size increases the risk of serious injury or death in the event of a sharp turn, sudden stop or crash.
  • Page 60 Sizing the Restraint Harness to Your Child cont’d Buckling the restraint harness : Unbuckle the restraint harness by squeezing the tabs on the chest clip as shown (Photo A). Unbuckle both buckle tongues by pushing the red button on the crotch buckle (Photo B).
  • Page 61 Pull up on the buckle tongues to CHECK they are locked. DO NOT use the car seat if the restraint harness does not lock in place, and contact Orbit Baby. Gently pull up on the shoulder straps to tighten the lap section of the restraint harness (Photo E).
  • Page 62 Securing Your Child with the Re- straint Harness cont’d pass between straps and the child’s shoulder (Photo H). A snug strap should not allow any slack. It lies in a relatively straight line without sagging. It does not press on the child’s flesh or push the child’s body into an unnatural position.
  • Page 63 WARNING Children have STRANGLED in loose or partially harness straps. Fully restrain the child even when carrider is used outside the vehicle.

  • Page 64: Using The Infant Head Support

    Using the Infant Head Support WARNING Death or Serious Injury Can Occur To prevent ejection, shoulder straps must be routed through the shoulder strap slots in both the upholstery and infant head support. Some smaller infants may need the extra stability from the infant head support to keep their head and body in a comfortable position (Photo A).
  • Page 65 To re-install the infant head support : Thread each shoulder strap through the corresponding slot on the infant head support. Secure the infant head support around the shoulder straps by fastening the hook and loop fasteners. (Photo C). CHECK that the infant head support does not interfere with the movement of the shoulder straps.

  • Page 66: Using And Traveling With Your Car Seat

    Using and Traveling with Your Car Seat Using the Soft Carrier Handle Using the Sunshade Terms You Need to Know: Stroller Using the Car Seat on the Stroller Terms You Need to Know: Rocker Using the Car Seat on the Rocker Using the Car Seat on an Aircraft...

  • Page 67: Using The Soft Carrier Handle

    Using the Soft Carrier Handle The soft carrier handle allows you to ergonomically and comfortably carry the car seat (Photo A). WARNING Death or Serious Injury Can Occur FALL HAZARD : • ALWAYS secure your child with the restraint harness. •...
  • Page 68 Using the Soft Carrier Handle cont’d Carrying the car seat using the soft carrier handle : To use the soft carrier handle, lift it into position (Photo B). Lock the soft carrier handle in place by securing the tab through the red D-ring on the soft carrier handle grip (Photo C).

  • Page 69: Using The Sunshade

    Using the Sunshade WARNING Death or Serious Injury Can Occur CRUSHING HAZARD : Never put ob- jects on top of the sunshade. The weight of objects may cause the sun- shade to collapse. FALL HAZARD : Never carry the car seat by grasping the sunshade.
  • Page 70 Using the Sunshade cont’d Using the sunshade and Paparazzi Shield : To deploy the sunshade, pull it up into the desired position (Photo B). To use the Paparazzi Shield sunshade extension, pull it out of the sunshade pocket (Photo C). Secure the sunshade extension by wrapping the elastic over the foot end of the car seat (Photo D).

  • Page 71: Terms You Need To Know: Stroller

    Terms You Need To Know: Stroller (sold separately) Orbit Baby ® Infant Car Seat Orbit Baby Stroller ® Stroller SmartHub Parking Brake...

  • Page 72: Using The Car Seat On The Stroller

    Using the Sunshade Refer to the instruction manual that accompanied your Orbit Baby Stroller for complete instructions on using and maintaining your stroller. WARNING Death or Serious Injury Can Occur Always secure your child with the restraint harness when using the car seat with the stroller.
  • Page 73 Docking and rotating the car seat : Make sure the stroller is unfolded, and the SmartHub is clear of objects, before docking the car seat. Lock the parking brakes on the stroller. Grasp the car seat firmly by both carry handles (Photo A).

  • Page 74: Terms You Need To Know: Rocker

    Rocker SmartHub Orbit Baby Rocker ® Refer to the instruction manual that accompanied your Orbit Baby Rocker for complete instructions on using and maintaining your rocker. WARNING Death or Serious Injury Can Occur Always secure your child with the restraint harness when using the car seat with the rocker.

  • Page 75: Using The Car Seat On The Rocker

    Using the Car Seat on the Rocker Docking and rotating the car seat : Make sure the rocker is fully assembled, and the SmartHub is clear of objects, before docking the car seat. Lock the anti-rock arms on the rocker. Grasp the car seat firmly by both carry handles (Photo A).

  • Page 76: Using The Car Seat On An Aircraft

    Using the Car Seat on an Aircraft The Orbit Baby Infant Car Seat is certifield for use in aircraft without the Orbit Baby Car Seat Base and is labeled as such on the car seat side label. Most airlines in the U.S. and Canada will allow the use of a car seat that is labeled as an approved child restraint for aircraft use.
  • Page 77 Notes...

  • Page 78: Maintaining Your Car Seat

    Using and Traveling with Your Car Seat Removing the Upholstery and Sunshade Cleaning the Upholstery and Sunshade Re-installing the Upholstery and Sunshade Other Cleaning Instructions Limited Customer Warranty (United States)

  • Page 79: Removing The Upholstery And Sunshade

    Removing the Upholstery and Sunshade To remove the upholstery : The upholstery can be easily removed for cleaning WITHOUT detaching the restraint harness from the car seat. Unhook each corner of the upholstery from the rim near the carry handles (Photo A) and pull it away from the seat shell.

  • Page 80: Cleaning The Upholstery And Sunshade

    Sunshade To clean the upholstery : Machine wash in cold water on a gentle cycle with a mild detergent, such as Orbit Baby’s Upholstery Wash. Washing inside a pillow case and in a front-loading washer is recom- mended. DO NOT USE BLEACH.

  • Page 81: Re-Installing The Upholstery And Sunshade

    (Photo B). Pull the crotch buckle through the outer slot in the upholstery (Photo C). If using the foam insert from the Orbit Baby Lower Birth Weight Fit Kit, use the inner...
  • Page 82 Re-installing the Upholstery and Sunshade cont’d slot in the upholstery. Place the crotch pad back onto the crotch buckle strap (Photo D). Secure the elastic edges of the upholstery over the plastic rim (Photo E). Hook the cor- ners into place. CHECK that the shoulder straps are not twisted.
  • Page 83 Notes...

  • Page 84: Other Cleaning Instructions

    Other Cleaning Instructions Metal and plastic parts Metal and plastic parts on the car seat and car seat base may be wiped clean with a mild soap and water solution. Towel dry. Do not use household detergents, such as bleach or abrasive agents. These detergents can weaken plastic parts.
  • Page 85 be cleaned with a damp cloth or removed and thoroughly rinsed with warm water. Towel dry. Test the crotch buckle by fastening and unfastening until a positive click is heard when inserting the buckle tongues. If a click is not heard, repeat the cleaning procedure. Do not use lubricants, solvents, abrasive cleaners, soap or other household detergents on the crotch buckle or buckle tongues.

  • Page 86: Limited Customer Warranty (United States)

    • What Orbit Baby will do: If you believe the product is defective please return it to Orbit Baby in the manner described below within the limited warranty period. If Orbit Baby determines a defect is covered by this limited warranty, Orbit Baby will, at its...
  • Page 87 Your remedies under this limited warranty are limited to repair or replacement of the product or components of the product. In no event will Orbit Baby or any of its retailers, dealers, distributors or resellers be liable for incidental, indirect or consequential damages relating to the product (including any repaired or replacement product or component) or its use.
  • Page 88 For the most updated version of this manual, scan this code. After-Impact Exchange : If your Orbit Baby Infant Car Seat or Car Seat Base were involved in a vehicle collision, please contact Orbit Baby or go to www.orbitbabyusa.com/support to find out if the products qualify under our After-Impact Exchange program Customer Service &...
