A-NC
Component Checklist
Top Cabinet
x1
Hardware:
Key
5mm Allen key
x2
IMPORTANT INFORMATION
!
IMPORTANT - Install as per Installation Instructions
!
This product is compatible with laptops up to 400mm (15.7") wide.
!
This product supports a maximum load 5kg.
!
The manufacturer accepts no responsibility for incorrect installation.
Step 1. Check Components
Check that you have received all parts against the Component Checklist.
Step 2. Remove the cover plates
Remove the 4x M5 screws on the cover
plates using the Phillips head screwdriver.
M4 screws
x4
Notebook Cart
M8x12
x1
x12
Installation Instructions
Base
x1
M5x8
x6
Step 3. Remove safety screw on post bottom
Post
Handle
x1
x1
Tools Required:
Phillips head
Screwdriver
Handle top cap
x2
Non-slip pad
x3
Remove screw
Advertisement
Table of Contents
Related Manuals for Atdec A-NC
Summary of Contents for Atdec A-NC
- Page 1 Installation Instructions A-NC Notebook Cart Component Checklist Top Cabinet Base Post Handle Handle top cap Hardware: Tools Required: Phillips head Screwdriver Non-slip pad 5mm Allen key M8x12 M5x8 IMPORTANT INFORMATION IMPORTANT - Install as per Installation Instructions This product is compatible with laptops up to 400mm (15.7”) wide.
- Page 2 Step 4. Attach post to base Step 5. Replace cover trays Attach the post Replace both cover trays to the base with 4x M4 screws and using the 7x the phillips screwdriver. M8 screws and the allen wrench. M4 screws x4 Pedal forward M8 screws Step 7.
- Page 3 No portion of this document or any artwork contained herein should be reproduced in any way without the express written consent of Atdec Pty Ltd. Due to the continuing product development, the manufacturer reserves the right to alter specifications without notice. Published 12-05-14 ©...
