Related Manuals for Inofia HD161A
Summary of Contents for Inofia HD161A
- Page 2 BEFORE FIRST USE: Please leave the dehumidifier standing upright and outside the box for 24 HOURS before plugging it in. The dehumidifiers may have been tilted or placed upside down during shipping. Leave the dehumidifier to stand upright for 24 hours so the oil in the compressor can settle from the move, not doing so can affect the performance or lifespan of the dehumidifier.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Important Safety Instructions ..............................1 Parts Identification ..................................2 Operation Instructions ................................3 1. Position Your Dehumidifier Properly ........................... 3 2. Understand the Control Panel ............................3 3. General Operation ................................4 4. Timer Setting ................................... 5 5. -
Page 4: Important Safety Instructions
Important Safety Instructions To prevent injury and property damage, the following instructions must be followed when using the dehumidifier. Warning 1. Do not place the dehumidifier near a heater. Do not use the dehumidifier near flammable gas or combustibles, such as gasoline, benzene, thinner, etc. 2. -
Page 5: Parts Identification
Parts Identification NOTE: Do not cover or block the air inlet or outlet. -
Page 6: Operation Instructions
Operation Instructions 1. Position Your Dehumidifier Properly • Place the dehumidifier on a smooth, level floor that is strong enough to support the dehumidifier with a full bucket of water. • To maintain efficiency, operate the dehumidifier in an enclosed area. Keep nearby doors and windows closed. •... -
Page 7: General Operation
active. When the timer function is enabled, pressing the TIMER button once could check the time remaining. Defrost Indicator The DEFROST indicator light will illuminate when the frost has accumulated on the interior of the dehumidifier. The dehumidifying function will cease until the frost has melted. And the defrosting indicator will go off when the dehumidifier has stopped defrosting. -
Page 8: Timer Setting
font digital number turns to statically display the room humidity level. · The set humidity is recommended to be at least 10% lower than the room humidity level. · If the set humidity level is 30, the dehumidifier will run continuously in CONTINUOUS Mode. ·... -
Page 9: Smart Functions
4. Smart Functions Auto Shut Off When the bucket is full and/or the humidity setting is reached, the dehumidifier will shut off automatically. 1) When the water bucket is full, the LCD will display an E7 code, the FULL indicator will illuminate and the dehumidifier will make a beep sound for a few seconds. -
Page 10: Continuous Draining
2) Continuous Draining Water can be automatically emptied into a floor drain by attaching the included drain hose. (NOTE: You can use any other hoses with inner diameter of 0.39 inches instead.) To Achieve Continuous Drain by Gravity: a. Remove the water bucket; b. -
Page 11: Care & Cleaning
Care & Cleaning To avoid possible electric shock, ensure to turn the dehumidifier off and disconnect the plug from the power source before before performing any cleaning or maintenance. 1. Clean the Vent and Case • Use water and a mild detergent. Do not use bleach or abrasives. •... - Page 12 • Operate the dehumidifier on high fan mode for half a day, and then wait 1 day before emptying the reservoir. • Clean the dehumidifier housing, water reservoir, and air filter. Ensure the whole dehumidifier is clean and dry. • Take out the water bucket, put the plug and as possible cord into the water bucket, and then replace the bucket in the dehumidifier.
-
Page 13: Troubleshooting
· Turn off the dehumidifier and unplug it to check if any obstructions. · Restart the dehumidifier 10 minutes later. If the ERROR message does not disappear after the restart, immediately contact Inofia customer service at service@inofia.com. 2. Reset the Dehumidifier Please try the below steps to reset the dehumidifier: 1) Turn the dehumidifier off;... - Page 14 Problem Possible Causes Solutions Dehumidifier The power cord is unplugged. Plug it in. can not turn on The fuse is blown or circuit breaker is tripped. Check the fuse or the circuit breaker. Water bucket is full or not in the proper Make sure the water bucket is empty and has position.
-
Page 15: Product Specifications
Product Specifications Inofia Dehumidifier Model No. HD161A Power Source AC 110-120V, 60 Hz Rated Power 200W Rated Current 2.0A Moisture Removal (65°F, RH 60%) 9 Pints/Day Moisture Removal (80°F, RH 60%) 14 Pints/Day Moisture Removal (86°F, RH 80%) 25 Pints/Day Moisture Removal (95°F, RH 90%) -
Page 16: Warranty Information
Inofia's exclusive obligation under this warranty is limited to such repair or replacement. If you have an issue with an Inofia product, please contact us at service@inofia.com, and we will do our best to resolve it for you.
