- Page 1 Electric Automatic Door Opener VIS-440 Series Installation Manual www.visionistech.com...
-
Page 2: Table Of Contents
Table C o n t e n t 1 Technical P a r a m e t e r s 2 Components 3 Installation Steps 4-12 3.1 Installation of bottom plate 3.2 Installation of bottom plate 3.3 Installation of pull bar 3.4 Installation of pull bar 3.5 Installation of push bar 3.6 Installation of push bar... -
Page 3: Technical Parameters
1. Technical Parameters Dimensions (LWH) 515.62*78.74*114.3mm (20.3*3.1*4.5 Inches) Weight 17.7lbs Ambient temperature -20°C~ +50°C (-4°F~ 122°F) Operation voltage AC 100V -127V Power supply external consumption 24V DC (±10%), 3A Door opening angle Max 120° Opening speed 45°/S Closing speed 45°/S Hold-open time 0-60S Protection class... -
Page 4: Components
2. Components Note: Only one type of door bar comes with every kit Connect the AC power cable to 110V input Bottom plate Pull bar (inswing) Push bar(outswing) Cover Pull guider Mechanism Installation Screws Allen wrench Door sticker Power cord (AC) - Page 5 Safety devices should be in place and operational. Have door adjusted as recommended in Owner’s Manual if necessary. Have door inspected at least annually by a certified technician. TYPICAL USED TOOLS If you choose to use no locks or any other type of locks that is not a door strike, this latch must be remove for proper operation.
-
Page 6: Installation Steps
Installation Steps 3.1 Installation of bottom plate Pull bar type (inswing) -
Page 7: Installation Of Bottom Plate
Installation Steps 3.2 Installation of bottom plate Push bar type (outswing) bottom plate Operator at right position. Operator at left position. -
Page 8: Installation Of Pull Bar
3.Installation Steps 3.3 Installation of pull bar guider (inswing) Operator at Right position Operator at left position 1. Open the door to 90 degree before installation put the slider of pull bar into groove 2. Fix the pull bar installation plate according to the picture 3. - Page 9 3. Installation Steps Installation of pull bar guider (Inswing Door) A. Right position Fix the pull bar on door leaf with 3 pcs self-tapping screw. Door leaf Adjust the opening angle position stopper by position stopper.
-
Page 10: Installation Of Pull Bar
3. Installation Steps Installation of pull bar guider B. Left position Fix the pull bar on door leaf with 3 pcs self-tapping screw. Door leaf Adjust the opening angle position stopper by position stopper. -
Page 11: Installation Of Push Bar
3. Installation Steps Installation of push bar (Outswing Door) Fix the bottom of push bar to door leaf Adjust the push bar length by two screw according to the door frame’s depth(L). -
Page 12: Installation Of Push Bar
3. Installation Steps Installation of push bar B. Left position Fix the bottom of push bar to door leaf Adjust the push bar length by two screw according to the door frame’s depth(L). -
Page 13: Finished Installation
3. Installation Steps 3.7 Finished installation Pull bar: Door leaf open toward inside (same direction as operator) Operator Push bar: Door leaf open toward outside (opposite direction as operator) Note: you may have to install a door stopper if there isn't one or a wall to stop the door after opening. -
Page 14: Mechanism And Cover Installation
3. Installation Steps 3.8 Mechanism installation Note: First step is to remove the 8 mounting screws with Allen wrench. Separating the Bottom plate from the mechanism, to be able to mount it on the wall Hang the mechanism on the fixed base cover with screws. Assemble and disassemble of the mechanism cover. -
Page 15: Terminal Details Of Controller
4. Wired Diagrams 4.1 Terminal details NOTE: This product can be adjusted to work in either left or right doors. To change the orientation of the motor Please use DIP switch 3 located on the controller. 4.2 Data setting code Setting range Default description... -
Page 16: Wired Diagram
4. Wired Diagram Inter-lock 24G Microwave sensor... - Page 17 4. Wired Diagram Access Control Reader/Keypads (Stand-alone) Access Control Panels (ETL & DLX Series, VIS-3013) Wiring connection of electronic bolt lock 18. GND 17. Electronic lock+ Anti-clamp sensor when opening 24. Anti-clamp 22. GND 22. GND +24V 20. +24V Anti-clamp sensor when closing 23.
-
Page 18: Remote Functions
5. Remote Functions Operation of remote control VIS-8016: Always open Closed Automatic open/close Full lock Add the remote ： press the learning button on controller till the indicator turn from green to red， then release the learning button and press A button on remote， the indicator turn from red to green alternately 3 times，... -
Page 19: Led Display Feedback
6. LED Display Feedback Single opening Double opening LED display Details LED display Details Dr11 Dr12 Master door No problem. Dr12 or Dr13 Terminal 11 and 13 are not Dr13 Slave door connected. (They should be Er01 Over current protection for Controller. connected when single opening) Er01 Over current protection for Controller.
