TABLE OF CONTENTS Specifications Safety guidelines Assembly Operation Exploded view Parts list Warranty NOTE: If any parts are missing or damaged, or if you have any questions, please call our toll-free helpline at 1-888-670-6682. SAVE THESE INSTRUCTIONS This manual contains important safety and operating instructions. -
Page 3: Specifications
057-1655-2 | contact us 1-888-670-6682 SPECIFICATIONS SAFETY GUIDELINES This manual contains information that relates to PROTECTING PERSONAL SAFETY and Material Steel tube construction PREVENTING EQUIPMENT PROBLEMS. It is very important to read this manual carefully Maximum height 23 1/4" (59 cm) from ground to stand top and understand it thoroughly before using the product. - Page 4 Stand support • DO NOT exceed maximum weight capacity of the stand. • This product is not a toy. Do not allow children to play with or near this item. • Maintain product labels and nameplates. These carry important safety information.
-
Page 5: Assembly
057-1655-2 | contact us 1-888-670-6682 model no. 057-1655-2 | contact us 1-888-670-6682 ASSEMBLE THE LEG STAND (Fig. 1-4) Description Qty Illustration Group the leg stand parts by type and size. Refer to the package contents. Roller wheels, roller sleeves, big flat washer 8, big flat washer 10 and... - Page 6 057-1655-2 | contact us 1-888-670-6682 ATTACH HANDLE ASSEMBLY (Fig. 2) • Attach the tubes of the handle assembly (1) with the corresponding tubes of the stand assembly (2) and align the holes. • Insert a flat round head screw M8 x 45 (3) through the hole and tighten with a locking nut M8 (4).
- Page 7 This leg stand includes two support A and B to apply to four table saws (Support A: Make sure that the four fixing holes on the frame tube for MAXIMUM™ 10" (25.4 cm) Dewalt DW7480/DW745; Support B: Bosch GTS1031 and MAXIMUM™ 10" (25.4 cm) Compact Table Saw 055-6766-2 are different from Bosch GTS1031 table saw.
- Page 8 057-1655-2 | contact us 1-888-670-6682 TO CLOSE THE LEG STAND (Fig. 8-9) Make sure that remove the workpiece and store the accessories such as rip fence, blade guard. etc. when the table saw attached to the leg stand.
- Page 9 057-1655-2 | contact us 1-888-670-6682 TO OPEN THE LEG STAND (Fig. 12-13) TO MOVE THE LEG STAND (FIG. 10-11) • Begin with the leg stand in the locked upright position. • Place the stand upright on floor in front of you, step on the release lever (1) and pull the •...
- Page 10 • Place the stand on a level surface and level the stand to the floor. TO MOUNT THE MAXIMUM™ 10" (25.4 cm) COMPACT TABLE SAW 055-6766-2 (Fig. 14-15) Support B •...
- Page 11 057-1655-2 | contact us 1-888-670-6682 Make sure that the leg stand is securely locked in an open position and that the shock absorption (3) and level foot stabilizes the table saw before operation. Support A Fig. 17 c: Mounting holes for Dewalt DW7480/DW745 table saw TO SECURE/LEVEL THE TABLE SAW (Fig.
-
Page 12: Parts List
057-1655-2 | contact us 1-888-670-6682 PARTS LIST Description Description Hex bolt M8 x 85 Roller wheel Septa A Sleeve Locking nut M8 Big flat washer 8 Leg stand assembly C Leg stand assembly A Septa B Locking knob... -
Page 13: Warranty
1-Year Limited Warranty Notice to Consumer This MAXIMUM product is guaranteed for a period of one (1) year from This warranty gives you specific legal rights, and you may have other rights, which may the date of original retail purchase against defects in materials and vary from province to province.
