MIRAGE
S
D
& T
D
I
I
HOWER
OOR
UB
OOR
NSTALLATION
NSTRUCTIONS
IMPORTANT
DreamLine
reserves the rights to alter, modify or redesign products at any time without prior
TM
notice. For the latest up-to-date technical drawings, manuals or any other details please refer
to the
support.BathAuthority.com
web page.
Please read these instructions carefully before installing. If you have any questions regarding
installation, please call our technical support specialists Monday through Friday 9:00 AM – 5:00
PM EST at Phone: 1-866-731-2244, Fax:
1-866-227-1533
or e-mail our technical support group
at support@BathAuthority.com.
For more information on
DreamLine Shower Doors
and
Tub Doors
please visit
www.BathAuthority.com
Advertisement
Related Manuals for Bath Authority DreamLine MIRAGE
Summary of Contents for Bath Authority DreamLine MIRAGE
- Page 1 MIRAGE & T HOWER NSTALLATION NSTRUCTIONS IMPORTANT DreamLine reserves the rights to alter, modify or redesign products at any time without prior notice. For the latest up-to-date technical drawings, manuals or any other details please refer to the support.BathAuthority.com web page. Please read these instructions carefully before installing.
-
Page 2: Tools Required
Preparation 1. After opening all boxes and packages, read this introduction carefully. Check that all of the needed parts are included in the package by marking all the components on the “Detailed Diagram of Shower Door Components”. Examine boxes and packages for shipping damage. If the unit has been damaged, has a finishing defect, or is missing parts, please contact our customer support department within 5 business days of the delivery date. - Page 3 Detailed Diagram of Shower/Tub Door Components Parts List Stationary glass A Stopper block Glass door Wall bracket 2pcs Guide rail Single side strip Handle Bumper strip Support bar Seal gasket Wall anchor 6pcs Countersunk screw ST4.2×40 Round head screw ST4.2×55 6pcs Shelf bracket (without nut) 4pcs...
- Page 4 Sliding Bracket Assembly Face Plate Head screw M4×10 2pcs Back Plate Head screw M6×16 2pcs Slider Head screw M6×8 1/16” PVC gasket 2pcs 1/8” wool strip 4pcs 1/16” PVC washer 2pcs Plastic bulkhead 8pcs “MIRAGE – 60” Rev. 2 Ver. 5 07/2013...
-
Page 5: For Example
Shower/Tub Door Installation NOTE: The installation of this door requires two installers. NOTE: The door can be installed on the shower base, tub or custom threshold. 1. Measure the distance between two walls. This distance is marked as “W”. See Fig. 1 for details. 2. - Page 6 3. Fasten the Guide rail connector (08) to one of the sides of the Guide rail (03). Slide in two Roller assemblies (10) from the other end of the Guide rail. Fasten another Guide rail connector to the other side of the Guide rail.
- Page 7 5. Mount the Wall bracket (12) to Stationary glass A (01). Slide the glass into the channel of the Guide rail (03). See Fig. 5 for details. 6. Butt up Stationary glass A (01) against the wall and level it vertically. See Fig.
- Page 8 7. Outline the position of the Wall bracket (12) on the wall. Set Stationary glass A (01) aside. Remove the Wall bracket from Stationary glass A and by replacing it to the outlined position mark the hole on the wall. Drill the hole using Ø...
- Page 9 9. Butt up Stationary glass B (20) against the wall and level it vertically. See fig. 9 for details. 10. Outline the position of the Wall bracket (12) on the wall. Set Stationary glass B (20) aside. Remove the Wall bracket from Stationary glass B and by replacing it to the outlined position mark the hole on the wall.
- Page 10 11. Push the Single side strip (13) between the groove of the Guide rail (03) and both Stationary glasses A & B using wooden shims or other piece of wood. See fig. 11 for details. . 11 12. Glass shelves (19) are installed to Stationary glass B (20).
- Page 11 . 13 NOTE: Please refer to Sliding bracket assembly (09) diagram on Page 4. 13. Disassemble the Sliding bracket assembly. Mount the Face Plate (A) and Back Plate (B) on the top of Stationary glass A (01) with the Head screw M6×16 (G). Use PVC gasket (D) and PVC washer (E) in between glass and metal parts.
- Page 12 . 15 14. Install the Stopper block (11) on the bottom of the Glass door (02). See fig. 16 for details. . 16 “MIRAGE – 60” Rev. 2 Ver. 5 07/2013...
- Page 13 15. Bring the Glass door (02) inside the shower. Remove nuts from the Roller assembly (10) bolts and spread the rollers against the installation holes on the Glass door. Fasten the Roller assembly to the Glass door through the predrilled holes. NOTE: Steps 15 and Steps 16 require second person to hold Glass door.
- Page 14 . 19 17. Press the Magnetic strip (14) on the vertical edge of the Glass door (02) and Stationary glass B (20). Push the Seal gasket (15) into the channel of the Guide rail (03). See Fig. 20 for details. .
- Page 15 18. Install the Handle (04) onto the Glass door (02). See fig. 21 for details. . 21 19. Locate the Support bar (05) and temporarily fasten it to the Sliding bracket assembly (09) with the Head screw M6×8 (H). Ø...
- Page 16 20. Apply the sealant along the connection of Stationary glasses A and B with the wall inside the shower, as well as between the Guide rail (03) and the threshold outside the shower. See Fig. 23 and Fig. 24 for details. caulk .
-
Page 17: Product Maintenance
NOTICE: The above installation steps are given for the right-hand configuration. For left-hand configuration door, please reverse Stationary glass A and B and attach the Sliding bracket assembly (12) to Stationary glass A. See Fig. 25 for details. . 25 Product Maintenance To ensure long lasting life for your acrylic back walls, wipe them off after each use with a soft cloth. - Page 18 ™ DREAMLINE EXCLUSIVE LIMITED WARRANTY AS OF MAY 6, 2013 This warranty extends only to the original owner/end‐user for household use only and is not transferable to a subsequent owner. This warranty extends for a designated period of time, so long as it remains in use in its original place of installation. This warranty applies only to DreamLine products purchased from an authorized dealer in United States or Canada. Proof of purchase (original sales receipt) from the original consumer purchase must be provided with all warranty claims. IN NO EVENT SHALL THE LIABILITY OF DREAMLINE EXCEED THE PURCHASE PRICE OF THE UNIT. DreamLine products must be installed by a fully insured and licensed professional. Installation of DreamLine product by anyone other than fully insured licensed professionals shall VOID THE WARRANTY. DreamLine recommends that such licensed professionals have experience in the installation of bathroom products. Installation of certain products, including, without limitation, glass products (i.e., shower and tub doors) by an inexperienced installer may result in glass breakage and, consequently, cause personal injury or death. PARTS ONLY WARRANTY This warranty is extensive in that it covers replacement of all defects. LABOR CHARGES AND/OR DAMAGE INCURRED IN INSTALLATION, REPAIR, OR REPLACEMENT, AS WELL AS ANY OTHER KIND OF LOSS OR DAMAGE ARE EXCLUDED COMMERCIAL USE AND OTHER EXCLUSIONS This warranty excludes all industrial, commercial and business usage, whose purchasers are hereby extended a one (1) year limited warranty from the date of purchase for shower and tub doors, a three (3) month limited warranty from the date of purchase for vanities and sinks, with all other terms of this warranty applying except the duration of the warranty. DREAMLINE ...
- Page 19 TEL: 866-731-2244 FAX: 866-227-1533 WWW. UTHORITY.COM For more information on DreamLine Shower Doors Tub Doors please visit www.BathAuthority.com...
