NEPTUNE
Steam Room Installation Instructions
IMPORTANT
Please read carefully the following instructions before installing your shower cabin. If you
have any questions on this shower cabin installation - please call our technical support
specialists Monday to Friday 9:00AM – 5:00PM EST at 1-866-731-8378 Option 3 or e-mail
our technical support group at support@BathAuthority.com
Our product may have changes without prior notice

Advertisement

loading
Need help?

Need help?

Do you have a question about the DreamLine Neptune and is the answer not in the manual?

Questions and answers

Related Manuals for Bath Authority DreamLine Neptune

Summary of Contents for Bath Authority DreamLine Neptune

  • Page 1 NEPTUNE Steam Room Installation Instructions IMPORTANT Please read carefully the following instructions before installing your shower cabin. If you have any questions on this shower cabin installation - please call our technical support specialists Monday to Friday 9:00AM – 5:00PM EST at 1-866-731-8378 Option 3 or e-mail our technical support group at support@BathAuthority.com Our product may have changes without prior notice...
  • Page 2 IMPORTANT SAFETY INFORMATION Your STEAM SHOWER is equipped with an Auto-Drain feature. 1-3 minutes after the unit control panel power is turned off any remaining hot water in the steam generator system is automatically drained into the shower cabin. For your safety – please do not turn off the power button on the control unit until you are ready to exit the cabin.
  • Page 3 WARNING Please, make sure you do the following: Electrical grounding is required on the steam generator; All electrical supplies must be disconnected when servicing the steam generator; All wiring must be installed by a licensed electrician (please consult your local codes); All plumbing must be installed by a licensed plumber (please, consult your local codes);...
  • Page 4 3 business days. Please note that Bath Authority™ / DreamLine™ will not replace any damaged product or parts free of charge after 3 business days or if the product has been installed.
  • Page 5 Detailed Diagram of Steam Room Components Packing List 01 Roof 20 Anti-water strip 1pcs 02 Back panel 21 Bottom anti-water strip 2pcs 03 Side panel 22 Bolt M6×40 (with nut, washer) 12pcs 04 Shelf panel 23 Bolt M6×20 (with nut, washer) 39pcs 05 Control panel 24 Bolt M6×16 (with nut, washer) 9pcs 06 Bottom tray...
  • Page 6 Cabin Installation 1. Choose the location where you cabin will be installed. Mark the location of the tray. Install the drain pipe according to drawing Fig 1. Be sure the upper edge of the 2” elbow or bushing will be on the level or below the floor level Fig 2. 2.
  • Page 7 13. Secure the Generator assembly (37) to the back corner of the tray with Round head screw ST4.2×25 (17). See Fig 15 for details. 14. Apply silicone sealant on the top of the acrylic panels. Secure the roof to the back panel, side panel, shelf panel and the control panel with Round head screw ST4.2×25 (17) and Bolt M6×20 (23).
  • Page 8 2" PVC pipe support Fig 1 Fig 2 power 1/2" screw connector Fig 3 Fig 4 Rev. 1. 3.
  • Page 9 Fig 5 Fig 6 Fig 7 Fig 8 Rev. 1. 3.
  • Page 10 ￠3 Fig 9 Fig 10 Fig 11 Fig 12 Rev. 1. 3.
  • Page 11 Fig 13 Fig 14 ￠3 Fig 15 Fig 16 Rev. 1. 3.
  • Page 12 Fig 17 Fig 18 Fig 19 Fig 20 Rev. 1. 3.
  • Page 13 ￠6 Fig 21 Fig 22 Blue Cool Fig 23 Fig 24 Rev. 1. 3.
  • Page 14 Fig 25 Fig 26 Fig 27 Fig 28 Rev. 1. 3.
  • Page 15 Fig 29 Fig 30 Control Panel Electronic Control Box Steam control wire Temperature probe Control panel cable Top light power cable Steam wire Steam generator Power wire Steam outlet Steamer water inlet Steamer remain water Ground cable Fig 31 Rev. 1. 3.
  • Page 16 Using Controls Thermostatic Valve Valve “a” turns on the “tropical rain” head shower. Valve “b” turns on massage jets. Valve “c” turns on the waterfall head shower. Valve “d” turns on the hand shower. Turning the revolving top of the hand shower head will change water patterns.
  • Page 17 Performance The control uses a blue color back light liquid crystal display with white back light induction type touching key. Turning the steam on will fill the generator with water automatically; when system is shut-down an automatic water draining system is turning on. Includes steam and light control functions Steam temperature regulation range: Centigrade temperature 30~60C, Fahrenheit 86~140F;...
  • Page 18 Product Maintenance Acrylic cleaning Acrylic should be cleaned with warm water and a clean, nonabrasive cloth. If desired, a mild, nonabrasive detergent may also be used. Use only light pressure when cleaning. Avoid rubbing dirt or grit into the surface. Turn the cloth often and replace with a clean cloth frequently.

  • Page 19: Warranty

    LIMITED WARRANTY ™ This is Bath Authority LLC’s (“DreamLine”) exclusive written warranty effective April 2, 2012 This warranty extends only to the original owner/end-user for household use only and is not transferable to a subsequent owner. This warranty applies only to DreamLine™...
