FREEDOM PLUS
Solar Street Light
Operation Instruction
LEADSUN INC.
th
Address: 10134 6 Street, Ste. M, Rancho Cucamonga, CA 91730
Phone: 909.476.0900
Fax: 909.466.0130
Email: sales@leadsun-us.com
LEADSUN Australia PTY LTD
Address: 42 Greens Road, Dandenong South, Victoria 3175
Phone: +61 1300 281 005
Fax: +61 3 8610 0393
Email: jeoffc@leadsun.com.au
LEADSUN Global Limited
Address: NO.1 Pingdong 1st Rd, Nanping Science & Technology
Industrial Park, Zhuhai, China 519060.
Phone: +
86 - 756 - 2289712
Fax: +
86 - 756 - 8682090
Email: sales@leadsunglobal . com
Made in China
FREEDOM PLUS
Solar Street Light
Operation Instruction
RUP.064-A
www.leadsunglobal.com
Advertisement
Table of Contents
Related Manuals for leadsun FREEDOM PLUS
Summary of Contents for leadsun FREEDOM PLUS
- Page 1 Address: 10134 6 Street, Ste. M, Rancho Cucamonga, CA 91730 Phone: 909.476.0900 Fax: 909.466.0130 Email: sales@leadsun-us.com Solar Street Light LEADSUN Australia PTY LTD Address: 42 Greens Road, Dandenong South, Victoria 3175 Phone: +61 1300 281 005 Fax: +61 3 8610 0393 Operation Instruction Email: jeoffc@leadsun.com.au...
-
Page 2: Product Components
Product Components Part List Check if all the components are complete before installation, the components and quantity of Solar Panel Components each set as follows: Solar Panel Parts List 110W 130W/180W Parts Quantity Solar panel U-type bracket Bushings Solar panel U-type bracket Bushings C-type Frame... - Page 3 If you need to replace the components /accessories, please go to qualified specialist. www.leadsun.globalcom, or contact the local distributor. The street light with AC adapter is customized product, please confirm the street light AC adapter is in accord with the local electric supply standard.
-
Page 4: Functional Specification
Operation instruction Overview FREEDOM PLUS series intelligent lithium battery solar led street light integrates LED street light, long lifespan LiFePO4 lithium battery pack, high-efficiency smart controller, and Aluminum structure shell. The product not only can apply to the traditional split type solar street light maintenance or replacement but also a brand new cost-efficient solution for newly installed lithium battery solar street light. -
Page 5: Product Installation
Operation instruction Product installation 1. Installation conditions Long press the button for (5s) to switch the working modes: Please choose the appropriate model depending on the sunlight intensity of the place and In the OFF mode, when connected to the solar panel, if the lighting condition is normal, it will required working time. - Page 6 Product Installation If you choose LEADSUN solar panel module and bracket, please follow the below 130~180W bracket module installation installations. If you use your own solar panel module, it can be used for reference. Embed 5pcs C-type screw nuts into the cross-bar. As shown in figure 3.
- Page 7 Product Installation 3. Install the bird spike As shown in figure 5, use the accessories M8*25 screw, M8 spring washer, M8 plain washer, C-type screw nut to Using the self-tapping screw in the accessory to fasten the fasten the U-type bracket on the cross-bar. M8*25 Screw bird spike on the top frame of the solar power system.
-
Page 8: Troubleshooting
Product Installation Troubleshooting 5. Solar Power System Installation Negative Inspection Process Approach Phenomenon Connect the solar power system with the waterproof wire in the light pole and lock the connectors in turns; embed the light pole into the X bracket and use the special tool to fasten the Test according to the “Button Instructions' M8*16mm screw.
