- Page 1 How to Assemble your Bobbin Junior Bike Gingersnap / Moonbug models All sizes...
- Page 2 Congratulations on getting a new Bobbin! Parenting level = Elite Assembling a Bobbin junior bike is really easy and fun. It’s also a good chance to get to know how it works. Allow 15-25 minutes to put your bike together and have it ready to ride.
- Page 3 Tools Your bike comes with a basic set of tools included. You will also need: • Scissors • Pump • Phillips Screwdriver...
- Page 4 Unpacking Box contents • Stand the bike box upright. Make sure you have enough space to work. Put your tools on a table. • Remove the large staples from the box. Warning – they are very sharp. Take care. • Open the top of the box and pull the bike out. • ...
- Page 5 Chain case Box contents • Gingersnap and Moonbug models 12-16” all use an injection-moulded plastic chaincase to save weight • All chaincases feature a cut-out section • The cut-out section can vary from model-to- model, and can also look like this • ...
- Page 6 Handlebars a. Remove and discard the black plastic cap from the bottom of the handlebar stem. Simply use your allen key to loosen the bolt at the top of the handle; the plastic cap will then pull off. a. b. Insert the stem into the hole in the frame. The ‘minimum insertion line’...
- Page 7 Front Mudguard a. Using the 10mm spanner, unfasten the front brake bolt nut. b. Fasten the front mudguard behind the fork like this. a. c. Using a 10mm spanner, unfasten the nuts at the bottom of the fork. d. Attach the mudguard stays (metal arms) to the fork, using these nuts.
- Page 8 Front Wheel a. Loosely fit the nuts and washers to the front wheel axle. There is a ‘tab’ on the washer. This must point inwards towards the wheel. b. The tyres have a “tread”. It’s best to have this facing forwards. a. ...
- Page 9 Saddle a. Insert the seat post into the frame Warning! Don’t exceed the minimum insertion mark. a. b. Tighten the seat collar using the allen key. “What is the correct saddle height?” Sitting on the saddle, the rider should be able to touch the floor with their toes.
-
Page 10: Left Right
Pedals LEFT IMPORTANT! Left and Right pedals are NOT THE SAME. Fitting them on the wrong side will break the crank. The pedals should go in easily; if not STOP! Check you have the correct pedal and check you are screwing in straight not at an angle. - Page 11 Bell • The bell goes on the left hand side of the handlebars. • The bell is fitted with a Philips screwdriver.
- Page 12 Basket 12”, 16” and 20” bikes • Your basket is fitted to the handlebars using the straps provided. • Make sure the straps are tight and the basket is not touching the front wheel/mudguard. • Wicker baskets are hand-made from natural materials.
- Page 13 Basket – Gingersnap 24” • Fit the support legs on the front wheel axle, using the 15mm spanner to remove then re- tighten the wheel nuts. • Attach the bracket base plate onto the base of the basket, about 5cm from the front of the basket.
- Page 14 Basket – Gingersnap 24” …continued • Attach the 2 support plate onto the back of the basket. This fits onto the bracket mounted on the bike’s head tube. • Tighten up both brackets.
- Page 15 Fitting Stabilisers (training wheels) - Go to p.16 if you have the nut & bolt attachment versions • Attach the stabiliser wheel bolt at the back using a 12mm spanner. • Tighten the front bolt using an allen key. • Remove rear wheel bolt on the bike using a 15mm spanner.
- Page 16 Fitting Stabilisers (training wheels) …continued • Re-attach the mudguard stay and re-attach the wheel bolt on top. • Tighten the wheel bolt securely with the 15mm spanner.
- Page 17 Nut & Bolt Attachment Stabilisers ( if you do not have allen key ones) Attach wheel to stabiliser leg and tighten nut on reverse using 12mm spanner. Tighten the nut on reverse using a 12mm spanner (1), holding the nut on front (2) with either a 12mm socket spanner or pliers.
- Page 18 Adjusting the brakes If you need to adjust the brakes, there are 3 ways to it: • Use a 10mm spanner to adjust cable tension (image 1 & 2). Pulling the cable through makes the brakes sharper. • Using your fingers, adjust the barrel adjuster (image 3).
- Page 19 Adjusting the Gears Gingersnap 20” and Gingersnap 24” The gears will probably not need adjustment straight away, however after a few weeks of riding the gear cable will loosen a little and they may need adjustment then. This is completely normal on all bikes using derailleur gears and is not a fault.
- Page 20 Recommended Maintenance • Check that the tyres are inflated regularly • To keep your Bobbin running beautifully we recommend regular servicing with a qualified mechanic • Keeping your Bobbin clean and serviced will significantly extend the life of your bike and makes for happier cycling all around.
- Page 21 Congratulations! You have assembled your Bobbin Junior bike! Share your photos on Instagram: @bobbinbicycles...
