- Page 1 S100 CONSTRUCTION HEATER Rev: 2.11 March 12, 2008 SERVICE AND MAINTENANCE MANUAL No. 934-6891 PLEASE RETAIN FOR FUTURE REFERENCE PRODUCTS A Division of Haul-All Equipment Ltd. 4115 - 18 Avenue North Lethbridge, Alberta T1H 5G1 www.sureflame.ca...
- Page 2 S100 CONSTRUCTION HEATER GENERAL HAZARD WARNING Failure to comply with the precautions and instructions provided with this heater, can result in death, serious bodily injury and property loss or damage from hazards of fire, explosion, burn, asphyxiation, carbon monoxide poisoning, and/or electrical shock. Only persons who can understand and follow the instructions should use or service this heater.
- Page 3 READ THIS WARNING FIRST ! The heater is designed and approved for use as a construction heater under CSA 2.14-2000 and ANSI Z83.7-2000. The primary purpose of construction heaters is to provide temporary heating of buildings under construction, alteration, or repair and to provide temporary emergency heat.
-
Page 4: Table Of Contents
S100 CONSTRUCTION HEATER FOR YOUR SAFETY DO NOT USE THIS HEATER IN A SPACE WHERE GASOLINE OR OTHER LIQUIDS HAVING FLAMMABLE VAPOURS ARE STORED OR USED. CONTENTS Specifications ..................5 Installation ....................6 Installation Using A Propane Supply Tank ..........7 Installation For Natural Gas Applications .......... -
Page 5: Specifications
SPECIFICATIONS Model No. S100 Construction Heaters CSA Certified to CSA 2.14-2000 and ANSI Z83.7-2000 Gas Fired Unvented Construction Heater Gases: Natural or Propane Capacity: 100,000 Btu/h (29 kW) maximum Orifice Size: 43 DMS (x10) Blower: 1,300 cfm (615 l/s) Electrical Rating: 115 volts, 60 Hz., 4 amps, single phase Gas Supply:... -
Page 6: Installation
INSTALLATION The Sure Flame Model S100 Construction Heater is a direct fired gas heater intended to be used primarily for the temporary heating of buildings under construction, alteration, or repair. Since all the products of combustion are released into the area being heated, it is imperative that adequate ventilation is provided. -
Page 7: Installation Using Apropane Supply Tank
INSTALLATION USING A PROPANE SUPPLY TANK 1 When installing the heater for use with propane gas, set the gas selector valve to “Propane”. 2 Arrange the propane supply system to provide for vapour withdrawal from the operating container. Supplying liquid propane to the heater is danger- ous and will damage the components. -
Page 8: Operating Instructions
OPERATING INSTRUCTIONS 1 Set GAS SELECTOR VALVE to gas being used. The conversion shall be done by the owner or lessor of the equipment. NOTE: When using Propane Gas the Selector Valve must be in the PROPANE position. 2 Ensure the MANUAL VALVE (blue knob at rear of heater) is in the “ON” position. -
Page 9: Common Installation And Operational Problems
COMMON INSTALLATION AND OPERATIONAL PROBLEMS 1 LOW VOLTAGE This is one of the most common problems and is usually the result of the supply cord having too small a wire gauge for its length. Low voltage results in the motor overheating, burnt relay contacts, or a relay that will not maintain contact. -
Page 10: Design Related Additional Safety Features
DESIGN RELATED ADDITIONAL SAFETY FEATURES 1 LOW SKIN TEMPERATURE Sure Flame Heaters are designed to have a low skin temperature. This provides added safety in the workplace. 2 DURABLE CONSTRUCTION The Model S100 uses a stainless steel burner for long life and consistent performance. -
Page 11: Preventative Maintenance
PREVENTIVE MAINTENANCE Sure Flame Construction Heaters are built to withstand the rigours of operating on construction sites, for mining applications, and a multitude of other locations where heaters are used. To maintain the reliable perform- ance required it is necessary to do a certain amount of regular maintenance. A VISUAL CHECKS The following items should be checked for excessive wear or damage: 1) Cords and Connectors... -
Page 12: S100 Heater Parts
S100 HEATER PARTS Page LM P/N: 934-6891 S100 Manual, Rev: 2.1.1... - Page 13 S100 HEATER PARTS Sept. 13, 2002 Ref. Part No Description 6897 Handle S100-101 Top Shell 5124 Air Switch (0.2" W.C.) 5768 Terminal Block 4519 Motor Relay 24V 4511 Transformer 24V 8264 Direct Spark Ignition Control S100-716 Downstream Airtube “S” S100-715 Upstream Airtube “C”...
-
Page 14: S100 Connection Wiring Diagram
S100 CONNECTION WIRING DIAGRAM CONNECTOR BLK 18cm GRN 7cm BLK 20cm WHT 20cm Page LM P/N: 934-6891 S100 Manual, Rev: 2.1.1... -
Page 15: S100 Ladder Wiring Diagram
S100 LADDER WIRING DIAGRAM POWER/MOTOR RELAY START BUTTON STOP BUTTON HI LIMIT SWITCH 110V-24V STEPDOWN TRANSFORMER SOLENOID VALVE AIR SWITCH Power S100 Manual, Rev: 2.1.1 P/N: 634-6891 Page RM...
