Acson international ADB75B Manual

Ducted blower split systems
Hide thumbs
Table of Contents

Advertisement

Quick Links

Models:
ADB 75-750 B
ADB 75-500 D
ADB 75/100 D
ADB 125/150 D
ADB 600 B4
Ducted Blower
Split Systems
ADB-B_(i)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ADB75B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Acson international ADB75B

Summary of Contents for Acson international ADB75B

  • Page 1 Models: ADB 75-750 B ADB 75-500 D ADB 75/100 D ADB 125/150 D ADB 600 B4 Ducted Blower Split Systems ADB-B_(i)

  • Page 2: Table Of Contents

    TABLE OF CONTENTS 1. NOMENCLATURE ..................... 1 - PRODUCT LINE UP ..................3 2. FEATURES ........................ 9 3. APPLICATION INFORMATION - OPERATING RANGE ..................10 - REFRIGERANT CIRCUIT DIAGRAM ............11 - CONTROLLER ....................13 - INSTALLATION ....................17 4. SOUND DATA ......................27 - NC CURVES ....................

  • Page 3: Nomenclature

    1. NOMENCLATURE Indoor Others AA : Revision Type of Connection B : For Brazed F : For Flare Electrical A : 50Hz/1Ph/220 ~ 240V F : 50Hz/3Ph/380 ~ 415V Model Type R : Heatpump Omitted if Cooling Only Series B : B series D : D series Capacity 200 : 200,000 Btu/h...
  • Page 4 Outdoor Others AA : Revision Type of Connection B : For Brazed F : For Flare Electrical A : 50Hz/1Ph/220 ~ 240V F : 50Hz/3Ph/380 ~ 415V Model Type R : Heatpump Omitted if Cooling Only Series B : B series D : D series Capacity 75 : 75,000 Btu/h...

  • Page 5: Product Line Up

    Product Line Up Classification Refrigerant Control Handset Marking A. Filter Air Discharge Others Control ABAF 100B ABAH 125B FBAH 150B FBAG FBAH 200B2 FBAI FBAG 250B2 FBAI FBAC 300B2 FBAE FBAC 300B3 FBAE FBAG 350B3 FBAI FBAC 400B4 FBAE FBAC 450B3 FBAE FBAG...
  • Page 6 Classification Refrigerant Controller Handset Marking Filter Air Discharge Others Control ABAE ABAG ABAE 100D ABAG FBAE 125D FBAF FBHB FBAA 125D2 FBHA FBAE 150D1 FBHB FBAC 150D2 FBHA 200D2 FBAF 250D2 FBAF 300D2 FBAF 400D4 FBAF 500D4 FBAF...
  • Page 7 Classification Control Marking Compressor Others FBAO FBAS FBAM FBAS FBAP 100B FBAR FBAS FBAH 100C FBAI FBAJ FBAR FBAW 125B FBAT FBAY FBAK 150C FBAM FBAP...
  • Page 8 Classification Expansion Control Marking Compressor Others Device FBAF FBAG FBAH FCAA FCAB FBAF FBAG 100D FBAH FCAA FCAB FBAF FBAG 125D FBAH FCAA FCAB FBAG FBAH FBAI 150D FCAA FCAB FCAC FBAA 200D2 250D2 FBAA 300D2 FBAA...
  • Page 9 Classification Expansion Control Marking Compressor Others Device A4MC FBAA FBAC FCAA FCAB FBAA FBAC 100D FCAA FCAB FBAA FBAC 125D FCAA FCAB FBAA FBAC 150D FCAA FCAB...
  • Page 10 Classification Controller Marking Compressor Others FBCA FBEA FBCA 100F FBEA FBCA 125F FBEA...

  • Page 11: Features

    2. FEATURES EASY MAINTENANCE The simple design concept has provided the ease of maintenance and servicing. Access to the internal part of the unit can be from the service panel or other side of the unit by loosening a few screws. Only for model ADB75/100D with additional service panel from bottom AIR DISCHARGE ORIENTATION ADB200B and ADB75-150D models come with standard horizontal air discharge.

  • Page 12: Application Information

    3. APPLICATION INFORMATION Operating Range Ensure the operating temperature is in allowable range. Cooling only Caution : The use of your air conditioner outside the range of working temperature and humidity can result in serious failure. Indoor temp. (°CWB)

  • Page 13: Refrigerant Circuit Diagram

    Refrigerant Circuit Diagram Standard Models...
  • Page 14 MODEL : AMC200D2 / 250D2 / 300D2 (WITH ACCUMULATOR)

  • Page 15: Controller

    Controllers ELECTRICAL CONNECTION Wiring regulations about wire diameter differs from country to country. Please refer to your LOCAL ELECTRICAL CODES for field wiring rules. Be sure that installation comply with such rules and regulations. GENERAL PRECAUTION Ensure that the rated voltage of the unit correspond to the name plate before carrying out proper wiring according to the wiring diagram.
  • Page 16 2.2 Selecting Operation Mode Press the MODE key to select the type of operating mode. Consecutive press of the key switches the operation over “COOL”, “HEAT”, “AUTO” and “FAN” 2.3 SAVE Mode Press the SAVE key to select the energy saving function. This option is only available for “COOL”, “HEAT”...
  • Page 17 3. ERROR CODE When the system is on and an error occurs, the ON/OFF LED on the LCD panel will blink and an error code is shown. When the system is off and there is a thermistor error, the ON/OFF LED is off but the error code is still displayed.
  • Page 18 5. AUTO RANDOM RESTART When power resumed, the unit will automatically restart and operate at the previous setting as before power failure occurred. (Remove jumper at JH/JP1 will cancel the auto random restart function. Please refer to wiring diagram for the location of the JH/JP1). SLM CONTROLLER OPERATING INSTRUCTIONS AC-5300 (OPTIONAL) 1.

  • Page 19: Installation

    Installation SPECIAL PRECAUTIONS WHEN DEALING WITH REFRIGERANT R407C UNIT 1) WHAT IS NEW REFRIGERANT R407C? R407C is a zeotropic refrigerant mixture which has Zero Ozone Depletion Potential (ODP = 0) and thus conformed to the Montreal Protocol regulation. It requires Polyol-ester oil (POE) oil for its compressor’s lubricant.
  • Page 20 c) Ensure that the compressor is not expose to open air for more than the recommended time specified by its manufacturer (typically less than 10 minutes). Removed the seal plugs only when the compressor is about to be brazed. d) The system should be thoroughly vacuumed to 1.0 Pa ( 700mmHg) or lower. This vacuuming level is more stringent than R22 system so as to ensure no incompressible gas and moisture in the system.
  • Page 21 Indoor Unit Preliminary Site Survey a) Electrical supply and installation is to confirm to local authority's (e.g. National Electricity Board) codes and regulations. b) Voltage supply fluctuation must not exceed +/- 10% of rated voltage. Electricity supply line must be indepen- dent of welding transformers which can cause supply fluctuation.
  • Page 22 Outdoor Unit Location For Installation Of The Condensing Units As condensing temperature rises, evaporating temperature rises and cooling capacity drops. In order to achieve maximum cooling capacity, the location selected should fulfill the following requirements:- a) Install the condensing (outdoor) unit in a way such that hot air distributed by the outdoor condensing unit cannot be drawn in again (as in the case of short circuit of hot discharge air).
  • Page 23 Field Piping To ensure satisfactory operation and performance, the following points should be noted for the field piping arrangements of the complete refrigerant cycle. a) Liquid loops or oil traps must be provided according to the position of the outdoor and the indoor units (de- pending on whether the indoor unit is above or below the outdoor unit).
  • Page 24 Installation Clearance When two or more outdoor units are installed in a location, they must be positioned such that one unit will not be taking the hot discharge air from another to avoid hot air short circuiting. This also applies when two or more units are installed one above the other. Below are the installation clearance guidelines :...
  • Page 25 Guidelines Of Field-charging Air Conditioning Systems With Scroll Compressors These guidelines are intended for use with Scroll compressors only with R22, R407C, R134a, R404A, R507, and R410A refrigerants. They do not apply to reciprocating compressors or competitive Scroll compressors. FIELD-CHARGING - SOME PRECAUTION POINTS Scroll compressors have a very high volumetric efficiency and quickly pump a deep vacuum if there is insuffi- cient refrigerant in the system or if refrigerant is added too slowly.
  • Page 26 Typical service valves Shredder valves found on the outdoor unit Shredder core Shredder valve with Shredder valve with core removed core in place Most split systems have a suitable connection on the outdoor unit Shredder valves provide easy system access for pressure reading and addition of refrigerant. On small sys- tems, they provide a reasonable connection for evacuation also.
  • Page 27 CHARGING RECOMMENDATIONS Charging liquid in a CONTROLLED manner into the suction side until the system is full. This recommen- dation does not hold true for reciprocating compressors where liquid charging into the suction side could cause severe damage. Charging Cylinder on Scale Close-up of Scale Carefully monitor the suction and discharge pressures - ensure that the suction pressure does not fall below 25 psig (1.7 bar) at any time during the charging process.
  • Page 28 System Refrigerant Charge Level Guidelines Refrigerant Charge Indoor Outdoor Liquid Pipe Gas Pipe (kg/7.5m pipe length) ADB75B AMC75B 4.00 ADB75B AMC75C 4.50 ADB100B AMC100B 1-1/8 7.60 ADB100B AMC100C 1-1/8 7.00 ADB125B AMC125B 1-3/8 7.95 ADB150B AMC150C 1-3/8 10.1 ADB200B2 AMC100B x 2 1-1/8 7.60 x 2...

  • Page 29: Sound Data

    Sound Pressure Level ADB-B SERIES 1/1 Octave Sound Pressure Level (dB, ref 20μPa) Overall A Model Speed Noise Criteria (dBA) 125Hz 250Hz 500Hz 1kHz 2kHz 4kHz 8kHz ADB75B High ADB100B High ADB125B High ADB150B High ADB200B High ADB250B High ADB300B High ADB350B...
  • Page 30 Sound Power Level ADB-B SERIES 1/1 Octave Sound Power Level (dB, reference 1pW) Overall A Model Speed (dBA) 125Hz 250Hz 500Hz 1kHz 2kHz 4kHz 8kHz ADB75B High ADB100B High ADB125B High ADB150B High ADB200B High ADB250B High ADB300B High ADB350B...

  • Page 31: Nc Curves

    ADB75B NC CURVE ADB100B NC CURVE...
  • Page 32 ADB125B NC CURVE ADB150B NC CURVE...
  • Page 33 ADB200B NC CURVE NC-60 HI FAN NC-55 NC-50 NC-45 NC-40 NC-35 NC-30 NC-25 NC-20 1000 2000 4000 8000 Octave-band Frequency (Hz) ADB250B NC CURVE NC-60 HI FAN NC-55 NC-50 NC-45 NC-40 NC-35 NC-30 NC-25 NC-20 1000 2000 4000 8000 Octave-band Frequency (Hz)
  • Page 34 ADB300B NC CURVE NC-65 HI FAN NC-60 NC-55 NC-50 NC-45 NC-40 NC-35 NC-30 NC-25 NC-20 1000 2000 4000 8000 Octave-band Frequency (Hz) ADB350B NC CURVE HI FAN NC-65 NC-60 NC-55 NC-50 NC-45 NC-40 NC-35 NC-30 NC-25 NC-20 1000 2000 4000 8000 Octave-band Frequency (Hz)
  • Page 35 ADB400B NC CURVE HI FAN NC-65 NC-60 NC-55 NC-50 NC-45 NC-40 NC-35 NC-30 NC-25 NC-20 1000 2000 4000 8000 Octave-band Frequency (Hz) ADB450B NC CURVE HI FAN NC-65 NC-60 NC-55 NC-50 NC-45 NC-40 NC-35 NC-30 NC-25 NC-20 1000 2000 4000 8000 Octave-band Frequency (Hz)
  • Page 36 ADB500B NC CURVE HI FAN NC-65 NC-60 NC-55 NC-50 NC-45 NC-40 NC-35 NC-30 NC-25 NC-20 1000 2000 4000 8000 Octave-band Frequency (Hz) ADB600B NC CURVE NC-70 HI FAN NC-65 NC-60 NC-55 NC-50 NC-45 NC-40 NC-35 NC-30 NC-25 NC-20 1000 2000 4000 8000 Octave-band Frequency (Hz)
  • Page 37 ADB750B NC CURVE NC-70 HI FAN NC-65 NC-60 NC-55 NC-50 NC-45 NC-40 NC-35 NC-30 NC-25 NC-20 1000 2000 4000 8000 Octave-band Frequency (Hz)
  • Page 38 ADB75D NC CURVE ME FAN HI FAN NC-55 NC-50 LO FAN NC-45 NC-40 NC-35 NC-30 NC-25 NC-20 1000 2000 4000 8000 Octave-band Frequency (Hz) ADB100D NC CURVE ME FAN HI FAN NC-55 NC-50 LO FAN NC-45 NC-40 NC-35 NC-30 NC-25 NC-20 1000 2000...
  • Page 39 ADB125D NC CURVE NC-55 HI FAN NC-50 NC-45 NC-40 NC-35 NC-30 NC-25 NC-20 1000 2000 4000 8000 Octave-band Frequency (Hz) ADB150D NC CURVE HI FAN NC-55 NC-50 NC-45 NC-40 NC-35 NC-30 NC-25 NC-20 1000 2000 4000 8000 Octave-band Frequency (Hz)
  • Page 40 ADB200D NC CURVE NC-60 HI FAN NC-55 NC-50 NC-45 NC-40 NC-35 NC-30 NC-25 NC-20 1000 2000 4000 8000 Octave-band Frequency (Hz) ADB250D NC CURVE NC-60 HI FAN NC-55 NC-50 NC-45 NC-40 NC-35 NC-30 NC-25 NC-20 1000 2000 4000 8000 Octave-band Frequency (Hz)
  • Page 41 ADB300D NC CURVE NC-65 HI FAN NC-60 NC-55 NC-50 NC-45 NC-40 NC-35 NC-30 NC-25 NC-20 1000 2000 4000 8000 Octave-band Frequency (Hz) ADB400D NC CURVE NC-65 HI FAN NC-60 NC-55 NC-50 NC-45 NC-40 NC-35 NC-30 NC-25 NC-20 1000 2000 4000 8000 Octave-band Frequency (Hz)
  • Page 42 ADB500D NC CURVE HI FAN NC-65 NC-60 NC-55 NC-50 NC-45 NC-40 NC-35 NC-30 NC-25 NC-20 1000 2000 4000 8000 Octave-band Frequency (Hz)

  • Page 43: Selection Process

    5. SELECTION PROCESS Fan Performance Chart Example 1 : The following are the design requirements for ADB250D2 unit: Model: ADB250D2 Supply Air Quantity 8000 External Static Pressure mmAq Step 1: From the fan curve (at 8000 CFM), Standard operating system; Total Static Pressure 46.5 mmAq...
  • Page 44 The following table summarizes the pulley data, motor size used for the ADB series, as manufactured: Motor pulley, Dm Blower pulley, Db Model V-pulley Taper # V-pulley Taper # (in.) (mm) (in.) (mm) ADB200B / ADSB200B ADB250B / ADSB250B 12.0 ADB300B / ADSB300B 12.0 ADB350B / ADSB350B...
  • Page 45 Example 1: FAN PERFORMANCE CURVE ADB250D...

  • Page 46: Fan Performance Chart

    FAN PERFORMANCE CURVE ADB75B...
  • Page 47 FAN PERFORMANCE CURVE ADB100B...
  • Page 48 FAN PERFORMANCE CURVE ADB125B...
  • Page 49 FAN PERFORMANCE CURVE ADB150B...
  • Page 50 FAN PERFORMANCE CURVE ADB200B/ADSB200B...
  • Page 51 FAN PERFORMANCE CURVE ADB250B/ADSB250B...
  • Page 52 FAN PERFORMANCE CURVE ADB300B/ADSB300B...
  • Page 53 FAN PERFORMANCE CURVE ADB350B/ADSB350B...
  • Page 54 FAN PERFORMANCE CURVE ADB400B/ADSB400B...
  • Page 55 FAN PERFORMANCE CURVE ADB450B...
  • Page 56 FAN PERFORMANCE CURVE ADB500B/ADSB500B...
  • Page 57 FAN PERFORMANCE CURVE ADB600B...
  • Page 58 FAN PERFORMANCE CURVE ADB750B...
  • Page 59 FAN PERFORMANCE CURVE ADB75D...
  • Page 60 FAN PERFORMANCE CURVE ADB100D...
  • Page 61 FAN PERFORMANCE CURVE ADB125D...
  • Page 62 FAN PERFORMANCE CURVE ADB150D...
  • Page 63 FAN PERFORMANCE CURVE ADB200D...
  • Page 64 FAN PERFORMANCE CURVE ADB250D...
  • Page 65 FAN PERFORMANCE CURVE ADB300D...
  • Page 66 FAN PERFORMANCE CURVE ADB400D...
  • Page 67 FAN PERFORMANCE CURVE ADB500D...
  • Page 68 FAN PERFORMANCE CURVE ADB75D VERY HIGH STATIC...
  • Page 69 FAN PERFORMANCE CURVE ADB100D VERY HIGH STATIC...
  • Page 70 FAN PERFORMANCE CURVE ADB125D VERY HIGH STATIC...
  • Page 71 FAN PERFORMANCE CURVE ADB150D VERY HIGH STATIC...

  • Page 72: Engineering And Physical Data

    6. ENGINEERING AND PHYSICAL DATA General Data - Cooling Only (R22) B Series INDOOR UNIT ADB75B ADB75B MODEL OUTDOOR UNIT AMC75B AMC75C Btu/h 75,000 75,000 NOMINAL CAPACITY 21,981 21,981 NOMINAL TOTAL INPUT POWER 8,390 8,389 NOMINAL RUNNING CURRENT 15.4 15.4 2.63...
  • Page 73 General Data - Cooling Only (R22) B Series INDOOR UNIT ADB100B ADB100B MODEL OUTDOOR UNIT AMC100B AMC100C Btu/h 100,000 100,000 NOMINAL CAPACITY 29,310 29,310 NOMINAL TOTAL INPUT POWER 10,334 10,914 NOMINAL RUNNING CURRENT 19.4 19.7 2.65 2.65 POWER SOURCE V/Ph/Hz 380~415 / 3 / 50 380~415 / 3 / 50 REFRIGERANT TYPE...
  • Page 74 General Data - Cooling Only (R22) B Series INDOOR UNIT ADB125B ADB150B MODEL OUTDOOR UNIT AMC125B AMC150C Btu/h 125,000 150,000 NOMINAL CAPACITY 36,640 43,960 NOMINAL TOTAL INPUT POWER 12,321 16,659 NOMINAL RUNNING CURRENT 22.5 29.1 3.21 2.92 POWER SOURCE V/Ph/Hz 380~415 / 3 / 50 380~415 / 3 / 50 REFRIGERANT TYPE...
  • Page 75 General Data - Cooling Only (R22) B Series INDOOR UNIT ADB200B2 ADB200B2 MODEL OUTDOOR UNIT AMC100B x 2 AMC100C x 2 Btu/h 200,000 200,000 NOMINAL CAPACITY 58,600 58,600 NOMINAL TOTAL INPUT POWER 11,930 11,790 NOMINAL RUNNING CURRENT 22.4 23.1 4.91 4.97 POWER SOURCE V/Ph/Hz...
  • Page 76 General Data - Cooling Only (R22) B Series INDOOR UNIT ADB250B2 ADB300B2 MODEL OUTDOOR UNIT AMC125B x 2 AMC150C x 2 Btu/h 250,000 300,000 NOMINAL CAPACITY 73,270 87,900 NOMINAL TOTAL INPUT POWER 14,258 19,230 NOMINAL RUNNING CURRENT 25.8 33.1 5.14 4.57 POWER SOURCE V/Ph/Hz...
  • Page 77 General Data - Cooling Only (R22) B Series INDOOR UNIT ADB300B3 ADB300B3 MODEL OUTDOOR UNIT AMC100B x 3 AMC100C x 3 Btu/h 300,000 300,000 NOMINAL CAPACITY 87,900 87,900 NOMINAL TOTAL INPUT POWER 13,200 13,060 NOMINAL RUNNING CURRENT 24.5 25.2 6.66 6.73 POWER SOURCE V/Ph/Hz...
  • Page 78 General Data - Cooling Only (R22) B Series INDOOR UNIT ADB350B3 MODEL OUTDOOR UNIT AMC100B x 1 AMC125B x 2 350,000 Btu/h NOMINAL CAPACITY 102,550 24,598 NOMINAL TOTAL INPUT POWER NOMINAL RUNNING CURRENT 45.0 4.00 POWER SOURCE 380~415 / 3 / 50 V/Ph/Hz REFRIGERANT TYPE INDOOR TXV...
  • Page 79 General Data - Cooling Only (R22) B Series INDOOR UNIT ADB400B4 ADB400B4 MODEL OUTDOOR UNIT AMC100B x 4 AMC100C x 4 Btu/h 400,000 400,000 NOMINAL CAPACITY 117,200 117,200 NOMINAL TOTAL INPUT POWER 14,035 13,895 NOMINAL RUNNING CURRENT 26.1 26.8 8.35 8.43 POWER SOURCE V/Ph/Hz...
  • Page 80 General Data - Cooling Only (R22) B Series INDOOR UNIT ADB450B3 ADB500B4 MODEL OUTDOOR UNIT AMC150C x 3 AMC125B x 4 Btu/h 450,000 500,000 NOMINAL CAPACITY 131,850 146,500 NOMINAL TOTAL INPUT POWER 22,550 18,923 NOMINAL RUNNING CURRENT 38.5 34.2 5.85 7.74 POWER SOURCE V/Ph/Hz...
  • Page 81 General Data - Cooling Only (R22) B Series INDOOR UNIT ADB600B4 ADB750B5 MODEL OUTDOOR UNIT AMC150C x 4 AMC150C x 5 Btu/h 600,000 750,000 NOMINAL CAPACITY 175,800 219,750 NOMINAL TOTAL INPUT POWER 28,130 30,130 NOMINAL RUNNING CURRENT 47.4 51.0 6.25 7.29 POWER SOURCE V/Ph/Hz...
  • Page 82 General Data - Cooling Only (R22) D Series INDOOR UNIT ADB75D MODEL OUTDOOR UNIT AMC75D 75000 Btu/h NOMINAL CAPACITY 21,980 NOMINAL TOTAL INPUT POWER 7765 NOMINAL RUNNING CURRENT 14.8 2.83 380~415 / 3 / 50 POWER SOURCE V/Ph/Hz REFRIGERANT TYPE REFRIGERANT CONTROL INDOOR TXV OPERATION...
  • Page 83 General Data - Cooling Only (R22) D Series 1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE. 2) ALL UNITS ARE BEING TESTED AND COMPLY TO ISO13253 3) NOMINAL COOLING AND HEATING CAPACITY ARE BASED ON THE CONDITIONS BELOW : COOLING - 26.7°C DB / 19.4°C WB INDOOR AND 35°C DB / 23.9°C WB OUTDOOR 4) SOUND PRESSURE LEVEL ARE ACCORDING TO JIS B 8615 STANDARD.
  • Page 84 General Data - Cooling Only (R22) D Series INDOOR UNIT ADB125D MODEL OUTDOOR UNIT AMC125D Btu/h 125,000 NOMINAL CAPACITY 36,630 NOMINAL TOTAL INPUT POWER 11,413 NOMINAL RUNNING CURRENT 20.5 3.20 POWER SOURCE V/Ph/Hz 380~415 / 3 / 50 REFRIGERANT TYPE REFRIGERANT CONTROL INDOOR TXV OPERATION...
  • Page 85 General Data - Cooling Only (R22) D Series INDOOR UNIT ADB150D1 ADB150D2 MODEL OUTDOOR UNIT AMC150D AMC75D x 2 150,000 Btu/h NOMINAL CAPACITY 43,960 NOMINAL TOTAL INPUT POWER 15,244 15,794 NOMINAL RUNNING CURRENT 27.5 30.5 2.88 2.78 380~415 / 3 / 50 POWER SOURCE V/Ph/Hz REFRIGERANT TYPE...
  • Page 86 General Data - Cooling Only (R22) D Series INDOOR UNIT ADB200D2 MODEL OUTDOOR UNIT AMC100D x 2 AMC200D2 Btu/h 200,000 200,000 NOMINAL CAPACITY 58,600 58,600 NOMINAL TOTAL INPUT POWER 19,940 21,720 NOMINAL RUNNING CURRENT 37.8 41.4 2.93 2.69 380~415 / 3 / 50 POWER SOURCE V/Ph/Hz REFRIGERANT TYPE...
  • Page 87 General Data - Cooling Only (R22) D Series INDOOR UNIT ADB250D2 MODEL OUTDOOR UNIT AMC125D x 2 AMC250D2 Btu/h 250,000 250,000 NOMINAL CAPACITY 73,250 73,250 NOMINAL TOTAL INPUT POWER 24,286 26,247 NOMINAL RUNNING CURRENT 43.0 49.7 3.01 2.79 380~415 / 3 / 50 POWER SOURCE V/Ph/Hz REFRIGERANT TYPE...
  • Page 88 General Data - Cooling Only (R22) D Series INDOOR UNIT ADB300D2 MODEL OUTDOOR UNIT AMC150D x 2 AMC300D2 Btu/h 300,000 300,000 NOMINAL CAPACITY 87,920 87,920 NOMINAL TOTAL INPUT POWER 32,008 33,680 NOMINAL RUNNING CURRENT 56.5 62.9 2.74 2.61 380~415 / 3 / 50 POWER SOURCE V/Ph/Hz REFRIGERANT TYPE...
  • Page 89 General Data - Cooling Only (R22) D Series INDOOR UNIT ADB400D4 MODEL AMC100D x 4 OUTDOOR UNIT 400,000 Btu/h NOMINAL CAPACITY 117,200 40,180 NOMINAL TOTAL INPUT POWER NOMINAL RUNNING CURRENT 75.8 2.91 380~415 / 3 / 50 POWER SOURCE V/Ph/Hz REFRIGERANT TYPE REFRIGERANT CONTROL INDOOR TXV...
  • Page 90 General Data - Cooling Only (R22) D Series INDOOR UNIT ADB500D4 MODEL OUTDOOR UNIT AMC125D x 4 500,000 Btu/h NOMINAL CAPACITY 146,500 NOMINAL TOTAL INPUT POWER 51,072 NOMINAL RUNNING CURRENT 88.7 2.86 380~415 / 3 / 50 POWER SOURCE V/Ph/Hz REFRIGERANT TYPE REFRIGERANT CONTROL INDOOR TXV...
  • Page 91 General Data - Cooling Only (R22) D Series - Very High Static INDOOR UNIT ADB75D ADB100D MODEL OUTDOOR UNIT AMC75D AMC100D Btu/h 75,000 100,000 NOMINAL CAPACITY 21,975 29,300 NOMINAL TOTAL INPUT POWER 8,310 10,302 NOMINAL RUNNING CURRENT 19.0 23.4 2.64 2.84 POWER SOURCE V/Ph/Hz...
  • Page 92 General Data - Cooling Only (R22) D Series - Very High Static INDOOR UNIT ADB125D MODEL OUTDOOR UNIT AMC125D Btu/h 125,000 NOMINAL CAPACITY 36,625 NOMINAL TOTAL INPUT POWER 11,579 NOMINAL RUNNING CURRENT 21.2 3.16 POWER SOURCE V/Ph/Hz 380~415 / 3 / 50 REFRIGERANT TYPE REFRIGERANT CONTROL INDOOR TXV...
  • Page 93 General Data - Cooling Only (R22) D Series - Very High Static INDOOR UNIT ADB150D1 ADB150D2 MODEL OUTDOOR UNIT AMC150D AMC75D x 2 Btu/h 150,000 150,000 NOMINAL CAPACITY 43,950 43,950 NOMINAL TOTAL INPUT POWER 15,369 15,919 NOMINAL RUNNING CURRENT 28.0 31.0 2.85 2.76...
  • Page 94 General Data - Cooling Only (R22) D Series INDOOR UNIT ADB75D MODEL OUTDOOR UNIT AMC75F 75,000 Btu/h NOMINAL CAPACITY 21,980 NOMINAL TOTAL INPUT POWER 9,120 16.3 NOMINAL RUNNING CURRENT 2.63 POWER SOURCE 380~415 / 3 / 50 V/Ph/Hz REFRIGERANT TYPE INDOOR TXV REFRIGERANT CONTROL OPERATION...
  • Page 95 General Data - Cooling Only (R22) D Series INDOOR UNIT ADB100D MODEL OUTDOOR UNIT AMC100F 98,000 Btu/h NOMINAL CAPACITY 28,720 NOMINAL TOTAL INPUT POWER 10,620 18.1 NOMINAL RUNNING CURRENT 2.89 POWER SOURCE 380~415 / 3 / 50 V/Ph/Hz REFRIGERANT TYPE INDOOR TXV REFRIGERANT CONTROL OPERATION...
  • Page 96 General Data - Cooling Only (R22) D Series INDOOR UNIT ADB125D MODEL OUTDOOR UNIT AMC125F 113,500 Btu/h NOMINAL CAPACITY 33,260 NOMINAL TOTAL INPUT POWER 11,087 NOMINAL RUNNING CURRENT 18.9 3.26 POWER SOURCE 380~415 / 3 / 50 V/Ph/Hz REFRIGERANT TYPE REFRIGERANT CONTROL INDOOR TXV OPERATION...
  • Page 97 General Data - Cooling Only (R407C) D Series INDOOR UNIT ADB75D ADB100D MODEL OUTDOOR UNIT A4MC75D A4MC100D Btu/h 73,000 91,000 NOMINAL CAPACITY 21,400 26,670 NOMINAL TOTAL INPUT POWER 8,080 10,160 NOMINAL RUNNING CURRENT 15.1 18.8 2.64 2.62 POWER SOURCE V/Ph/Hz 380~415 / 3 / 50 380~415 / 3 / 50 REFRIGERANT TYPE...
  • Page 98 General Data - Cooling Only (R407C) D Series INDOOR UNIT ADB125D ADB150D1 MODEL OUTDOOR UNIT A4MC125D A4MC150D Btu/h 108,000 145,000 NOMINAL CAPACITY 31,650 42,500 NOMINAL TOTAL INPUT POWER 12,100 16,239 NOMINAL RUNNING CURRENT 21.6 28.4 2.61 2.61 POWER SOURCE 380~415 / 3 / 50 380~415 / 3 / 50 V/Ph/Hz REFRIGERANT TYPE...
  • Page 99 General Data - Cooling Only (R407C) D Series INDOOR UNIT ADB150D2 ADB200D2 MODEL OUTDOOR UNIT A4MC75D x 2 A4MC100D x 2 Btu/h 146,000 182,000 NOMINAL CAPACITY 42,790 53,500 NOMINAL TOTAL INPUT POWER 16,424 21,100 NOMINAL RUNNING CURRENT 31.1 39.6 2.60 2.53 POWER SOURCE 380~415 / 3 / 50...
  • Page 100 General Data - Cooling Only (R407C) D Series INDOOR UNIT ADB250D2 ADB300D2 MODEL OUTDOOR UNIT A4MC125D x 2 A4MC150D x 2 Btu/h 216,000 290,000 NOMINAL CAPACITY 63,310 84,990 NOMINAL TOTAL INPUT POWER 25,660 33,998 NOMINAL RUNNING CURRENT 45.2 59.2 2.46 2.49 POWER SOURCE 380~415 / 3 / 50...
  • Page 101 General Data - Cooling Only (R407C) D Series INDOOR UNIT ADB400D4 ADB500D4 MODEL OUTDOOR UNIT A4MC100D x 4 A4MC125D x 4 Btu/h 364,000 432,000 NOMINAL CAPACITY 105,510 126,610 NOMINAL TOTAL INPUT POWER 42,500 53,820 NOMINAL RUNNING CURRENT 79.4 93.1 2.48 2.35 POWER SOURCE 380~415 / 3 / 50...

  • Page 102: Components Data

    Components Data - Cooling Only (R22) B Series 1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
  • Page 103 Components Data - Cooling Only (R22) B Series 1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
  • Page 104 Components Data - Cooling Only (R22) B Series 1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
  • Page 105 Components Data - Cooling Only (R22) B Series 1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
  • Page 106 Components Data - Cooling Only (R22) B Series INDOOR UNIT ADB200B2 MODEL OUTDOOR UNIT AMC100B x 2 AMC100C x 2 TYPE CENTRIFUGAL QUANTITY MATERIAL ZINC COATED STEEL INDOOR FAN DRIVE BELT DRIVEN DIAMETER 394.97 / 15.55 mm/in LENGTH 381.0 / 15.0 mm/in TYPE SQUIRREL CAGE INDUCTION...
  • Page 107 Components Data - Cooling Only (R22) B Series INDOOR UNIT ADB250B2 MODEL OUTDOOR UNIT AMC125B x 2 CENTRIFUGAL TYPE QUANTITY MATERIAL ZINC COATED STEEL INDOOR FAN DRIVE BELT DRIVEN DIAMETER 469.90 / 18.50 mm/in 459.99 / 18.11 LENGTH mm/in TYPE SQUIRREL CAGE INDUCTION INDOOR FAN QUANTITY...
  • Page 108 Components Data - Cooling Only (R22) B Series INDOOR UNIT ADB300B2 MODEL OUTDOOR UNIT AMC150C x 2 TYPE CENTRIFUGAL QUANTITY MATERIAL ZINC COATED STEEL INDOOR FAN BELT DRIVEN DRIVE DIAMETER 469.90 / 18.50 mm/in LENGTH 459.99 / 18.11 mm/in TYPE SQUIRREL CAGE INDUCTION INDOOR FAN QUANTITY...
  • Page 109 Components Data - Cooling Only (R22) B Series INDOOR UNIT ADB300B3 MODEL OUTDOOR UNIT AMC100B x 3 AMC100C x 3 TYPE CENTRIFUGAL QUANTITY MATERIAL ZINC COATED STEEL INDOOR FAN DRIVE BELT DRIVEN DIAMETER 469.90 / 18.50 mm/in LENGTH 459.99 / 18.11 mm/in TYPE SQUIRREL CAGE INDUCTION...
  • Page 110 Components Data - Cooling Only (R22) B Series INDOOR UNIT ADB350B3 MODEL OUTDOOR UNIT AMC100B x 1 AMC125B x 2 TYPE CENTRIFUGAL QUANTITY MATERIAL ZINC COATED STEEL INDOOR FAN DRIVE BELT DRIVEN DIAMETER 469.90 / 18.50 mm/in LENGTH 459.99 / 18.11 mm/in TYPE SQUIRREL CAGE INDUCTION...
  • Page 111 Components Data - Cooling Only (R22) B Series INDOOR UNIT ADB400B4 MODEL OUTDOOR UNIT AMC100B x 4 AMC100C x 4 TYPE CENTRIFUGAL QUANTITY MATERIAL ZINC COATED STEEL INDOOR FAN DRIVE BELT DRIVEN DIAMETER 591.82 / 23.30 mm/in LENGTH 563.88 / 22.20 mm/in TYPE SQUIRREL CAGE INDUCTION...
  • Page 112 Components Data - Cooling Only (R22) B Series INDOOR UNIT ADB450B3 MODEL OUTDOOR UNIT AMC150C x 3 TYPE CENTRIFUGAL QUANTITY MATERIAL ZINC COATED STEEL INDOOR FAN BELT DRIVEN DRIVE DIAMETER 591.82 / 23.30 mm/in LENGTH 563.88 / 22.20 mm/in TYPE SQUIRREL CAGE INDUCTION INDOOR FAN QUANTITY...
  • Page 113 Components Data - Cooling Only (R22) B Series INDOOR UNIT ADB500B4 MODEL OUTDOOR UNIT AMC125B x 4 TYPE CENTRIFUGAL QUANTITY MATERIAL ZINC COATED STEEL INDOOR FAN BELT DRIVEN DRIVE DIAMETER 591.82 / 23.30 mm/in LENGTH 563.88 / 22.20 mm/in TYPE SQUIRREL CAGE INDUCTION INDOOR FAN QUANTITY...
  • Page 114 Components Data - Cooling Only (R22) B Series INDOOR UNIT ADB600B4 MODEL OUTDOOR UNIT AMC150C x 4 TYPE CENTRIFUGAL QUANTITY MATERIAL ZINC COATED STEEL INDOOR FAN DRIVE BELT DRIVEN DIAMETER 785.00 / 30.90 mm/in LENGTH 706.00 / 27.79 mm/in TYPE SQUIRREL CAGE INDUCTION INDOOR FAN QUANTITY...
  • Page 115 Components Data - Cooling Only (R22) B Series INDOOR UNIT ADB750B5 MODEL OUTDOOR UNIT AMC150C x 5 TYPE CENTRIFUGAL QUANTITY MATERIAL ZINC COATED STEEL INDOOR FAN BELT DRIVEN DRIVE DIAMETER 785.00 / 30.90 mm/in LENGTH 706.00 / 27.79 mm/in TYPE SQUIRREL CAGE INDUCTION INDOOR FAN QUANTITY...
  • Page 116 Components Data - Cooling Only (R22) D Series INDOOR UNIT ADB75D MODEL OUTDOOR UNIT AMC75D TYPE CENTRIFUGAL QUANTITY MATERIAL ZINC COATED STEEL INDOOR FAN DRIVE DIRECT DIAMETER mm/in 282.70 / 11.13 LENGTH mm/in 203.2 / 8.00 TYPE PERMANENT SPLIT CAPACITOR INDOOR FAN QUANTITY MOTOR...
  • Page 117 Components Data - Cooling Only (R22) D Series INDOOR UNIT ADB100D MODEL OUTDOOR UNIT AMC100D TYPE CENTRIFUGAL QUANTITY MATERIAL ZINC COATED STEEL INDOOR FAN DRIVE DIRECT DIAMETER mm/in 282.70 / 11.13 LENGTH mm/in 203.20 / 8.00 TYPE PERMANENT SPLIT CAPACITOR INDOOR FAN QUANTITY MOTOR...
  • Page 118 Components Data - Cooling Only (R22) D Series INDOOR UNIT ADB125D MODEL OUTDOOR UNIT AMC125D TYPE CENTRIFUGAL QUANTITY MATERIAL ZINC COATED STEEL INDOOR FAN DRIVE BELT DRIVEN DIAMETER mm/in 394.97 / 15.55 LENGTH mm/in 381.00 / 15.00 TYPE SQUIRREL CAGE INDUCTION INDOOR FAN QUANTITY MOTOR...
  • Page 119 Components Data - Cooling Only (R22) D Series INDOOR UNIT ADB150D1 MODEL OUTDOOR UNIT AMC150D TYPE CENTRIFUGAL QUANTITY MATERIAL ZINC COATED STEEL INDOOR FAN BELT DRIVEN DRIVE DIAMETER 394.97 / 15.55 mm/in LENGTH 381.00 / 15.00 mm/in TYPE SQUIRREL CAGE INDUCTION INDOOR FAN QUANTITY MOTOR...
  • Page 120 Components Data - Cooling Only (R22) D Series INDOOR UNIT ADB150D2 MODEL OUTDOOR UNIT AMC75D x 2 TYPE CENTRIFUGAL QUANTITY MATERIAL ZINC COATED STEEL INDOOR FAN DRIVE BELT DRIVEN DIAMETER mm/in 394.97 / 15.55 LENGTH mm/in 381.00 / 15.00 TYPE SQUIRREL CAGE INDUCTION INDOOR FAN QUANTITY...
  • Page 121 Components Data - Cooling Only (R22) D Series INDOOR UNIT ADB200D2 MODEL OUTDOOR UNIT AMC100D x 2 AMC200D2 TYPE CENTRIFUGAL QUANTITY MATERIAL ZINC COATED STEEL INDOOR FAN DRIVE BELT DRIVEN DIAMETER 394.97 / 15.55 mm/in LENGTH 381.00 / 15.00 mm/in TYPE SQUIRREL CAGE INDUCTION INDOOR FAN...
  • Page 122 Components Data - Cooling Only (R22) D Series INDOOR UNIT ADB250D2 MODEL OUTDOOR UNIT AMC125D x 2 AMC250D2 TYPE CENTRIFUGAL QUANTITY MATERIAL ZINC COATED STEEL INDOOR FAN DRIVE BELT DRIVEN DIAMETER 469.90 / 18.50 mm/in LENGTH 459.99 / 18.11 mm/in TYPE SQUIRREL CAGE INDUCTION INDOOR FAN...
  • Page 123 Components Data - Cooling Only (R22) D Series INDOOR UNIT ADB300D2 MODEL OUTDOOR UNIT AMC150D x 2 AMC300D2 TYPE CENTRIFUGAL QUANTITY MATERIAL ZINC COATED STEEL INDOOR FAN DRIVE BELT DRIVEN DIAMETER 469.90 / 18.50 mm/in LENGTH 459.99 / 18.11 mm/in TYPE SQUIRREL CAGE INDUCTION INDOOR FAN...
  • Page 124 Components Data - Cooling Only (R22) D Series INDOOR UNIT ADB400D4 MODEL OUTDOOR UNIT AMC100D x 4 TYPE CENTRIFUGAL QUANTITY MATERIAL ZINC COATED STEEL INDOOR FAN DRIVE BELT DRIVEN DIAMETER mm/in 591.82 / 23.30 LENGTH mm/in 563.88 / 22.20 TYPE SQUIRREL CAGE INDUCTION INDOOR FAN QUANTITY...
  • Page 125 Components Data - Cooling Only (R22) D Series INDOOR UNIT ADB500D4 MODEL OUTDOOR UNIT AMC125D x 4 TYPE CENTRIFUGAL QUANTITY MATERIAL ZINC COATED STEEL INDOOR FAN DRIVE BELT DRIVEN DIAMETER mm/in 591.82 / 23.30 LENGTH mm/in 563.88 / 22.20 TYPE SQUIRREL CAGE INDUCTION INDOOR FAN QUANTITY...
  • Page 126 Components Data - Cooling Only (R22) D Series - Very High Static INDOOR UNIT ADB75D MODEL OUTDOOR UNIT AMC75D TYPE CENTRIFUGAL QUANTITY MATERIAL ZINC COATED STEEL INDOOR FAN DRIVE DIRECT DIAMETER 282.70 / 11.13 mm/in LENGTH 203.20 / 8.00 mm/in TYPE PERMANENT SPLIT CAPACITOR INDOOR FAN...
  • Page 127 Components Data - Cooling Only (R22) D Series - Very High Static INDOOR UNIT ADB100D MODEL OUTDOOR UNIT AMC100D TYPE CENTRIFUGAL QUANTITY MATERIAL ZINC COATED STEEL INDOOR FAN DIRECT DRIVE DIAMETER 282.70 / 11.13 mm/in LENGTH 203.20 / 8.00 mm/in TYPE PERMANENT SPLIT CAPACITOR INDOOR FAN...
  • Page 128 Components Data - Cooling Only (R22) D Series - Very High Static INDOOR UNIT ADB125D MODEL OUTDOOR UNIT AMC125D CENTRIFUGAL TYPE QUANTITY MATERIAL ZINC COATED STEEL INDOOR FAN DRIVE BELT DRIVEN DIAMETER 394.97 / 15.55 mm/in 381.00 / 15.00 LENGTH mm/in TYPE SQUIRREL CAGE INDUCTION...
  • Page 129 Components Data - Cooling Only (R22) D Series - Very High Static INDOOR UNIT ADB150D1 MODEL OUTDOOR UNIT AMC150D CENTRIFUGAL TYPE QUANTITY MATERIAL ZINC COATED STEEL INDOOR FAN DRIVE BELT DRIVEN DIAMETER 394.97 / 15.55 mm/in 381.00 / 15.00 LENGTH mm/in TYPE SQUIRREL CAGE INDUCTION...
  • Page 130 Components Data - Cooling Only (R22) D Series - Very High Static INDOOR UNIT ADB150D2 MODEL OUTDOOR UNIT AMC75D x 2 TYPE CENTRIFUGAL QUANTITY MATERIAL ZINC COATED STEEL INDOOR FAN BELT DRIVEN DRIVE DIAMETER 394.97 / 15.55 mm/in LENGTH 381.00 / 15.00 mm/in TYPE SQUIRREL CAGE INDUCTION...
  • Page 131 Components Data - Cooling Only (R22) D Series INDOOR UNIT ADB75D MODEL OUTDOOR UNIT AMC75F CENTRIFUGAL TYPE QUANTITY ZINC COATED STEEL MATERIAL INDOOR FAN DRIVE DIRECT DIAMETER 282.70 / 11.13 mm/in LENGTH 203.20 / 8.00 mm/in TYPE PERMANENT SPLIT CAPACITOR INDOOR FAN QUANTITY MOTOR...
  • Page 132 Components Data - Cooling Only (R22) D Series INDOOR UNIT ADB100D MODEL OUTDOOR UNIT AMC100F TYPE CENTRIFUGAL QUANTITY ZINC COATED STEEL MATERIAL INDOOR FAN DRIVE DIRECT 282.70 / 11.13 DIAMETER mm/in LENGTH 203.20 / 8.00 mm/in TYPE PERMANENT SPLIT CAPACITOR INDOOR FAN QUANTITY MOTOR...
  • Page 133 Components Data - Cooling Only (R22) D Series INDOOR UNIT ADB125D MODEL OUTDOOR UNIT AMC125F CENTRIFUGAL TYPE QUANTITY ZINC COATED STEEL MATERIAL INDOOR FAN DRIVE BELT DRIVEN DIAMETER 394.97 / 15.55 mm/in LENGTH 381.00 / 15.00 mm/in TYPE INDUCTION INDOOR FAN QUANTITY MOTOR INDEX OF PROTECTION (IP)
  • Page 134 Components Data - Cooling Only (R407C) D Series INDOOR UNIT ADB75D MODEL OUTDOOR UNIT AMC75D TYPE CENTRIFUGAL QUANTITY MATERIAL ZINC COATED STEEL INDOOR FAN DRIVE DIRECT DIAMETER 282.70 / 11.13 mm/in LENGTH 203.20 / 8.00 mm/in TYPE PERMANENT SPLIT CAPACITOR INDOOR FAN QUANTITY MOTOR...
  • Page 135 Components Data - Cooling Only (R407C) D Series INDOOR UNIT ADB100D MODEL OUTDOOR UNIT A4MC100D TYPE CENTRIFUGAL QUANTITY MATERIAL ZINC COATED STEEL INDOOR FAN DRIVE DIRECT DIAMETER 282.70 / 11.13 mm/in LENGTH 203.20 / 8.00 mm/in TYPE PERMANENT SPLIT CAPACITOR INDOOR FAN QUANTITY MOTOR...
  • Page 136 Components Data - Cooling Only (R407C) D Series INDOOR UNIT ADB125D MODEL OUTDOOR UNIT A4MC125D TYPE CENTRIFUGAL QUANTITY MATERIAL ZINC COATED STEEL INDOOR FAN DRIVE BELT DRIVEN DIAMETER 394.97 / 15.55 mm/in LENGTH 381.00 / 15.00 mm/in TYPE SQUIRREL CAGE INDUCTION INDOOR FAN QUANTITY MOTOR...
  • Page 137 Components Data - Cooling Only (R407C) D Series INDOOR UNIT ADB150D1 MODEL OUTDOOR UNIT A4MC150D TYPE CENTRIFUGAL QUANTITY MATERIAL ZINC COATED STEEL INDOOR FAN BELT DRIVEN DRIVE DIAMETER 394.97 / 15.55 mm/in LENGTH 381.00 / 15.00 mm/in TYPE SQUIRREL CAGE INDUCTION INDOOR FAN QUANTITY MOTOR...
  • Page 138 Components Data - Cooling Only (R407C) D Series INDOOR UNIT ADB150D2 MODEL OUTDOOR UNIT A4MC75D x 2 CENTRIFUGAL TYPE QUANTITY MATERIAL ZINC COATED STEEL INDOOR FAN DRIVE BELT DRIVEN DIAMETER 394.97 / 15.55 mm/in 381.00 / 15.00 LENGTH mm/in TYPE SQUIRREL CAGE INDUCTION INDOOR FAN QUANTITY...
  • Page 139 Components Data - Cooling Only (R407C) D Series INDOOR UNIT ADB200D2 MODEL OUTDOOR UNIT A4MC100D x 2 TYPE CENTRIFUGAL QUANTITY MATERIAL ZINC COATED STEEL INDOOR FAN BELT DRIVEN DRIVE DIAMETER 394.97 / 15.55 mm/in LENGTH 381.00 / 15.00 mm/in TYPE SQUIRREL CAGE INDUCTION INDOOR FAN QUANTITY...
  • Page 140 Components Data - Cooling Only (R407C) D Series INDOOR UNIT ADB250D2 MODEL OUTDOOR UNIT A4MC125D x 2 TYPE CENTRIFUGAL QUANTITY MATERIAL ZINC COATED STEEL INDOOR FAN BELT DRIVEN DRIVE DIAMETER 469.90 / 18.50 mm/in LENGTH 459.99 / 18.11 mm/in TYPE SQUIRREL CAGE INDUCTION INDOOR FAN QUANTITY...
  • Page 141 Components Data - Cooling Only (R407C) D Series INDOOR UNIT ADB300D2 MODEL OUTDOOR UNIT AMC150D x 2 CENTRIFUGAL TYPE QUANTITY MATERIAL ZINC COATED STEEL INDOOR FAN DRIVE BELT DRIVEN DIAMETER 469.90 / 18.50 mm/in 459.99 / 18.11 LENGTH mm/in TYPE SQUIRREL CAGE INDUCTION INDOOR FAN QUANTITY...
  • Page 142 Components Data - Cooling Only (R407C) D Series INDOOR UNIT ADB400D4 MODEL OUTDOOR UNIT A4MC100D x 4 TYPE CENTRIFUGAL QUANTITY MATERIAL ZINC COATED STEEL INDOOR FAN DRIVE BELT DRIVEN DIAMETER 591.82 / 23.30 mm/in LENGTH 563.88 / 22.20 mm/in TYPE SQUIRREL CAGE INDUCTION INDOOR FAN QUANTITY...
  • Page 143 Components Data - Cooling Only (R407C) D Series INDOOR UNIT ADB500D4 MODEL OUTDOOR UNIT A4MC125D x 4 TYPE CENTRIFUGAL QUANTITY MATERIAL ZINC COATED STEEL INDOOR FAN DRIVE BELT DRIVEN DIAMETER 591.82 / 23.30 mm/in LENGTH 563.88 / 22.20 mm/in TYPE SQUIRREL CAGE INDUCTION INDOOR FAN QUANTITY...

  • Page 144: Safety Devices

    Safety Devices Data - Cooling Only (R22) B Series 1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE. 1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE. 1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
  • Page 145 Safety Devices Data - Cooling Only (R22) B Series INDOOR UNIT ADB200B2 MODEL OUTDOOR UNIT AMC100B x 2 AMC100C x 2 TYPE AUTO RESET 2937167 / 426 HIGH PRESSURE SWITCH OPEN Pa / psi 2413165 / 350 CLOSE Pa / psi TYPE AUTO RESET SAFETY DEVICE...
  • Page 146 Safety Devices Data - Cooling Only (R22) B Series INDOOR UNIT ADB400B4 MODEL OUTDOOR UNIT AMC100B x 4 AMC100C x 4 TYPE AUTO RESET 2937167 / 426 HIGH PRESSURE SWITCH OPEN Pa / psi 2413165 / 350 CLOSE Pa / psi TYPE AUTO RESET SAFETY DEVICE...
  • Page 147 Safety Devices Data - Cooling Only (R22) D Series INDOOR UNIT ADB75D MODEL OUTDOOR UNIT AMC75D TYPE AUTO RESET HIGH PRESSURE SWITCH 2937167 / 426 OPEN Pa / psi 2413165 / 350 CLOSE Pa / psi TYPE AUTO RESET SAFETY DEVICE LOW PRESSURE SWITCH 124105.6 / 18 OPEN...
  • Page 148 Safety Devices Data - Cooling Only (R22) D Series INDOOR UNIT ADB150D2 MODEL OUTDOOR UNIT AMC75D x 2 TYPE AUTO RESET 2937167 / 426 HIGH PRESSURE SWITCH OPEN Pa / psi 2413165 / 350 CLOSE Pa / psi AUTO RESET TYPE SAFETY DEVICE LOW PRESSURE SWITCH...
  • Page 149 Safety Devices Data - Cooling Only (R22) D Series INDOOR UNIT ADB400D4 MODEL OUTDOOR UNIT AMC100D x 4 TYPE AUTO RESET 2937167 / 426 HIGH PRESSURE SWITCH OPEN Pa / psi 2413165 / 350 CLOSE Pa / psi TYPE AUTO RESET SAFETY DEVICE LOW PRESSURE SWITCH 124105.6 / 18...
  • Page 150 Safety Devices Data - Cooling Only (R22) D Series - Very High Static INDOOR UNIT ADB75D ADB100D MODEL OUTDOOR UNIT AMC75D AMC100D TYPE AUTO RESET HIGH PRESSURE SWITCH 2937167 / 426 OPEN Pa / psi 2413165 / 350 CLOSE Pa / psi TYPE AUTO RESET SAFETY DEVICE...
  • Page 151 Safety Devices Data - Cooling Only (R22) D Series INDOOR UNIT ADB75D MODEL OUTDOOR UNIT AMC75F TYPE AUTO RESET HIGH PRESSURE SWITCH 2937167 / 426 OPEN Pa / psi 2413165 / 350 CLOSE Pa / psi TYPE AUTO RESET SAFETY DEVICE 124105.6 / 18 LOW PRESSURE SWITCH OPEN...
  • Page 152 Safety Devices Data - Cooling Only (R407C) D Series INDOOR UNIT ADB75D ADB100D MODEL OUTDOOR UNIT A4MC75D A4MC100D TYPE AUTO RESET 3240536 / 470 HIGH PRESSURE SWITCH OPEN Pa / psi 2647587 / 384 CLOSE Pa / psi TYPE AUTO RESET SAFETY DEVICE LOW PRESSURE SWITCH 124105.6 / 18...
  • Page 153 Safety Devices Data - Cooling Only (R407C) D Series INDOOR UNIT ADB400D4 ADB500D4 MODEL OUTDOOR UNIT A4MC100D x 4 A4MC125D x 4 TYPE AUTO RESET 3240536 / 470 HIGH PRESSURE SWITCH OPEN Pa / psi 2647587 / 384 CLOSE Pa / psi TYPE AUTO RESET SAFETY DEVICE...

  • Page 154: Performance Data

    Extrapolation method are not allowed to be used to get the TC, SC and PI Example: Model: ADB75B / AMC75B Indoor Condition: 23°C DB, 15°C WB Outdoor Condition: 37°C DB...
  • Page 155 Details: Step: To obtain the Total capacity and Sensible capacity and Power input for (a) Indoor Condition: 25°C DB, 16°C WB Outdoor Condition: 35°C DB Outdoor DB ° C Indoor WB Indoor DB ° C ° C TC (kW) SHC (kW) PI (kW) 20.02 18.71...
  • Page 156 (b) Indoor Condition: 25°C DB, 16°C WB Outdoor Condition: 40°C DB Outdoor DB ° C Indoor WB Indoor DB ° C ° C TC (kW) SHC (kW) PI (kW) 18.01 17.14 8.71 18.52 18.52 8.76 Total capacity, TC Interpolation Method: 25°C - 24°C - 18.01kW ⇒...
  • Page 157 Step: To obtain the Total capacity and Sensible capacity and Power Input for (a) Indoor Condition: 25°C DB, 17°C WB Outdoor Condition: 35°C DB Outdoor DB ° C Indoor DB Indoor WB ° C ° C TC (kW) SC (kW) PI (kW) 20.15 19.28...
  • Page 158 (b) Indoor Condition: 25°C DB, 17°C WB Outdoor Condition: 40°C DB Outdoor DB ° C Indoor DB Indoor WB ° C ° C TC (kW) SC (kW) PI (kW) 18.18 17.60 8.73 19.73 14.32 8.88 Total capacity, TC Interpolation Method: 17°C - 16°C - 18.18kW ⇒...
  • Page 159 Step: To obtain the Total capacity and Sensible capacity for (a) Indoor Condition: 25°C DB, 17°C WB Outdoor Condition: 37°C DB Outdoor DB ° C Indoor DB Indoor WB ° C ° C (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) 20.74...

  • Page 160: Performance Tables

    B SERIES (R22) MODEL : ADB75B ~ AMC75B Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 21.72 16.14 6.46 21.03 15.78 6.90 20.30 15.41 7.42 19.52 15.00 8.00 17.56 13.70 8.66 16.31 12.96 9.53 24°C 21.81 19.22 6.46 21.12...
  • Page 161 B SERIES (R22) MODEL : ADB100B ~ AMC100B Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 28.96 19.61 7.98 28.05 19.18 8.53 27.07 18.72 9.16 26.02 18.23 9.89 23.42 16.65 10.70 21.75 15.75 11.78 24°C 29.08 23.36 7.99 28.16 22.87 8.54...
  • Page 162 B SERIES (R22) MODEL : ADB125B2 ~ AMC125B Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 36.19 25.19 9.40 35.05 24.63 10.05 33.83 24.04 10.80 32.52 23.42 11.65 29.26 21.38 12.61 27.18 20.22 13.88 24°C 36.33 30.00 9.41 35.19 29.38 10.06...
  • Page 163 B SERIES (R22) MODEL : ADB200B2 ~ AMC100B x 2 Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 57.91 39.21 16.58 56.07 38.35 17.71 54.12 37.43 19.04 52.03 36.46 20.54 46.82 33.28 22.23 43.49 31.48 24.47 24°C 58.13 46.71 16.59 56.30...
  • Page 164 B SERIES (R22) MODEL : ADB250B2 ~ AMC125B x 2 Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 72.40 50.39 19.73 70.11 49.28 21.08 67.67 48.10 22.65 65.06 46.85 24.45 58.54 42.77 26.45 54.38 40.46 29.12 24°C 72.69 60.02 19.75 70.39...
  • Page 165 B SERIES (R22) MODEL : ADB300B3 ~ AMC100C x 3 Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 86.86 58.82 24.46 84.11 57.52 26.14 81.19 56.15 28.09 78.05 54.69 30.31 70.23 49.92 32.80 65.24 47.23 36.11 24°C 87.20 70.06 24.48 84.45...
  • Page 166 B SERIES (R22) MODEL : ADB350B3 ~ AMC100B + AMC125B x 2 Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 101.34 70.53 27.84 98.13 68.97 29.75 94.72 67.33 31.97 91.05 65.57 34.50 81.94 59.86 37.33 76.11 56.63 41.10 24°C 101.73 84.01...
  • Page 167 MODEL : ADB400B4 ~ AMC100C x 4 Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 115.81 78.42 32.22 112.15 76.69 34.44 108.25 74.86 37.00 104.06 72.91 39.93 93.64 66.57 43.21 86.99 62.97 47.57 24°C 116.27 93.41 32.25 112.60 91.47 34.47 108.70...
  • Page 168 B SERIES (R22) MODEL : ADB500B4 ~ AMC125B x 4 Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 144.77 100.75 40.47 140.19 98.53 43.25 135.31 96.18 46.47 130.08 93.67 50.15 117.05 85.52 54.26 108.73 80.90 59.75 24°C 145.33 120.01 40.51 140.75...
  • Page 169 B SERIES (R22) MODEL : ADB750B5 ~ AMC150C x 5 Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 217.15 142.96 71.42 210.28 139.81 76.33 202.96 136.47 82.03 195.11 132.92 88.51 175.58 121.34 95.77 163.10 114.79 105.45 24°C 218.00 170.28 71.49 211.12...
  • Page 170 D SERIES (R22) MODEL : ADB75D ~ AMC75D Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 20.72 14.46 5.90 19.99 14.09 6.38 19.25 13.71 6.91 18.47 13.31 7.49 16.96 12.39 8.13 15.66 11.65 8.96 24°C 20.75 17.32 5.90 20.01 16.92 6.38...
  • Page 171 D SERIES (R22) MODEL : ADB125D ~ AMC125D Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 36.20 25.87 8.95 35.05 25.30 9.57 33.83 24.70 10.28 32.52 24.05 11.09 29.27 21.96 12.00 27.19 20.77 13.22 24°C 36.34 30.82 8.96 35.19 30.18 9.58...
  • Page 172 D SERIES (R22) MODEL : ADB150D2 ~ AMC75D x 2 Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 43.44 30.23 12.39 42.07 29.57 13.24 40.60 28.86 14.23 39.03 28.11 15.35 35.12 25.66 16.61 32.63 24.28 18.29 24°C 43.61 36.01 12.40 42.23...
  • Page 173 D SERIES (R22) MODEL : ADB200D2 ~ AMC200D2 Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 57.91 43.02 17.04 56.07 42.07 18.21 54.12 41.07 19.57 52.03 40.00 21.11 46.82 36.52 22.85 43.49 34.55 25.15 24°C 58.13 51.25 17.06 56.30 50.18 18.23...
  • Page 174 MODEL : ADB250D2 ~ AMC250D2 Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 72.38 53.78 20.59 70.09 52.59 22.00 67.65 51.34 23.65 65.04 50.00 25.52 58.53 45.65 27.61 54.37 43.18 30.40 24°C 72.67 64.06 20.61 70.37 62.73 22.03 67.94 61.32 23.67...
  • Page 175 D SERIES (R22) MODEL : ADB300D2 ~ AMC300D2 Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 86.88 64.55 26.42 84.13 63.13 28.24 81.20 61.62 30.34 78.06 60.02 32.74 70.25 54.79 35.43 65.26 51.83 39.01 24°C 87.22 76.89 26.45 84.47 75.29 28.27...
  • Page 176 D SERIES (R22) MODEL : ADB500D4 ~ AMC125D x 4 Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 144.77 100.75 40.06 140.19 98.53 42.82 135.31 96.18 46.01 130.08 93.67 49.65 117.05 85.52 53.72 108.73 80.90 59.15 145.33 120.01 40.10 140.75 117.51...
  • Page 177 D SERIES (R22) MODEL : ADB100D ~ AMC100F Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 28.38 21.89 8.33 27.48 21.40 8.90 26.53 20.89 9.57 25.50 20.35 10.32 22.95 18.58 11.17 21.32 17.57 12.30 24°C 28.49 26.07 8.34 27.59 25.53 8.91...
  • Page 178 D SERIES (R407C) MODEL : ADB75D ~ A4MC75D Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 20.17 14.27 6.14 19.46 13.90 6.64 18.73 13.52 7.19 17.98 13.13 7.80 16.51 12.22 8.46 15.24 11.50 9.33 24°C 20.20 17.08 6.14 19.48 16.69 6.64...
  • Page 179 D SERIES (R407C) MODEL : ADB125D ~ A4MC125D Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 31.28 23.53 9.49 30.29 23.01 10.14 29.23 22.46 10.90 28.10 21.88 11.76 25.29 19.97 12.73 23.49 18.89 14.01 24°C 31.40 28.03 9.50 30.41 27.45 10.15...
  • Page 180 R407C MODEL : ADB150D2 ~ A4MC75D x 2 Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 42.28 29.83 12.88 40.95 29.17 13.77 39.52 28.47 14.80 37.99 27.73 15.97 34.19 25.32 17.28 31.76 23.95 19.02 24°C 42.45 35.53 12.90 41.11 34.79 13.78...
  • Page 181 R407C MODEL : ADB250D2 ~ A4MC125D x 2 Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 62.56 47.07 20.13 60.58 46.03 21.51 58.47 44.93 23.12 56.21 43.76 24.94 50.58 39.95 26.99 46.99 37.79 29.72 24°C 62.81 56.07 20.15 60.82 54.90 21.53...
  • Page 182 R407C MODEL : ADB400D4 ~ A4MC100D x 4 Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 104.26 75.50 33.34 100.96 73.84 35.63 97.45 72.08 38.29 93.68 70.20 41.32 84.30 64.09 44.70 78.31 60.63 49.22 24°C 104.67 89.94 33.37 101.37 88.06 35.67...

  • Page 183: Outline And Dimension

    8. DIMENSIONAL DATA INDOOR ADB~B SERIES MODEL : ADB 75 / 100 B Dimension in mm MODEL : ADB 125B Dimension in mm...
  • Page 184 MODEL : ADB 150B Dimension in mm...
  • Page 185 MODEL : ADB200B2 NOTE : FOR VERTICAL AIR DISCHARGE Dimension in mm MODEL : ADB250/300B2 NOTE : FOR VERTICAL AIR DISCHARGE Dimension in mm...
  • Page 186 MODEL : ADB300B3 NOTE : FOR VERTICAL AIR DISCHARGE Dimension in mm MODEL : ADB350B3 NOTE : FOR VERTICAL AIR DISCHARGE Dimension in mm...
  • Page 187 MODEL : ADB400/500B4, ADB450B3 NOTE : FOR VERTICAL AIR DISCHARGE Note : ADB200-500B models are available in vertical air discharge as standard; Convertible at field. Dimension in mm MODEL : ADB600B4 *CAN CUSTOMIZE TO TO HORIZONTAL OR VERTICAL AIR DISCHARGE; NOT CONVERTIBLE AT FIELD NOTE : FOR VERTICAL AIR DISCHARGE Dimension in mm...
  • Page 188 MODEL : ADB750B5 *CAN CUSTOMIZE TO TO HORIZONTAL OR VERTICAL AIR DISCHARGE; NOT CONVERTIBLE AT FIELD NOTE : FOR VERTICAL AIR DISCHARGE Dimension in mm...
  • Page 189 ADB ~ D SERIES MODEL : ADB 75D Dimension in mm MODEL : ADB 100D Dimension in mm...
  • Page 190 MODEL : ADB 125D Dimension in mm MODEL : ADB 125D2 Dimension in mm...
  • Page 191 MODEL : ADB 150D1 Dimension in mm MODEL : ADB 150D2 Dimension in mm...
  • Page 192 MODEL : ADB 200D2 Dimension in mm MODEL : ADB 250D2 Dimension in mm...
  • Page 193 MODEL : ADB 300D2 Dimension in mm MODEL : ADB 400D4 Dimension in mm...
  • Page 194 MODEL : ADB 500D4 Note : ADB200-500D4 models are available in vertical air discharge as standard; Convertible at field. Dimension in mm...
  • Page 195 OUTDOOR MODEL : AMC 75 / 100 / 125B NOTE : FOR VERTICAL AIR DISCHARGE Dimension in mm MODEL : AMC 75C Dimension in mm...
  • Page 196 MODEL : AMC 100C Dimension in mm MODEL : AMC 150C Dimension in mm...
  • Page 197 MODEL : A(4)MC 75 / 100D Dimension in mm MODEL : A(4)MC 125D Dimension in mm...
  • Page 198 MODEL : A(4)MC 150D Dimension in mm MODEL : AMC 200D2 Dimension in mm...
  • Page 199 MODEL : AMC 250 / 300D2 Dimension in mm...
  • Page 200 MODEL : AMC 75F Dimension in mm MODEL : AMC 100-125F Dimension in mm...

  • Page 201: Electrical Data

    9. ELECTRICAL DATA Electrical Data - Cooling Only (R22) B Series INDOOR UNIT ADB75B ADB75B MODEL OUTDOOR UNIT AMC75B AMC75C INSULATION GRADE CLASS F CLASS F POWER SOURCE V/Ph/Hz 220~240 / 1 / 50 220~240 / 1 / 50 RATED INPUT POWER...
  • Page 202 Electrical Data - Cooling Only (R22) B Series INDOOR UNIT ADB125B MODEL OUTDOOR UNIT AMC125B INSULATION GRADE CLASS F POWER SOURCE V/Ph/Hz 380~415 / 3 / 50 RATED INPUT POWER 1490 INDOOR MOTOR RATED RUNNING CURRENT 2.90 MOTOR OUTPUT 1140 POLES INSULATION GRADE CLASS F...
  • Page 203 Electrical Data - Cooling Only (R22) B Series INDOOR UNIT ADB200B2 MODEL OUTDOOR UNIT AMC100B x 2 AMC100C x 2 INSULATION GRADE CLASS F POWER SOURCE V/Ph/Hz 380~415 / 3 / 50 RATED INPUT POWER 3625 INDOOR MOTOR RATED RUNNING CURRENT MOTOR OUTPUT 3000 POLES...
  • Page 204 Electrical Data - Cooling Only (R22) B Series INDOOR UNIT ADB300B3 MODEL OUTDOOR UNIT AMC100B x 3 AMC100C x 3 INSULATION GRADE CLASS F POWER SOURCE V/Ph/Hz 380~415 / 3 / 50 4749 RATED INPUT POWER INDOOR MOTOR RATED RUNNING CURRENT 4000 MOTOR OUTPUT POLES...
  • Page 205 Electrical Data - Cooling Only (R22) B Series INDOOR UNIT ADB400B4 MODEL OUTDOOR UNIT AMC100B x 4 AMC100C x 4 INSULATION GRADE CLASS F POWER SOURCE V/Ph/Hz 380~415 / 3 / 50 6413 RATED INPUT POWER INDOOR MOTOR 11.6 RATED RUNNING CURRENT 5500 MOTOR OUTPUT POLES...
  • Page 206 Electrical Data - Cooling Only (R22) B Series INDOOR UNIT ADB600B4 ADB750B5 MODEL OUTDOOR UNIT AMC150C x 4 AMC150C x 5 INSULATION GRADE CLASS F CLASS F POWER SOURCE V/Ph/Hz 380~415 / 3 / 50 380~415 / 3 / 50 RATED INPUT POWER 12495 16951...
  • Page 207 Electrical Data - Cooling Only (R22) D Series INDOOR UNIT ADB75D MODEL OUTDOOR UNIT AMC75D INSULATION GRADE CLASS F 220~240 / 1 / 50 POWER SOURCE V/Ph/Hz RATED INPUT POWER INDOOR MOTOR RATED RUNNING CURRENT MOTOR OUTPUT POLES INSULATION GRADE CLASS F 380~415 / 3 / 50 POWER SOURCE...
  • Page 208 Electrical Data - Cooling Only (R22) D Series INDOOR UNIT ADB125D MODEL OUTDOOR UNIT AMC125D INSULATION GRADE CLASS F 380~415 / 3 / 50 POWER SOURCE V/Ph/Hz 1420 RATED INPUT POWER INDOOR MOTOR RATED RUNNING CURRENT 1500 MOTOR OUTPUT POLES INSULATION GRADE CLASS F 380~415 / 3 / 50...
  • Page 209 Electrical Data - Cooling Only (R22) D Series INDOOR UNIT ADB150D1 ADB150D2 MODEL OUTDOOR UNIT AMC150D AMC75D x 2 INSULATION GRADE CLASS F CLASS F POWER SOURCE V/Ph/Hz 380~415 / 3 / 50 380~415 / 3 / 50 RATED INPUT POWER 1740 1740 INDOOR MOTOR...
  • Page 210 Electrical Data - Cooling Only (R22) D Series INDOOR UNIT ADB250D2 MODEL OUTDOOR UNIT AMC125D x 2 AMC250D2 INSULATION GRADE CLASS F POWER SOURCE V/Ph/Hz 380~415 / 3 / 50 380~415 / 3 / 50 RATED INPUT POWER 4300 4300 INDOOR MOTOR RATED RUNNING CURRENT MOTOR OUTPUT...
  • Page 211 Electrical Data - Cooling Only (R22) D Series INDOOR UNIT ADB400D4 MODEL OUTDOOR UNIT AMC100D x 4 INSULATION GRADE CLASS F POWER SOURCE V/Ph/Hz 380~415 / 3 / 50 RATED INPUT POWER 5900 INDOOR MOTOR 11.0 RATED RUNNING CURRENT 7500 MOTOR OUTPUT POLES INSULATION GRADE...
  • Page 212 Electrical Data - Cooling Only (R22) D Series - Very High Static INDOOR UNIT ADB75D ADB100D MODEL OUTDOOR UNIT AMC75D AMC100D INSULATION GRADE CLASS F CLASS F POWER SOURCE V/Ph/Hz 220~240 / 1 / 50 220~240 / 1 / 50 RATED INPUT POWER 1283 1732...
  • Page 213 Electrical Data - Cooling Only (R22) D Series - Very High Static INDOOR UNIT ADB150D1 ADB150D2 MODEL OUTDOOR UNIT AMC150D AMC75D x 2 INSULATION GRADE CLASS F CLASS F POWER SOURCE V/Ph/Hz 380~415 / 3 / 50 380~415 / 3 / 50 RATED INPUT POWER 1865 1865...
  • Page 214 Electrical Data - Cooling Only (R22) D Series INDOOR UNIT ADB100D MODEL OUTDOOR UNIT AMC100F INSULATION GRADE CLASS B 220~240 / 1 / 50 POWER SOURCE V/Ph/Hz RATED INPUT POWER 1405 INDOOR MOTOR 6.11 RATED RUNNING CURRENT MOTOR OUTPUT POLES INSULATION GRADE CLASS F 220~240 / 1 / 50...
  • Page 215 Electrical Data - Cooling Only (R407C) D Series INDOOR UNIT ADB75D ADB100D MODEL OUTDOOR UNIT A4MC75D A4MC100D INSULATION GRADE CLASS F CLASS F POWER SOURCE V/Ph/Hz 220~240 / 1 / 50 220~240 / 1 / 50 RATED INPUT POWER 1010 INDOOR MOTOR RATED RUNNING CURRENT MOTOR OUTPUT...
  • Page 216 Electrical Data - Cooling Only (R407C) D Series INDOOR UNIT ADB150D2 ADB200D2 MODEL OUTDOOR UNIT A4MC75D x 2 A4MC100D x 2 INSULATION GRADE CLASS F CLASS F POWER SOURCE V/Ph/Hz 380~415 / 3 / 50 380~415 / 3 / 50 RATED INPUT POWER 1740 2800...
  • Page 217 Electrical Data - Cooling Only (R407C) D Series INDOOR UNIT ADB400D4 ADB500D4 MODEL OUTDOOR UNIT A4MC100D x 4 A4MC125D x 4 INSULATION GRADE CLASS F CLASS F POWER SOURCE V/Ph/Hz 380~415 / 3 / 50 380~415 / 3 / 50 RATED INPUT POWER 5900 11100...

  • Page 218: Wiring Diagrams

    10. WIRING DIAGRAMS COOLING UNIT MODEL : ADB 75B vs AMC 75B...
  • Page 219 COOLING UNIT MODEL : ADB 75B vs AMC 75C...
  • Page 220 COOLING UNIT MODEL : ADB 100B vs AMC 100B...
  • Page 221 COOLING UNIT MODEL : ADB 100B vs AMC 100C...
  • Page 222 COOLING UNIT MODEL : ADB 125B vs AMC 125B...
  • Page 223 COOLING UNIT MODEL : ADB 150B vs AMC 150C...
  • Page 224 COOLING UNIT MODEL : ADB 75D vs A(4)MC 75D...
  • Page 225 MODEL : ADB 100D vs A(4)MC 100D...
  • Page 226 MODEL : ADB 125D vs A(4)MC 125D...
  • Page 227 MODEL : ADB 150D1 vs A(4)MC 150D...
  • Page 228 MODEL : ADB 75D vs AMC 75F...
  • Page 229 MODEL : ADB 100D vs AMC 100F...
  • Page 230 MODEL : ADB 125D vs AMC 125F...
  • Page 231 MODEL : ADB 200B2 vs AMC 100B x 2 ADB 150D2 vs A(4)MC 75D x 2 ADB 200B2 vs AMC 100C x 2 ADB 200D2 vs A(4)MC 100D x 2 ADB 250B2 vs AMC 125B x 2 ADB 250D2 vs A(4)MC 125D x 2...
  • Page 232 MODEL : ADB 200D2 vs AMC 200D2 ADB 250D2 vs AMC 250D2...
  • Page 233 MODEL : ADB 300B2 vs AMC 150C x 2 ADB 300D2 vs A(4)MC 150D x 2...
  • Page 234 MODEL : ADB 300D2 vs AMC 300D2...
  • Page 235 MODEL : ADB 300B3 vs AMC 100B x 3 ADB 300B3 vs AMC 100C x 3 ADB 350B3 vs AMC 125B x 2 + AMC 100B...
  • Page 236 MODEL : ADB 450B3 vs AMC 150C x 3...
  • Page 237 MODEL : ADB 400B4 vs AMC 100B x 4 ADB 400B4 vs AMC 100C x 4 ADB 400D4 vs A(4)MC 100D x 4 ADB 500D4 vs A(4)MC 125D x 4...
  • Page 238 MODEL : ADB 600B4 vs AMC 150C x 4...
  • Page 239 MODEL : ADB 750B5 vs AMC 150C x 5 (WITH MAGNETIC CONTACTOR AS STANDARD)

  • Page 240: Servicing And Maintenance

    11. SERVICING AND MAINTENANCE The design concept of the Condensing Unit is such that all servicing can be done from the front and side of the unit. Upon removal of front and side panel, all the electrical “terminal box”, fan and motor assembly and compressor are easily accessible.
  • Page 241 Make sure the air conditioner is properly grounded by checking the ground terminal. MAINTENANCE For superb performance and lasting durability, please do not forget to conduct proper and regular maintenance. Cleaning The Outdoor Unit Heat Exchanger If you use your air conditioner for prolonged period of time, the outdoor unit heat exchanger will become dirty impairing its function and reducing the performance of the air conditioned.

  • Page 242: Troubleshooting

    12. TROUBLESHOOTING When a malfunction of the air conditioner unit is detected, immediately switch off the main power supply before proceeding with the following troubleshooting procedures. The following are common fault conditions and simple troubleshooting tips. If any other fault conditions which are not listed occur, contact your nearest local dealer.
  • Page 243 Diagnostic Guidelines By means of pressure reading: Pressure Data Probable cause Circuit High side ● 1. Overcharged with refrigerant. Low side ● 2. Non-condensable gases in refrigerant circuit (e.g. air) 3. Obstructed air-intake / discharge. 4. Hot air short circuiting in outdoor unit. High side ●...
  • Page 244 By means of diagnostic flow chart: Generally, there are two kinds of problems, i.e. starting failure and insufficient cooling/heating. “Starting failure” is caused by electrical defect while improper application or defects in refrigerant circuit causes “Insufficient cooling / heating”. i) Diagnosis of Electric Circuit The most common causes of air conditioner failure to “start”...
  • Page 245 ii ) Diagnosis of Refrigerant Circuit / Application There might be some causes where the unit starts running but does not perform satisfactorily, i.e. insufficient cooling. Judgement could be made by measuring temperature difference of indoor unit’s intake and discharge air as well as running current.
  • Page 246 Satisfactory operation with temperature difference of air intake & discharge of indoor unit 14°C to 20°C. * ( * value is for reference only )

  • Page 247: Exploded View And Part List

    13. EXPLODED VIEW AND PARTS LIST INDOOR MODELS MODEL : ADB75B DESCRIPTION DESCRIPTION ASSY, BASE PAN ASSY, SIDE PANEL RIGHT BIG PANEL, BASE COVER TERMINAL COVER ASSY, DRAIN PAN SCREW, S.T TRUSSD HEAD PHILIP ASSY, DRAIN PAN SMALL SCREW, SELF TAPPING...
  • Page 248 MODEL : ADB100B DESCRIPTION DESCRIPTION ASSY, BASE PAN ASSY, SIDE PANEL RIGHT BIG PANEL, BASE COVER TERMINAL COVER ASSY, DRAIN PAN SCREW, S.T TRUSSD HEAD PHILIP ASSY, DRAIN PAN SMALL SCREW, SELF TAPPING ASSY, COIL SCREW, TRUSS HEAD PHILIP ASSY, COIL SIDE COVER LEFT SCREW, TRUSS HEAD PHILIP ASSY, SIDE PANEL LEFT SCREW WOOD...
  • Page 249 MODEL : ADB125B DESCRIPTION DESCRIPTION ASSY, BASE PAN ASSY, FILTER ASSY, BLOWER HOUSING PANEL, SIDE BIG SUPPORT BLOWER COVER, TERMINAL ASSY, DRIVE PACKAGE SCREW, S.T TRUSSD HEAD PHILIP ASSY, MOTOR BRACKET SCREW, SELF TAPPING MOTOR SCREW, TRUSSD HEAD PHILIP ASSY, DRAIN PAN SCREW, TRUSSD HEAD PHILIP ASSY, COIL TUBING SCREW, WOOD...
  • Page 250 MODEL : ADB150B1 DESCRIPTION DESCRIPTION ASSY, BASE PAN FILTER ASSY, BLOWER HOUSING PANEL, SIDE BIG SUPPORT BLOWER COVER, TERMINAL ASSY, DRIVE PACKAGE SCREW, S.T TRUSSD HEAD PHILIP ASSY, MOTOR BRACKET SCREW, SELF TAPPING MOTOR, 1.5KW 50HZ SCREW, TRUSSD HEAD PHILIP ASSY, DRAIN PAN SCREW, TRUSSD HEAD PHILIP ASSY, COIL TUBING...
  • Page 251 MODEL : ADB200B2 DESCRIPTION DESCRIPTION ASSY, BASE PAN ASSY, PANEL SMALL SIDE L BLOWER ASSY, TER. BOX SUPT, BLOWER L ASSY, PANEL F SUPT, BLOWER R FLANGE, BLOWER T/B PULLEY, 2 SPZ 140/1610 FLANGE, BLOWER L/R BASE, MOTOR UPPER ASSY, PANEL T BASE, MOTOR LOWER COVER, BLOWER MOTOR...
  • Page 252 MODEL : ADB 250 / 300 B2 DESCRIPTION NO. DESCRIPTION ASSY, BASE PAN PANEL, SIDE L BLOWER COVER, COIL SIDE R SUPT, BLOWER L PANEL, SMALL SIDE R SUPT, BLOWER L ADB 250B2 PULLEY, 2 SPZ 180/2012 ADB 300B2 BASE, MOTOR UPPER ASSY, PANEL F BASE, MOTOR LOWER FLANGE, BLOWER T/B...
  • Page 253 MODEL : ADB300B3 DESCRIPTION DESCRIPTION ASSY, BASE PAN PANEL, SMALL SIDE R BLOWER ASSY, PANEL F SUPT, BLOWER L FLANGE, BLOWER T/B SUPT, BLOWER L FLANGE, BLOWER L/R PULLEY, 2 SPZ 180/2012 ASSY, PANEL T BASE, MOTOR UPPER COVER, BLOWER BASE, MOTOR LOWER ASSY, FILTER SUPT.
  • Page 254 MODEL : ADB350B3 DESCRIPTION DESCRIPTION ASSY, BASE PAN PANEL, SMALL SIDE R BLOWER ASSY, PANEL F BLOWER, SUPT L FLANGE, BLOWER L/R BLOWER, SUPT R FLANGE, BLOWER T/B PULLEY, 2 SPZ 250/2012 ASSY, PANEL T BASE, MOTOR UPPER COVER, BLOWER BASE, MOTOR LOWER ASSY, FILTER SUPT.
  • Page 255 MODEL : ADB400B4 DESCRIPTION DESCRIPTION ASSY, BASE PAN PANEL, BACK SIDE R BLOWER PANEL, SIDE FRONT L/R SUPT, BLOWER L ASSY, PANEL F SUPT, BLOWER R FLANGE, BLOWER L/R SUPT, BLOWER F/B FLANGE, BLOWER T/B PULLEY, 2 SPA 250/2517 ASSY, PANEL T BASE, MOTOR UPPER COVER, BLOWER BASE, MOTOR LOWER...
  • Page 256 MODEL : ADB450B3 DESCRIPTION DESCRIPTION ASSY, BASE PAN PANEL, SIDE BACK R BLOWER PANEL, SIDE FRONT L/R SUPT, BLOWER L ASSY, PANEL F SUPT, BLOWER R FLANGE, BLOWER L/R SUPT, BLOWER F/B FLANGE, BLOWER T/B PULLEY, 2 SPA 250/2517 ASSY, PANEL T BASE, MOTOR UPPER COVER, BLOWER BASE, MOTOR LOWER...
  • Page 257 MODEL : ADB500B4 DESCRIPTION DESCRIPTION ASSY, BASE PAN PANEL, SIDE BACK R HEADER BLOWER PANEL, SIDE FRONT L/R SUPT, BLOWER L ASSY, PANEL F SUPT, BLOWER R FLANGE, BLOWER L/R SUPT, BLOWER F/B FLANGE, BLOWER T/B PULLEY, 2 SPA 315/2517 ASSY, PANEL T BASE, MOTOR UPPER COVER, BLOWER...
  • Page 258 MODEL : ADB600B4 DESCRIPTION DESCRIPTION ASSY, BASE PAN PANEL, SIDE BACK R BLOWER PANEL, SIDE FRONT L PANEL , BLOWER DUCT L/R PANEL, SIDE FRONT T/R PANEL , BLOWER DUCT L/R FLANGE, BLOWER F/B PANEL, BLOWER DUCT F/B FLANGE, BLOWER L/R PULLEY, 3 SPA 400/3020 PANEL, TOP BIG STRUC, MOTOR UPPER BASE...
  • Page 259 MODEL : ADB750B5 DESCRIPTION DESCRIPTION ASSY, BASE PAN PANEL, SIDE BACK R BLOWER PANEL, SIDE FRONT L PULLEY, 3 SPA 400/3020 ASSY, PANEL FRONT L/R BELT PANEL, TOP BIG PANEL, BLOWER DUCT F/B PANEL, TOP SMALL PANEL, BLOWER DUCT L/R FLANGE, BLOWER F/B STRUC, MOTOR UPPER BASE FLANGE, BLOWER L/R...
  • Page 260 MODEL : ADB75D DESCRIPTION DESCRIPTION ASSY, BASE PAN ASSY, DRAIN PAN ASSY, PANEL FRONT ASSY, COIL ASSY, BLOWER FLANGE COVER, COIL SIDE R MOTOR BRACKET COVER, COIL SIDE L MOTOR PANEL, SIDE L CAPACITOR PANEL, SIDE SMALL R CLAMP, CAPACITOR PANEL, SIDE BIG R SUPT, BLOWER BRACKET PANEL, TOP...
  • Page 261 MODEL : ADB100D DESCRIPTION DESCRIPTION ASSY, BASE PAN ASSY, DRAIN PAN ASSY, PANEL F ASSY, COIL ASSY, BLOWER FLANGE COVER, COIL SIDE R MOTOR BRACKET COVER, COIL SIDE L MOTOR PANEL, SIDE L CAPACITOR PANEL, SIDE SMALL R CLAMP, CAPACITOR PANEL, SIDE BIG R SUPT, BLOWER BRACKET PANEL, TOP...
  • Page 262 MODEL : ADB125D DESCRIPTION DESCRIPTION ASSY, BASE PAN ASSY, DRAIN PAN BLOWER ASSY, COIL SUPT, BLOWER BRACKET L COVER, COIL L SUPT, BLOWER BRACKET R PANEL, SIDE L BASE, MOTOR LOWER COVER, COIL R BASE, MOTOR UPPER PANEL, SIDE SMALL R MOTOR ASSY, PANEL F PULLEY, 1 SPZ 85/1210...
  • Page 263 MODEL : ADB125D2 DESCRIPTION DESCRIPTION ASSY, BASE PAN ASSY, DRAIN PAN BLOWER ASSY, COIL SUPT, BLOWER BRACKET L COVER, COIL L SUPT, BLOWER BRACKET R PANEL, SIDE L BASE, MOTOR LOWER COVER, COIL R BASE, MOTOR UPPER PANEL, SIDE SMALL R MOTOR ASSY, PANEL F PULLEY, 1 SPZ 85/1210...
  • Page 264 MODEL : ADB150D DESCRIPTION DESCRIPTION ASSY, BASE PAN ASSY, DRAIN PAN BLOWER ASSY, COIL SUPT, BLOWER BRACKET L COVER, COIL L SUPT, BLOWER BRACKET R PANEL, SIDE L BASE, MOTOR LOWER COVER, COIL R BASE, MOTOR UPPER PANEL, SIDE SMALL R MOTOR ASSY, PANEL FRONT PULLEY, 1 SPZ 85/1210...
  • Page 265 MODEL : ADB150D2 DESCRIPTION DESCRIPTION ASSY, BASE PAN ASSY, DRAIN PAN BLOWER ASSY, COIL SUPT, BLOWER BRACKET L COVER, COIL L SUPT, BLOWER BRACKET R PANEL, SIDE L BASE, MOTOR LOWER COVER, COIL R BASE, MOTOR UPPER PANEL, SIDE SMALL R MOTOR ASSY, PANEL FRONT PULLEY, 1 SPZ 85/1210...
  • Page 266 MODEL : ADB200D2 DESCRIPTION DESCRIPTION ASSY, BASE PAN ASSY, COIL L SUPT, BLOWER L ASSY, COIL R SUPT, BLOWER R ASSY, PANEL F BLOWER COVER, BLOWER PULLEY, 2P2 125/160 PANEL, HEADER L BASE, MOTOR UPPER PANEL, HEADER R SHEET, RUBBER ASSY, PANEL TOP MOTOR ASSY, BLOWER FLANGE...
  • Page 267 MODEL : ADB250D2 DESCRIPTION DESCRIPTION ASSY, BASE PAN ASSY, COIL L SUPT, BLOWER L ASSY, COIL R SUPT, BLOWER R ASSY, PANEL F BLOWER COVER, BLOWER PULLEY, 2 SPZ 180/2012 ASSY, HEADER PANEL L BASE, MOTOR UPPER PANEL, HEADER R SHEET, RUBBER ASSY, PANEL T MOTOR...
  • Page 268 MODEL : ADB300D2 DESCRIPTION DESCRIPTION ASSY, BASE PAN ASSY, COIL L SUPT, BLOWER L ASSY, COIL R SUPT, BLOWER R ASSY, PANEL F BLOWER COVER, BLOWER PULLEY, 2 SPZ 250/2012 ASSY, HEADER PANEL L BASE, MOTOR UPPER PANEL, HEADER R SHEET, RUBBER PANEL, TOP R MOTOR...
  • Page 269 MODEL : ADB400D4 DESCRIPTION DESCRIPTION ASSY, BASE PAN ASSY, COIL T/L SUPT, BLOWER L ASSY, COIL BT R SUPT, BLOWER R ASSY, COIL T/R BLOWER ASSY, PANEL F PULLEY, 2 SPZ 315/2012 COVER, BLOWER BASE, MOTOR UPPER PANEL, HEADER L SHEET, RUBBER PANEL, HEADER R MOTOR...
  • Page 270 MODEL : ADB500D4 DESCRIPTION DESCRIPTION ASSY, BASE PAN ASSY, COIL T/L SUPT, BLOWER L ASSY, COIL BT R SUPT, BLOWER R ASSY, COIL T/R BLOWER ASSY, PANEL F PULLEY, 3 SPA 250/2517 COVER, BLOWER BASE, MOTOR UPPER PANEL, HEADER L SHEET, RUBBER PANEL, HEADER R MOTOR...
  • Page 271 OUTDOOR MODELS MODEL : AMC75B DESCRIPTION DESCRIPTION ASSY, BASE PAN BRACKET, HOISTING ASSY, COMPRESSOR STRUCTURE, TUBE SUPPORT ASSY, STRUCTURE BACK LEFT SUPPORT, TUBE GAS OD 1" ASSY, STRUCTURE BACK RIGHT CLAMP, GAS TUBE OD 1" SUPPORT, ORIFICE PLATE SUPPORT, TUBE LIQUID OD 1/2" ASSY, COIL LEFT CLAMP, TUBE LIQUID OD 1/2"...
  • Page 272 MODEL : AMC75C DESCRIPTION DESCRIPTION ASSY, BASE PAN CAP FOR FAN BLADE ASSY, COIL GUARD, FAN STRUCTURE FRONT LEFT PANEL, TOP ASSY, PARTITION PANEL, SERVICE ASSY, COMPRESSOR SCREW, TRUSSD HEAD PHILIP PLATE, VALVE SCREW, TRUSSD HEAD PHILIP ASSY, ACCESS VALVE 1/4" SCREW, TRUSSD HEAD PHILIP CLAMP, LIQUID TUBE 3/4"...
  • Page 273 MODEL : AMC100B / 125B DESCRIPTION NO. DESCRIPTION ASSY, BASE PAN MOTOR COMPRESSOR PROPELLER FAN AMC100B FAN GUARD AMC125B COVER, TER. BOARD FRONT ASSY, STRUC. BACK L HOISTING BRACKET ASSY, STRUC. BACK R STRUC. TUBE SUPT. SUPT, ORIFICE PLATE AMC100B ASSY, COIL L AMC125B AMC100B...
  • Page 274 MODEL : AMC100C DESCRIPTION DESCRIPTION ASSY, PANEL BASE PANEL, ORIFICE ASSY, COIL MOTOR PANEL, FRONT L FAN PROPELLER ASSY, PARTITION FAN GUARD COMPRESSOR PANEL, TOP PANEL, VALVE TER.BOX COVER ASSY, ACCESS VALVE PANEL, SERVICE CLAMP, TUBE LIQUID Parts not in diagram CLAMP, TUBE GAS PRESS SWITCH, 18PSI PANEL, FRONT R...
  • Page 275 MODEL : AMC150C DESCRIPTION DESCRIPTION ASSY, BASE PAN TER. BOX COVER COMPRESSOR PANEL, ORIFICE STRUC, PIPE SUPT. FAN MOTOR BRACKET ASSY, ACCESS VALVE MOTOR SUPT, TUBE LIQUID FAN PROPELLER SUPT, GAS TUBE FAN GUARD ASSY, COIL L PANEL, SERVICE T ASSY, COIL R PANEL, SERVICE B STRUC, COIL...
  • Page 276 MODEL : AMC75D / 100D DESCRIPTION NO. DESCRIPTION ASSY, BASE PAN CLAMP, TUBE LIQUID COMPRESSOR AMC75D AMC75D AMC100D AMC100D CLAMP, TUBE GAS STRUC. TUBE SUPT AMC75D AMC75D AMC100D AMC100D STRUC, FRONT L ASSY, ACCESS VALVE STRUC, FRONT R SUPT, TUBE LIQUID COVER, TER.
  • Page 277 MODEL : AMC125 / 150D DESCRIPTION NO. DESCRIPTION ASSY, BASE PAN CLAMP, TUBE LIQUID AMC125D CLAMP, GAS TUBE AMC150D STRUC, FRONT L COMPRESSOR AMC125D AMC125D AMC150D AMC150D STRUC, FRONT R STRUC, TUBE SUPT. AMC125D AMC125D AMC150D AMC150D COVER, TER. BOARD BACK ASSY, ACCESS VALVE PANEL, ORIFICE SUPT, TUBE LIQUID...
  • Page 278 MODEL : AMC200D2 / 250D2...
  • Page 279 MODEL : AMC200D2 / 250D2 DESCRIPTION NO. DESCRIPTION ASSY. PANEL BASE SUPT, LIQUID TUBE STRUC, COIL STRUC, FRONT L AMC200D2 STRUC, FRONT R AMC250D2 AMC200D2 STRUCT, BACK L AMC250D2 AMC200D2 SEPARATOR AMC250D2 AMC200D2 ASSY, COIL L BOTTOM MAIN AMC250D2 AMC200D2 STRUC, CENTRE AMC250D2 AMC200D2...
  • Page 280 MODEL : AMC300D2 DESCRIPTION DESCRIPTION ASSY, PANEL BASE SUPT, TUBE LIQUID STRUC, COIL STRUC, FRONT L STRUC, BACK L STRUC, FRONT R ASSY. COIL L BOTTOM MAIN SEPARATOR ASSY. COIL R BOTTOM MAIN STRUC, CENTRE ASSY. COIL L TOP MAIN COVER, TER.
  • Page 281 MODEL : AMC75F DESCRIPTION DESCRIPTION ASSY, BASE PAN GROUP, ASSY. COIL ASSY, BRACKET MOTOR COMPRESSOR PANEL, PARTITION RELAY MOTOR, MSL61C-501-BOM-1.6M CAPACITOR, 10uF/450VAC MOTOR, MSS75-501-BOM CAPACITOR, 15uF/450VAC FAN PROPELLER CONTACTOR, 2NO+2NC PANEL, ORIFICE TOP TERMINAL BLOCK, 20A PANEL, ORIFICE BOTTOM TERMINAL BLOCK, 50A PANEL , SIDE LEFT PHASE PROTECTOR, PP1.03 STRUCTURE, FRONT RIGHT...
  • Page 282 MODEL : AMC100F DESCRIPTION DESCRIPTION ASSY, BASE PAN GROUP, ASSY. COIL ASSY, BRACKET MOTOR COMPRESSOR PANEL, PARTITION RELAY MOTOR, MSL61C-501-BOM-1.6M CAPACITOR, 10uF/450VAC MOTOR, MSL61C-501-BOM-1.6M CAPACITOR, 10uF/450VAC FAN PROPELLER CONTACTOR, 2NO+2NC PANEL, ORIFICE TOP TERMINAL BLOCK, 20A PANEL, ORIFICE BOTTOM TERMINAL BLOCK, 50A PANEL , SIDE LEFT PHASE PROTECTOR, PP1.03 STRUCTURE, FRONT RIGHT...
  • Page 283 MODEL : AMC125F DESCRIPTION DESCRIPTION ASSY, BASE PAN GROUP, ASSY. COIL ASSY, BRACKET MOTOR COMPRESSOR PANEL, PARTITION RELAY MOTOR, MSL60C-501-BOM-1-HA CAPACITOR, 15uF/450VAC MOTOR, MSL60C-501-BOM-1-HA CAPACITOR, 15uF/450VAC FAN PROPELLER CONTACTOR, 2NO+2NC PANEL, ORIFICE TOP TERMINAL BLOCK, 20A PANEL, ORIFICE BOTTOM TERMINAL BLOCK, 50A PANEL , SIDE LEFT PHASE PROTECTOR, PP1.03 STRUCTURE, FRONT RIGHT...
  • Page 284 While upmost care is taken in ensuring that all details in the publication are correct at time of going to press, we are constantly striving for improvement and therefore reserve the rights to alter model spercifications and equipment without prior notice. Details of specifications and equipment are also subject to change to suit local conditions and equirements and not all models are available in every market.

This manual is also suitable for:

Amc75bAmc75cAdb100bAmc100bAmc100cAdb125b ... Show all

Table of Contents
