  • Page 1 ® P R O D U C T I N F O R M A T I O N Rotor ® The World’s Best-Selling Rotor for Residential and Light Commercial Applications...

  • Page 2: Table Of Contents

    ® TABLE OF CONTENTS Product Overview ..................1 Product Features and Benefits ..............2 Product Comparisons................. 6 Nozzle Replacement Guide ............... 7 Technical Information................8 Product Performance ................. 9 Installation Details ................... 10 Installation and Maintenance ..............11 PGS Replacement Parts ................14 PGP Replacement Parts ................

  • Page 3: Product Overview

    Rotor ® PRODUCT OVERVIEW In the 1950ʼs, Edwin J. Hunter became the first Different Applications, Different Models to design and patent plastic gear driven sprin- The patriarch of the PGP family is the stan- klers. His revolutionary concept was applied...

  • Page 4: Product Features And Benefits

    40˚ to 360˚ Adjustable Arc, most odd shaped areas can be irrigated with a quick turn of the twelve nozzles provide a system with the Hunter wrench. The PGP can be adjusted up or ultimate in versatility for any application. down, wet or dry, for maximum convenience.
  • Page 5 The blank nozzle is just one more feature Typical slope installation that sets the Hunter PGP rotor apart from using PGS shrub sprinklers. the competition. Proven, Long-Life Water Lubricated Quick Check™...
  • Page 6 When the right side valve feature can be added to PGP sprinklers arc-stop needs adjustment, and unscrewing in the field by ordering Hunter part # 142300. the rotor case or removing the entire internal This field installed check valve will hold back assembly is not the answer, just pull-up the water to a maximum of 2 ft.
  • Page 7 Rotor ® Shrub Staking Kit Hunter Nozzle Height and Trajectory Chart Secure installation of Sprinkler Nozzle Pressure Degrees Max Height Distance shrub rotors on slopes or Model in PSI of Trajec- of Spray from head tory (ft.) (ft.) to Max.

  • Page 8: Product Comparisons

    ® PRODUCT COMPARISONS Rain Bird Hunter Toro Toro Toro Rain Bird Rain Bird Features T-Bird Super 700 Super 600 V-1550 R-50 5000 ® (T-Tree) Standard angle nozzles Low angle nozzles Pull-up socket for easy servicing   Arc Adjustment, without removing parts ...

  • Page 9: Nozzle Replacement Guide

    6704 (Black) Maxi-Paw 2045 06 (Red) 316-XX-03 07 (Black) 6760 see “Single Nozzle” 08 (Blue) XP 300 Series XP-300-090-07 Pro 6000 Use Hunter 4-11 10 (Yellow) 180-07 Pro 6500 12 (Beige) 360-07 090-09 R-50 1.5 (Black) 180-09 2.0 (Brown) 360-09 3.0 (Gray)

  • Page 10: Technical Information

    ® TECHNICAL INFORMATION MODELS PGS – Shrub PGP – 4" Pop-up (10 cm) PGH – 12" Pop-up (30 cm) DIMENSIONS • Overall height: PGS – 7³⁄ " (19 cm) PGP – 7³⁄ " (19 cm) PGH – 17" (43 cm) •...

  • Page 11: Product Performance

    Optimum performance is shown in bold. For information on testing standards and precipitation rate calculations, see 0.77 12.9 Hunter Irrigation Products catalog. 10.4 0.89 14.8 To measure pressure at the nozzle of a PGS, PGP, PGH or any rotor sprinkler, order Hunter rotor pressure gauge kit part # 122900. 11.3 1.00 16.7 11.6 1.07 17.8 10.1...

  • Page 12: Installation Details

    ® INSTALLATION DETAILS FINISH GRADE FINISH GRADE RUBBER COVER MODEL PGP GEARED ROTOR MODEL PGP GEARED ROTOR POLY ELL 3/4" SCH 80 RISER (LENGTH AS REQUIRED) STREET ELL SADDLE POLY PIPE (LENGTH AS REQUIRED) POLY LATERAL LINE POLY ELL LATERAL LINE ®...

  • Page 13: Installation And Maintenance

    1. Using the palm of your hand, rotate the nozzle turret counterclockwise to the left To Decrease the Arc: stop to complete any interrupted rotation 1. Insert the plastic key end of the Hunter cycle (Fig. 2). wrench into the adjustment socket (Fig. 3 & 4).
  • Page 14 INSTALLATION AND MAINTENANCE (continued) Radius/Distance of Throw Aligning the Right (fixed) Side of Arc Insert the steel hex end of the Hunter wrench If the right side of the arc into the radius adjustment screw (Fig. 6). Turn is not properly aligned,...
  • Page 15 Secure installation of shrub rotors on STAKING KIT slopes and shrub areas. The Hunter Shrub Staking Kit allows con- tractors to install PGS & I-10 with ease and security to assure complete sprinkler stability and vandal resistance. The kit is used with a ⁄...

  • Page 16: Pgs Replacement Parts

    ® PGS REPLACEMENT PARTS Item Description Catalog No. HDPE Standard Nozzle Set (12) 25˚ Trajectory 130900 Low Angle Nozzle Set (7) 13˚ Trajectory 233200 Set Screw 120300 Protective Rubber Cover (Fits Units Manufactured After 2/93) HDPE Black (ADJ) 269400 Black (360) 295800 Purple (ADJ) 297900...

  • Page 17: Pgp Replacement Parts

    Rotor ® PGP REPLACEMENT PARTS Item Description Catalog No. Standard Nozzle Set (12) 25˚ Trajectory 130900 Low Angle Nozzle set (7) 13˚ Trajectory 233200 Set Screw 120300 Protective Rubber Cover (Fits Units Manufactured After 2/93) Black (ADJ) 269400 Black (360) 295800 Purple (ADJ) 297900...

  • Page 18: Pgh Replacement Parts

    ® PGH REPLACEMENT PARTS Item Description Catalog No. Standard Nozzle Set (12) 25˚ Trajectory 130900 Low Angle Nozzle set (7) 13˚ Trajectory 233200 Set Screw 120300 Protective Rubber Cover (Fits Units Manufactured After 2/93) Black (ADV) 269400 Black (36V) 295800 Purple (ARV) 297900 Purple (3RV)

  • Page 19: Precipitation Rate And Sprinkler Run Time Formulas

    Rotor ® PRECIPITATION RATE Two formulas are shown below, the first is most useful when comparing precipitation rates between different types of sprinklers or calculating precipitation rates on areas with a single type of sprinkler and uniform head and row spacing. The second method is better suited to areas where sprinkler head flows or spacing varies.
  • Page 20 ® Hunter Industries Incorporated • The Irrigation Innovators © 2003 Hunter Industries Incorporated 1940 Diamond Street • San Marcos, California 92069 • TEL: (1) 760-744-5240 • FAX: (1) 760-744-7461 www.HunterIndustries.com P/N 700427 LIT-213 1/03...
