TDT C1500
Router Configuration
Technical Product Information No. 10.02
Product/Version
Date
Topic
Short description
Download Current
Firmware Version
Download
CamControl LITE
Demo Version
Download
CamControl PRO
Demo Version
Contents:
1.
Introduction .................................................................................................................................... 2
2.
Requirements.................................................................................................................................. 2
3.
Router Preparation......................................................................................................................... 3
3.1.
Insert data card ................................................................................................................................ 3
3.2.
Power supply.................................................................................................................................... 3
3.3.
Network connection ........................................................................................................................ 3
4.
C1500 Router Configuration via Web Browser............................................................................ 4
4.1.
Creating a connection to the router ............................................................................................... 4
4.2.
Overview of Web interface ............................................................................................................. 5
4.3.
Configuring PPP Connections .......................................................................................................... 6
4.4.
Diagnosing connection problems ................................................................................................. 13
4.5.
Changing the network address of the LAN interface.................................................................. 15
5.
Transmitter Configuration (CamDisc/CamTel/CamServer/Cam4mobile)................................. 17
5.1.
Connection settings ....................................................................................................................... 17
5.2.
HTconnect....................................................................................................................................... 18
Technical Production Information
CamDisc HNVR 10, CamDisc SVR 4s, CamDisc SVR 10s,
CamServer 2, CamDisc SVR 4, CamDisc SVR 10, CamTel SVR 4,
CamTel SVR 10, Cam4mobile 4, Cam4mobile 10
March 2010
TDT C1500 Router Configuration
HeiTel-specific configuration of the TDT C1500 router
CamDisc S R 4s, CamDisc SVR 10s, CamServer 2:
V
http://www.heitel.com/en/service/upgrades/firmware/camdisc-svr-s-camserver-2
CamDisc SVR 4, CamDisc SVR 10, CamTel SVR 4, CamTel SVR 10, Cam4mobile 4,
Cam4mobile 10:
http://www.heitel.com/en/service/upgrades/firmware/camtel-svr-camdisc-svr-cam4mobile
CamDisc HNVR:
http://www.heitel.com/en/service/upgrades/firmware/camdisc-hnvr
http://www.heitel.com/en/service/downloads/CamControl LITE
http://www.heitel.com/en/service/downloads/CamControl PRO
© HeiTel Digital Video GmbH 2010
1/18
Advertisement
Table of Contents
Related Manuals for HeiTel TDT C1500
Summary of Contents for HeiTel TDT C1500
-
Page 1: Table Of Contents
Configuring PPP Connections ......................6 4.4. Diagnosing connection problems ....................13 4.5. Changing the network address of the LAN interface..............15 Transmitter Configuration (CamDisc/CamTel/CamServer/Cam4mobile)......... 17 5.1. Connection settings ........................17 5.2. HTconnect............................18 1/18 Technical Production Information © HeiTel Digital Video GmbH 2010... -
Page 2: Introduction
The following specifications are assumed: • CamDisc/CamTel/CamServer/Cam4mobile transmitters with device firmware 1.80 or higher • 12 V DC power supply unit for HeiTel transmitters (8-30 V DC power supply for Cam4mobile) • CamControl LITE or CamControl PRO software of version 3.82 or higher as receiver and archive access software ... -
Page 3: Router Preparation
TDT C1500 Router Configuration 3. Router Preparation 3.1. Insert data card Insert the SIM card into the SIM 2 slot inside your C1500 router. Ensure that the SIM card used is not PIN-protected. 3.2. Power supply Connect to the power supply in accordance with manufacturer instructions. 3.3. Network connection The C1500 router has two network interfaces (WAN and LAN). For router configuration with a PC or Notebook or to connect a HeiTel video system, use only the LAN network interface. 3/18 Technical Production Information © HeiTel Digital Video GmbH 2010... -
Page 4: C1500 Router Configuration Via Web Browser
TDT C1500 Router Configuration 4. C1500 Router Configuration via Web Browser Before the C1500 router can be operated with a HeiTel system, it must be configured appropriately. A DHCP service is active on the router. Initial access should be via a CrossLink ... -
Page 5: Overview Of Web Interface
The Networking area is the most multifaceted since the entire scope of function is configurable here. For a mobile network connection, the area PPP Functions is used. • The log files and status displays under Diagnose can be used to locate errors. • Configuration changes to the router are temporary: following a restart or power failure, default or previously stored configurations are active. To create a permanent configuration, after entering changes under Permanent Save the function Save Config must be accessed. 5/18 Technical Production Information © HeiTel Digital Video GmbH 2010... -
Page 6: Configuring Ppp Connections
GRPS or UMTS, selected or those actions configured that are accessed following establishment of the connection, e.g. DynDNS update. Click on the PPP Functions symbol to access the relevant function. First, a PPP Interface with data belonging to the desired mobile network provider must be configured. 6/18 Technical Production Information © HeiTel Digital Video GmbH 2010... - Page 7 TDT C1500 Router Configuration The PPP Interfaces function contains a list of existing entries. When delivered it is empty: No PPP interfaces configured Click Create a new PPP interface to create a new PPP Interface. Accept the default setting PPP0 and select the option UMTS/GPRS. Click Create to open the editing mask. Adjust the parameter for the SIM card used (SIM card = SIM 2). 7/18 Technical Production Information © HeiTel Digital Video GmbH 2010...
- Page 8 TDT C1500 Router Configuration The SIM card must not be PIN-protected. The SIM 2 slot is located inside the device and is the only one that should be used. You now need to enter the PPP access data for the relevant provider in the editing mask. Example: Vodafone Germany APN: web.vodafone.de Username: Password: All other settings are to be entered as shown on the screenshot. Once you have made these settings, complete the procedure by pressing Save. 8/18 Technical Production Information © HeiTel Digital Video GmbH 2010...
- Page 9 TDT C1500 Router Configuration For trouble-free Internet access, under Advanced Settings the entry Add a Defaultroute must be changed to Yes. All other entries are standard settings. After you click Save the previous page listing the PPP Interfaces is displayed and ppp0 must be opened again for editing. Select here the Advanced Settings button. Here too, close this editing mask by pressing Save. 9/18 Technical Production Information © HeiTel Digital Video GmbH 2010...
- Page 10 To do so, the Connection-Manager (see Networking/Connection- Manager Functions) is required. This is responsible for dynamic connection, i.e. connection when required, or static connection, i.e. connection as soon as the router is started. Click the Connection-Manager Functions symbol to access the relevant function. Click on the Static Connections symbol to access the relevant function. 10/18 Technical Production Information © HeiTel Digital Video GmbH 2010...
- Page 11 Click Add Connection to open a mask on which to create a new connection. Under Use Interface the ppp0 interface created is selected by default. All other settings can be accepted as they are. Create the entry by clicking Create. Click Return to Connection-Manager to return to the overview where the connection you just created is now displayed. Under “Activate Connection-Manager” select Yes and accept the settings by clicking Apply Changes. To check the PPP connection to the mobile network provider, use the function Active PPP Connections (see Networking/PPP Functions/Active PPP Connections). 11/18 Technical Production Information © HeiTel Digital Video GmbH 2010...
- Page 12 TDT C1500 Router Configuration This function is used to check the previously made settings. If a connection was created, under Active PPP Connections the current values for Type (connection type), Local IP (WAN IP address of the router), Remote IP (provider IP address), State (status) and Uptime (operating time) are displayed. 12/18 Technical Production Information © HeiTel Digital Video GmbH 2010...
-
Page 13: Diagnosing Connection Problems
GSM/GPRS/UMTS connection the function GSM Modem State is the means by which to ensure that everything is okay with the mobile network connection, that signal strength is sufficient and that registration with the provider was successful. For analyses, system information and the router logs are available. If a connection has been created successfully, data on the registered network is given here. The Signal Quality bar indicates the signal strength of the mobile network. Click Refresh to update the display. 13/18 Technical Production Information © HeiTel Digital Video GmbH 2010... - Page 14 If the signal is too weak, relocate the router or use an external additional antenna. If not, intermittent connectivity or considerably slower transfer speeds could result. The LED indicators at the front provide information on the current operating status (see TDT C1500 series device manual). 14/18 Technical Production Information © HeiTel Digital Video GmbH 2010...
-
Page 15: Changing The Network Address Of The Lan Interface
Router Configuration 4.5. Changing the network address of the LAN interface The LAN interface is administered in the router as eth0. Under Networking you will find the option Network Configuration. Click Network Interfaces to view a list of all interfaces. 15/18 Technical Production Information © HeiTel Digital Video GmbH 2010... - Page 16 Activated at Boot Time. IP address, network mask and MTU can be adapted to the existing network. The IP address adapted here is the gateway address for other devices in the network of the router. The DHCP service active on the router can generate collisions in a network with other DHCP services. Further documentation and configuration options including tips can be found in the manual or on the manufacturer page of the router: http://www.tdt.de 16/18 Technical Production Information © HeiTel Digital Video GmbH 2010...
-
Page 17: Transmitter Configuration (Camdisc/Camtel/Camserver/Cam4Mobile)
If you wish to use the DHCP function of the C1500 router and the latter was configured correctly, instead of the connection settings given above you can also activate the Obtain an IP address automatically (DHCP) function and if necessary also the Obtain a DNS server address automatically function. The HeiTel system then obtains the IP address and if necessary the address of the DNS server from the router. 17/18 Technical Production Information © HeiTel Digital Video GmbH 2010... -
Page 18: Htconnect
Router Configuration 5.2. HTconnect Since, generally speaking, no fixed IP addresses are assigned in UMTS networks and the transmitter cannot therefore be reached directly, HeiTel uses the HTconnect procedure with which the transmitter sets up an active connection to the receiving PC. To use HTconnect under Connections/HTconnect the fixed IP address of the receiving PC ...
