Sierra Wireless GX400
Router Configuration
Technical Product Information No. 11.06
For product/version CamDisc HNVR 10, CamDisc SVR 4s, CamDisc SVR 10s,
Date
Subject
Summary
Download current
firmware version
Download
CamControl LITE
Demo Version
Download
CamControl PRO
Demo Version
Contents:
1.
Introduction .................................................................................................................................... 2
2.
Requirements.................................................................................................................................. 2
3.
Router preparation ........................................................................................................................ 3
3.1.
Insert data card ................................................................................................................................ 3
3.2.
Create Ethernet/GPS connection..................................................................................................... 3
3.3.
Power supply.................................................................................................................................... 4
4.
GX400 router configuration per AceManager ............................................................................. 5
4.1.
Creating a connection to the router ............................................................................................... 5
4.2.
Entry of APN ..................................................................................................................................... 6
4.3.
Changing the network address of the LAN interface.................................................................... 7
4.4.
Port Forwarding ............................................................................................................................... 8
4.5.
GPS settings...................................................................................................................................... 8
4.6.
Diagnosing ConnectionProblems .................................................................................................... 9
5.
Transmitter Configuration (CamDisc/CamTel/CamServer/Cam4mobile)................................. 11
5.1.
Connection settings ....................................................................................................................... 11
5.2.
HTconnect....................................................................................................................................... 12
5.3.
GPS settings.................................................................................................................................... 12
Technical Product Information
CamServer 2, CamDisc SVR 4, CamDisc SVR 10, CamTel SVR 4,
CamTel SVR 10, Cam4mobile 4, Cam4mobile 10
December 2011
Sierra Wireless GX400 Router Configuration
HeiTel-specific configuration of the Sierra wireless GX400 router
CamDisc SVR 4s, CamDisc SVR 10s, CamServer 2; CamServer 2c:
http://www.heitel.com/en/service/upgrades/firmware/camdisc-svr-s-camserver-2
CamDisc SVR 4, CamDisc SVR 10, CamTel SVR 4, CamTel SVR 10, Cam4mobile 4,
Cam4mobile 10:
http://www.heitel.com/en/service/upgrades/firmware/camtel-svr-camdisc-svr-cam4mobile
CamDisc HNVR:
http://www.heitel.com/en/service/upgrades/firmware/camdisc-hnvr
http://www.heitel.com/en/service/downloads/CamControl LITE
http://www.heitel.com/en/service/downloads/CamControl PRO
© HeiTel Digital Video GmbH 2011
1/13
Advertisement
Table of Contents
Related Manuals for HeiTel GX400
Summary of Contents for HeiTel GX400
-
Page 1: Table Of Contents
3.1. Insert data card ..........................3 3.2. Create Ethernet/GPS connection..................... 3 3.3. Power supply............................ 4 GX400 router configuration per AceManager ................5 4.1. Creating a connection to the router ....................5 4.2. Entry of APN ............................. 6 4.3. Changing the network address of the LAN interface..............7 4.4. -
Page 2: Introduction
The following specifications are assumed: • CamDisc/CamTel/CamServer/Cam4mobile transmitters with device firmware 1.90 or higher • 12 V DC power supply unit for HeiTel transmitters (8-30 V DC power supply for Cam4mobile) • CamControl LITE or CamControl PRO software of version 3.90 or higher as receiver and archive access software ... -
Page 3: Router Preparation
Sierra Wireless GX400 Router Configuration 3. Router preparation 3.1. Insert data card Insert the SIM card into the correct slot located inside your GX400 router. 3.2. Create Ethernet/GPS connection Connect your HeiTel video system to the GX400 router in accordance with the following diagram. Antenna for UMTS and GPS Cellular Diversity/AUX... -
Page 4: Power Supply
Sierra Wireless GX400 Router Configuration Serial interface (D-Sub 9-pin): Sierra wireless HeiTel GX400 Transmitter Pin 2 Pin 3 Pin 3 Pin 2 Pin 5 Pin 5 Pin 7 Pin 8 Pin 8 Pin 7 3.3. Power supply Connect to the power supply in accordance with manufacturer instructions. 4/13 Technical Product Information © HeiTel Digital Video GmbH 2011... -
Page 5: Gx400 Router Configuration Per Acemanager
Sierra Wireless GX400 Router Configuration 4. GX400 router configuration per AceManager Before the GX400 router can be operated with a HeiTel system, it must be configured. To do so, install the AceManager software on the CD and launch it. A DHCP service is active on the router. We therefore recommend that you create the initial access via a USB connection in order not to collide with other active DHCP services within a network. When the USB cable is connected for the first time, your PC demands the installation of the driver AirLink USB Ethernet/RNDIS which is included on the CD supplied. The menu structure on the version of AceManager you are using may differ from the version ... -
Page 6: Entry Of Apn
User Name: user • Password: 12345 4.2. Entry of APN Once a connection has been created, "Custom" must be selected as APN Type under the menu item WAN/Cellular and the APN of your mobile phone provider entered under Custom APN. If necessary contact your mobile network operator to obtain the necessary information. Example: Vodafone Germany APN: web.vodafone.de User Name: Password: Note: The SIM card used must not have a PIN number. The input field SIM PIN must therefore be left empty. 6/13 Technical Product Information © HeiTel Digital Video GmbH 2011... -
Page 7: Changing The Network Address Of The Lan Interface
Host Public Mode to All Hosts User Private IP to be able to use a private IP address assignment for the HeiTel transmitter. The IP address adjusted here (device IP: 192.168.13.31) is the Gateway address for other devices (e.g. your HeiTel transmitter) in the network of the router. If you are in a network with other active DHCP services, you should set the DHCP Server Mode in the Ethernet menu to 0-Disabled. Alternatively, you can also use the router's DHCP function to automatically assign an IP address to your HeiTel system. Enter the DHCP area in the designated fields Start IP and Ending IP. 7/13 Technical Product Information © HeiTel Digital Video GmbH 2011... -
Page 8: Port Forwarding
CamControl iPhone and CamControl Android) must be configured in accordance with the router manual. 4.5. GPS settings The GX400 router has an integrated GPS receiver. GPS data can be transferred to CamDisc via a serial interface. The GPS receiver must supply data in accordance with the NMEA 0183 standard with the GPRMC data record via the serial interface to the HeiTel transmitter. Therefore, in the router menu GPS, Local/Streaming set the GPS Reports port to DB9 Serial and check the value for GPS Reports Type, which must be set to NMEA GGA+VTG+RMC. 8/13 Technical Product Information © HeiTel Digital Video GmbH 2011... -
Page 9: Diagnosing Connectionproblems
If the power LED lights up yellow intermittently, this indicates reception of GPS data. Other LED status messages can be found in the manual of the GX400 router. Furthermore, the Status menu gives you information on a successfully created connection to the network of your mobile network provider and on GPS reception quality. 9/13 Technical Product Information © HeiTel Digital Video GmbH 2011... - Page 10 Sierra Wireless GX400 Router Configuration Further documentation and configuration options including tips can be found in the manual or on the manufacturer page of the router: http://www.sierrawireless.com 10/13 Technical Product Information © HeiTel Digital Video GmbH 2011...
-
Page 11: Transmitter Configuration (Camdisc/Camtel/Camserver/Cam4Mobile)
If you wish to use the DHCP function of the GX400 router and the latter was configured correctly, instead of the connection settings given above you can activate the Obtain an IP address automatically (DHCP) function or if necessary the Obtain a DNS server address automatically ... -
Page 12: Htconnect
For alarm forwarding, settings may need to be made under Connections/Phone & IP numbers. 5.3. GPS settings The GPS (Global Positioning System) function was primarily designed for Cam4mobile devices. The GPS receiver integrated in the GX400 router is connected via the serial interface with a Cam4mobile. 12/13 Technical Product Information ©... - Page 13 Depending on the GPS receiver, baud rate and mode can vary and must be parameterised in accordance with the manufacturer's specifications. If necessary, the parameters can be adjusted in the Serial GX400 menu. The standard values of the serial port are configured to 115200 Baud, 8N1. 13/13 Technical Product Information © HeiTel Digital Video GmbH 2011...
