- Page 1 Dorado Handheld Reader Wi-Fi User Manual Dorado Handheld Reader Wi-Fi User Manual Version 2.0 Copyright © 2017 – 09 – 01 SSI reserves the right to change specifications without prior notice...
- Page 2 All other products names mentioned herein may be trademarks of their respective companies. Star Systems International Ltd. shall not be liable for technical or editorial errors or omissions contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material.
- Page 3 Just use the included carrying case on your belt or carry it in your pocket! You can easily connect and download all your collected data files from Dorado directly into your application via the computer's USB port. Optional Wi-Fi and Bluetooth interface with corresponding Android and iOS app is also available.
-
Page 4: Table Of Contents
Attaching GPS Data/Photo to Record ......................13 Uploading/Sending records through FTP/Email ....................14 Dorado Wi-Fi iOS App ....................... 15 Starting the App ............................15 Reset Wi-Fi ..............................16 Export Data Format ............................17 Hardware Products Warranty Statement .................. 18 Appendix ..........................19 Dorado Handheld Reader – Wi-Fi - Version 2.0... -
Page 5: Wi-Fi Setting Interface
Wi-Fi Setting Interface Power up Dorado by holding the MIDDLE button. If Dorado is in AP (default) or APSTA mode, a new access point can be found in the wireless network. The default AP name is “DoradoXXXXXX” (XXXXXX is the serial no. found on the back of Dorado) or “HF-LPB”... -
Page 6: Work Mode
Dorado current support 3 work modes: AP, APSTA and STA mode AP Mode (default) Dorado will act as an Access Point and broadcast its SSID to the wireless network. User can connect to Dorado by searching for Dorado’s SSID and connect to it as a client. -
Page 7: Sta Setting
STA Setting Network Name: SSID of the network Dorado will connect to in STA mode. Press “Scan” to scan for existing networks or enter the SSID manually Encryption Method: Encryption mode of the network Dorado is connecting to as a client If the network has DHCP enabled, choose “enable”... -
Page 8: Ap Setting
Encryption Mode: WPA2-PSK encryption could be enabled in AP mode to prevent unauthorized access to Dorado. Once an encryption mode is selected, additional option for password will be shown in the menu. IP Address (DHCP Gateway Setting): Default IP of Dorado in AP mode DHCP Server: Once enabled, clients connected to the Dorado access point will be automatically assigned an IP. -
Page 9: Other Setting
Network Parameters Setting – Port ID: This is the port client listen to when trying to connect to Dorado in AP or STA mode. If user wants to connect to Dorado with the iOS or Android app, please do not change this setting. -
Page 10: Wi-Fi Config Interface Account Setup
Upgrade Wi-Fi Module Firmware Firmware upgrade for the Wi-Fi module Note: This interface does NOT represent the firmware of the RFID module of Dorado. Please refer to the Dorado Firmware Update Guide for information on updating the RFID module firmware. -
Page 11: Dorado Wi-Fi Android App
App. User can confirm connection through the Dorado WiFi Setting Interface. Connect the phone to the same network as Dorado and start the App. The screen o nthe right would be displayed Dorado Handheld Reader – Wi-Fi - Version 2.0... -
Page 12: App Settings
Click the “Menu” button on the Android device, a menu on the right will be shown. Click “Settings” to enter the setting menu. Device IP IP of Dorado the app is about to connect. Default IP of Dorado in AP mode is 10.10.100.254, port 8899. FTP Server IP The app support uploading data record to a designated (S)FTP site. -
Page 13: Establishing Connection
Upon successful connection, the connection status at the bottom of the screen will change to “Connected” User can use the Dorado to read and tag to test the connection. Data will be transmitted to the app when user releases the MIDDLE button of Dorado after a tag read. Tag data will be displayed on the app’s interface. -
Page 14: Attaching Gps Data/Photo To Record
After attaching GPS data or photo to a record, a small icon will be displayed next to the record to indicate extra data is attached Dorado Handheld Reader – Wi-Fi - Version 2.0... -
Page 15: Uploading/Sending Records Through Ftp/Email
Upload Selected Item: The app will attempt to upload the selected records through the ftp defined in the App Setting. If username and password is required for the ftp, user will need to define them in the App Setting page first for the upload to process correctly. Dorado Handheld Reader – Wi-Fi - Version 2.0... -
Page 16: Dorado Wi-Fi Ios App
App. User can confirm connection through the Dorado WiFi Setting Interface. Connect the phone to the same network as Dorado and start the App. The screen o nthe right would be displayed Dorado Handheld Reader – Wi-Fi - Version 2.0... -
Page 17: Reset Wi-Fi
Reset Wi-Fi If Dorado’s Wi-Fi parameter is set to an incorrect state which reconnection to the Wi-Fi Setting Interface impossible, user can reset all Wi-Fi parameter to default with the following procedure. 1. Start Dorado by holding the MIDDLE button 2. -
Page 18: Export Data Format
A XML file containing the tag, GPS data and photo filename Photos Sample XML data record <RECORD> <DATETIME>14/2/24 PM 8:17</DATETIME> <DATETIME_RAW>1393244263753</DATETIME_RAW> <SERIAL>DORADO001</SERIAL> <TYPE>USER</TYPE> <EPC>3000E2003065951700431130A605</EPC> <TID>E20034120126FF000153A6051B0A015600055FFBFFFFDC60</TID> <USER> 0000000000000000000000000000000000000000000000000000000000000000000000000000000000 0000000000000000000000000000000000000000000000 </USER> <GPS> <LATITUDE>22.3647865</LATITUDE> <LONGITUDE>114.1343735</LONGITUDE> </GPS> <IMAGE_NAME>20140224_201907.jpg</IMAGE_NAME> </RECORD> Dorado Handheld Reader – Wi-Fi - Version 2.0... -
Page 19: Hardware Products Warranty Statement
Prior to shipping a product to STAR Systems International for warranty inspection, replacement or repair, an RMA number must be obtained from STAR Systems International’s RMA department at +852 3691 9925 or by email at helpdesk@star-int.net. RMA forms can be downloaded from the STAR Systems International website or the Customer can receive the form by fax (+852 37474065) or email by contacting the RMA department. -
Page 20: Appendix
(in PDF). Visit the Star Systems University at www.star-int.net and click Tech Support > Star Systems University to review technical information or to request technical support for your RFID product. Send Feedback Your feedback is crucial to the continual improvement of our documentation. To provide feedback about this manual, please visit the Contact Us at www.star-int.net. - Page 21 Dorado Handheld Reader Wi-Fi User Manual Version 2.0 Copyright © 2017 – 09 – 01 SSI reserves the right to change specifications without prior notice...
